| Ref | Part Number | Description |
|---|
| 1 |
72050411 |
SUB= 872050411 Price: Call Us |
| 2 |
127423X |
SUB= 140119 Price: Call Us |
| 2 |
737-0224 |
Fitting, Lube Price: $6.56 |
| 3 |
59-8040 |
SPRING Price: $7.29 |
| 3 |
74641008 |
SUB= 71031008 Price: Call Us |
| 3 |
934-0255 |
Tubeless Air Valve This part replaces 734-0255. Price: $3.83 |
| 4 |
59-8080 |
WASHER Price: $18.05 |
| 4 |
73680500 |
SUB= 73690500 Price: Call Us |
| 4 |
777-8680 |
Label, Inflation Price: Call Us |
| 5 |
105529X |
SUB= 139888 Price: Call Us |
| 5 |
59-8170 |
WASHER Price: $8.09 |
| 5 |
941-3002 |
FRONT WHEEL BEARING ASSEMBLY Not Available This part replaces 741-3002. Price: |
| 6 |
4171R |
CLIP T Price: Call Us |
| 6 |
63-4820 |
BLOCK-DETENT Price: $275.22 |
| 6 |
931-3020 |
Hubcap This part replaces 731-3020. Price: $7.77 |
| 7 |
59-8070 |
LOCKWASHER Price: $0.49 |
| 7 |
736-0179 |
Washer, Flat, .531 x 1.25 x .100 Thk Price: $4.02 |
| 8 |
63-4830 |
CAPSCREW Price: $0.85 |
| 8 |
736-3095 |
Washer, Flat, .535 x 1.92 x .060 Thk Price: $6.01 |
| 8 |
74760612 |
SUB= 74780612 Price: Call Us |
| 9 |
126656X |
SUB= 140551 Price: Call Us |
| 9 |
59-8060 |
PLUG Price: $22.35 |
| 10 |
59-8050 |
SPRING Price: $15.65 |
| 11 |
19133210 |
WASHER Price: Call Us |
| 11 |
59-8150 |
PAWL Price: $36.37 |
| 12 |
63-4840 |
SCREW-DETENT Price: $172.21 |
| 12 |
73680600 |
SUB= 73690600 Price: Call Us |
| 13 |
59-8100 |
WASHER Price: $8.63 |
| 13 |
74780814 |
BOLT Price: Call Us |
| 14 |
10040800 |
LOCKWASHER Price: Call Us |
| 14 |
59-8180 |
WASHER Price: $33.37 |
| 15 |
19171912 |
WASHER Price: Call Us |
| 16 |
59-8190 |
WIPER Price: $10.41 |
| 17 |
121251X |
STRIP FORM Price: Call Us |
| 17 |
63-4780 |
VALVE-RELIEF Price: $485.19 |
| 18 |
123976X |
SUB= 73900400 Price: Call Us |
| 18 |
63-4850 |
PLUNGER Price: $88.33 |
| 19 |
121248X |
BUSHING Price: Call Us |
| 19 |
63-4510 |
SPRING Price: $38.85 |
| 20 |
121250X |
SPRING Price: Call Us |
| 20 |
63-4860 |
CIRCLIP Price: $28.63 |
| 21 |
121249X |
SPACER SPLIT Price: Call Us |
| 21 |
59-8230 |
PLUG Price: $47.93 |
| 22 |
121246X |
BRKT SWITCH Price: Call Us |
| 22 |
AU114313A1 |
O-RING This part replaces 59-7780. Price: $2.40 |
| 23 |
302-66 |
FITTING-GREASE Price: $5.13 |
| 24 |
59-8140 |
RING Price: $1.44 |
| 25 |
59-8160 |
PLUG Price: $18.66 |
| 26 |
59-8120 |
RING Price: $3.69 |
| 27 |
66-5420 |
SLEEVE Price: $29.51 |
| 28 |
60-4550 |
SWITCH-MICRO Price: $318.29 |
| 29 |
3256-12 |
WASHER-FLAT This part replaces 3256-13. Price: $0.99 |
| 30 |
63-4440 |
O-RING Price: $13.18 |
| 31 |
3253-19 |
WASHER-LOCK Price: $0.25 |
| 32 |
66-5430 |
SCREW Price: $10.07 |
| 33 |
66-5440 |
NUT-HEX Price: $1.07 |
| 34 |
59-7860 |
WASHER Price: $4.31 |
