| Ref | Part Number | Description |
|---|
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 1 |
727-3038 |
HOSE-STEERING CYL Not Available Price: |
| 1 |
98-7572 |
NUT Price: $0.32 |
| 2 |
532413591 |
AXLE.SVC.ASM CAST IRON.TEX This part replaces 532195968. Price: $119.99 |
| 2 |
727-3037 |
HOSE-STEERING CYL Not Available Price: |
| 2 |
98-7699 |
WASHER-SPRING This part replaces 98-9367. Price: $0.44 |
| 3 |
727-3039 |
FITTING-HYDR 90 Not Available Price: |
| 3 |
98-9363 |
STUD Price: $1.36 |
| 4 |
727-3012 |
Elbow, 90 Deg Tube Price: $23.35 |
| 4 |
98-9362 |
STUD Price: $0.66 |
| 5 |
115-4105 |
GEAR CASE ASM This part replaces 98-9481. Price: $560.23 |
| 5 |
717-3041A-0637 |
POWER STEERING CYLINDER Not Available This part replaces 717-3041. Price: |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
727-3034 |
TUBE ASSEMBLY-VALVE Not Available Price: |
| 6 |
98-9633 |
GASKET-CASE, GEAR Price: $30.19 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 7 |
98-9592 |
SCREW Price: $0.70 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
98-9541 |
COVER-PUMP, OIL Price: $222.71 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 9 |
98-9540 |
OIL PUMP ROTOR ASM Price: $271.67 |
| 10 |
98-9372 |
O-RING Price: $1.66 |
| 11 |
98-7547 |
O-RING Price: $0.92 |
| 12 |
98-9544 |
SPRING Price: $0.94 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 13 |
98-9380 |
BALL Price: $0.84 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 14 |
98-9543 |
SEAT-VALVE Price: $26.61 |
| 15 |
108-3841 |
FILTER-OIL This part replaces 99-8384. Price: $10.81 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 16 |
98-9388 |
JOINT-PIPE Price: $31.66 |
| 17 |
98-7562 |
WASHER-PLAIN Price: $0.36 |
| 18 |
127-0425 |
PLUG This part replaces 98-9598. Price: $4.34 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 19 |
98-9356 |
BOLT Price: $2.06 |
| 20 |
105-3797 |
BOLT This part replaces 98-9355. Price: $1.40 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 21 |
99-3510 |
BOLT This part replaces 98-9586. Price: $0.80 |
| 22 |
119-8038 |
SEAL-OIL This part replaces 98-9482. Price: $40.16 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029802. Price: $14.99 |
| 23 |
98-9437 |
BOLT Price: $1.05 |
| 24 |
100-1765 |
BOLT This part replaces 98-7496. Price: $1.59 |
| 25 |
98-9684 |
GASKET-CASE, GEAR Price: $2.18 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 26 |
99-3515 |
PLUG-GEARCASE This part replaces 98-9641. Price: $9.00 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683701. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
