| Ref | Part Number | Description |
|---|
| 1 |
530037793 |
Foam - Air Filter Price: $1.99 |
| 2 |
256-268 |
BUSHING Price: $18.24 |
| 2 |
530016101 |
Nut Price: $1.99 |
| 3 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 3 |
530049244 |
Grommet-Carb Adjust Price: $1.99 |
| 4 |
105-7441 |
BEARING-SPHERICAL Price: $56.85 |
| 4 |
530038479 |
Limiter Cap-High (red) Price: $1.99 |
| 5 |
32151-34 |
RING-RETAINING Price: $0.67 |
| 5 |
530038478 |
Limiter Cap-Low(blue) Price: $1.99 |
| 6 |
119-2200 |
PAD-RUBBER, REAR HOC Price: $10.33 |
| 7 |
119-2230 |
PAD-PLASTIC, REAR HOC Price: $7.14 |
| 8 |
110-0606 |
RIVET-BLIND Price: $1.15 |
| 8 |
530069247 |
Kit-Fuel Line (Small) Price: $3.99 |
| 9 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 10 |
530047127 |
CYLINDER This part replaces 530069606. Price: $59.99 |
| 11 |
530016136 |
Clip-High Tension Lead Price: $1.99 |
| 12 |
530016153 |
Screw Price: $1.99 |
| 13 |
530055187 |
Shield-Cylinder 2075c Price: $17.99 |
| 13 |
530056047 |
Shield-Cylinder 2075oc Price: $17.99 |
| 13 |
530071310 |
Shield-Cylinder 2075 Price: $9.99 |
| 14 |
530071835 |
Kit-Purge Bulb This part replaces 530047213. Price: $5.99 |
| 15 |
530015780 |
Screw Price: $1.99 |
| 16 |
530095646 |
Assy-Fuel Pick-up Price: $2.99 |
| 17 |
530037652 |
Insulator-Heat Price: $1.99 |
| 18 |
530052296 |
Assy. -Wire Harness Price: $4.99 |
| 20 |
530047442 |
Strap-Ground Price: $1.99 |
| 21 |
530039198 |
Module - Ignition This part replaces 530052277. Price: $29.99 |
| 22 |
530015814 |
Screw Price: $1.99 |
| 24 |
530016132 |
Screw Price: $1.99 |
| 25 |
530036103 |
Screen-Spark Price: Call Us |
| 26 |
530037813 |
Diffuser-Muffler Price: $1.99 |
| 27 |
530069608 |
Gasket-Muffler Price: $5.99 |
| 28 |
530049870 |
Backplate-Muffler Price: $3.99 |
| 29 |
545113101 |
CRANKSHAFT ASSY This part replaces 530047062. Price: $54.99 |
| 30 |
530037935 |
Cap-Crankcase Price: $8.99 |
| 31 |
530056363 |
Assy.-Seal & Bearing Price: $11.99 |
| 33 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 34 |
530029805 |
Ring - Piston Price: $2.99 |
| 35 |
530069608 |
Gasket - Carb. Adapter Price: $5.99 |
| 36 |
530016187 |
Screw Price: $1.99 |
| 37 |
530071310 |
Adapter - Carb. 2075 (Kit) Price: $9.99 |
| 38 |
530016386 |
Screw Price: $5.99 |
| 39 |
530069608 |
Gasket - Carburetor Price: $5.99 |
| 41 |
530057480 |
Housing- Air Filter This part replaces 530037804. Price: $4.99 |
| 42 |
530031163 |
Wrench - Bar Price: $4.99 |
