| Ref | Part Number | Description |
|---|
| 2 |
532069180 |
Nut, Crown lock #10-24 Price: $2.69 |
| 3 |
532127533 |
Screen, Cover Price: $11.99 |
| 5 |
532139569 |
Chute, Upper Price: $70.99 |
| 6 |
818021008 |
Screw, Special Price: $3.99 |
| 7 |
532140572 |
Dump Bag Indicator Price: $4.99 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $5.99 |
| 9 |
819061216 |
Washer 3/16x3/4x16 Ga. Price: $2.69 |
| 10 |
532007206 |
Spacer, Split Price: $3.99 |
| 11 |
539108086 |
NUT.#10-24 ACORN.ZD This part replaces 532060867. Price: $1.99 |
| 12 |
810071000 |
Washer, lock Price: $2.99 |
| 13 |
532109808 |
Latch, Chute Price: $2.69 |
| 14 |
532002029 |
NUT.WELD.#10-24 This part replaces 532125004. Price: $2.69 |
| 15 |
874930620 |
Bolt, Hex Head 3/8-16 x 1-1/4 Price: $3.99 |
| 16 |
105-9339 |
CRANKSHAFT This part replaces 99-9252. Price: $2,387.77 |
| 16 |
819131612 |
Washer 13/32 x 1 x 12 Ga. This part replaces 819131616. Price: $3.99 |
| 17 |
873680600 |
Nut This part replaces 873930600. Price: $1.99 |
| 18 |
532131970 |
Chute, Lower Price: $72.99 |
| 19 |
532135651 |
Wingnut 3/8-16 Price: $3.99 |
| 20 |
871081010 |
Screw #10-24 x 5/8 Price: $3.49 |
| 21 |
532132796 |
Spring, Cover L.H.(black) Price: $2.99 |
| 22 |
532133235 |
Spacer, Cover Price: $3.99 |
| 23 |
532132983 |
Spring, Cover R.H. (gray) Price: $2.99 |
| 23 |
99-9267 |
FLYWHEEL Price: $506.35 |
| 24 |
532180923 |
Support Assembly Price: $52.99 |
| 25 |
539976978 |
NUT.1/4C.NYLOC This part replaces 873800400. Price: $1.49 |
| 25 |
99-9268 |
PISTON ASM (.010 IN OVERSIZED) Price: $226.79 |
| 25 |
99-9605 |
PISTON ASM Price: $311.37 |
| 26 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 26 |
99-9269 |
RING SET (.010 OVERSIZED) Price: $234.03 |
| 26 |
99-9606 |
RING SET Price: $151.69 |
| 27 |
872140405 |
Bolt Price: $3.99 |
| 27 |
99-9607 |
LOCK-PIN, PISTON Price: $11.66 |
| 28 |
532179745 |
Bracket, Stop Price: $3.99 |
| 29 |
532170165 |
Shoulder Bolt Price: $2.99 |
| 29 |
99-9608 |
SEE PARTS BULLETIN #949 Price: Call Us |
| 31 |
532174083 |
Plug, Tubing End Price: $3.99 |
| 32 |
532179746 |
Bagger, Frame Price: $82.99 |
| 32 |
99-9030 |
SCREW Price: $18.05 |
| 33 |
532192786 |
Pin, Hinge This part replaces 532128600. Price: $7.99 |
| 34 |
532127534 |
Gasket, Cover Price: $8.99 |
| 35 |
532183286 |
Container, Top This part replaces 532129585. Price: $17.99 |
| 36 |
532183286 |
Container, Bottom Price: $17.99 |
| 38 |
532130895 |
Latch Handle, Cover Price: $3.99 |
| 39 |
532155042 |
Strip, Reinforcement Price: $11.99 |
| 44B |
99-9031 |
SCREW-HEX Price: $21.08 |
| 49 |
99-9032 |
SCREW-HEX Price: $10.37 |
| 62 |
99-9033 |
SCREW-HEX Price: $14.61 |
| 154 |
99-9034 |
NUT-HEX Price: $9.31 |
| 220 |
99-9035 |
SHIM-ENDPLAY Price: $90.46 |
| 220 |
99-9036 |
SHIM-ENDPLAY (.005 OVERSIZED) Price: $133.55 |
| 718C |
99-9037 |
PIN-LOCATING Price: $16.64 |
| 743 |
99-9609 |
GEAR-DRIVE Price: $304.63 |
| 900 |
99-9039 |
SHAFT-GEAR Price: $139.50 |
| 1073 |
99-9040 |
PLATE-GEAR, IDLER Price: $18.03 |
| 1075 |
99-9041 |
PULLEY-CRANKSHAFT This part replaces 99-9692. Price: $162.61 |
| 1076 |
117-4893 |
ROD BEARING SET (STD) This part replaces 99-9042. Price: $91.06 |
| 1076A |
117-4893 |
ROD BEARING SET (STD) This part replaces 99-9043. Price: $91.06 |
| 1079 |
99-9045 |
MAIN BEARING SET (SET OF 8) Price: $123.13 |
| 1079 |
99-9046 |
MAIN BEARING SET (.010 UNDERSIZED) Price: $146.62 |
