| Ref | Part Number | Description |
|---|
| 1 |
710-0726 |
Screw, 5/16-12 x.750 Price: $3.82 |
| 2 |
710-0599 |
Self-tapping Screw, 1/4-20 x.5 Price: $3.86 |
| 3 |
783-04829 |
SIDE PANEL (LH) Not Available Price: |
| 4 |
946-1084 |
Throttle Cable This part replaces 746-1084. Price: $29.76 |
| 5 |
731-1999 |
Choke Plug Price: $8.98 |
| 6 |
731-06414 |
LENS-T STYLE Not Available This part replaces 731-05357. Price: |
| 7 |
738-04091A |
Shoulder Screw, .43 x .29 This part replaces 738-04091. Price: $3.50 |
| 8 |
783-04827 |
HOOD Not Available Price: |
| 9 |
783-04828 |
SIDE PANEL (RH) Not Available Price: |
| 10 |
783-04840 |
Pivot Bracket - RH Price: $16.32 |
| 10 |
783-04841 |
HOOD PIVOT BRACKET Not Available Price: |
| 11 |
783-04606C |
Hood Pivot Bracket This part replaces 783-04606A. Price: $34.80 |
| 12 |
712-0185 |
SPEED NUT 1/4-20 Not Available Price: |
| 13 |
751-10283B |
FUEL TANK (3 GAL) This part replaces 751-10283. Price: $153.84 |
| 14 |
751-0603B |
TANK CAP This part replaces 751-0603. Price: $20.42 |
| 15 |
710-1017 |
Screw, 1/4-14 x.625 Price: $7.26 |
| 16 |
710-0895 |
Self-tapping Screw, 1/4-15 x.75 Price: $5.82 |
| 17 |
710-3217 |
Truss Phillips Screw, #8-32 x .375 Price: $5.94 |
| 18 |
712-0142 |
Hex Nut, #8-32 Price: $3.90 |
| 19 |
731-1857 |
Throttle Control Knob Price: $12.90 |
| 20 |
731-06167 |
DASH PANEL TROY W/MAN PTO N/WIND Not Available This part replaces 731-05001A. Price: |
| 21 |
731-04729 |
CUISE LEVER Not Available Price: |
| 22 |
731-04728 |
BRAKE LEVER Not Available Price: |
| 23 |
747-04161 |
SUPPORT ROD (LH) Not Available Price: |
| 24 |
747-1196 |
Brake/Cruise Pivot Rod Price: $13.38 |
| 25 |
929-04083B |
Harness, Headlight This part replaces 629-04083. Price: $34.50 |
| 26 |
925-04156 |
Ammeter Monitor Indicator This part replaces 725-04156. Price: $25.99 |
| 27 |
783-04285F-0637 |
DASH SUPPORT Not Available This part replaces 783-04908. Price: |
| 28 |
710-0642 |
Self-tapping Screw, 1/4-20 x .75 Price: $4.05 |
| 29 |
783-04323F-0637 |
DASH SUPPORT Not Available This part replaces 783-04909. Price: |
| 30 |
925-0963 |
Lamp This part replaces 725-0963. Price: $6.73 |
| 31 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 32 |
710-1611B |
Screw, 5/16-18 x.75 Price: $5.94 |
| 33 |
925-1649A |
HEADLIGHT SOCKET (1/4 TURN) This part replaces 725-1649. Price: $10.30 |
| 34 |
925-06119C |
IGNITION MODULE SWITCH RMC (MAN PTO BLK) This part replaces 725-04227A. Price: $102.50 |
| 35 |
925-1745A |
IGNITION KEYS This part replaces 725-1745. Price: $15.91 |
