| Ref | Part Number | Description |
|---|
| 1 |
105-8452 |
DECK-RAKE AND FINGER ASM Price: $2,676.22 |
| 2 |
3231-28 |
SCREW-CARR Price: $1.92 |
| 3 |
BD733-00 |
BEARING-FLANGE Price: $141.86 |
| 4 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 5 |
SV165-00-03 |
PINCHER-BELT, MIDDLE Price: $29.89 |
| 6 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 7 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 8 |
SV159-00-03 |
PINCHER-BELT, END Price: $19.87 |
| 9 |
SV166-00 |
FINGER-BELT Price: $9.69 |
| 10 |
SV161-00-03 |
ROTOR-FINGER, RUBBER Price: $1,036.15 |
| 11 |
RS205-00-01 |
GUARD-BEARING, SHAFT Price: $61.85 |
| 12 |
RS250-00 |
BEARING-FLANGE Price: $201.67 |
| 13 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 16 |
325-6 |
SCREW-HH Price: $1.42 |
| 18 |
106-0124-01 |
LH GUARD ASM Price: $138.00 |
| 19 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 20 |
106-0326 |
BEARING-FLANGE Price: $79.71 |
| 22 |
RS206-00-01 |
GUARD-BEARING, ROTOR SHAFT Price: $47.82 |
| 23 |
106-0224 |
ROTOR-FLAIL, VERTICAL CUT Price: $3,580.89 |
| 24 |
RS322-00-01 |
ROLLER-SCALP, ANTI Price: $322.28 |
| 25 |
RS224-00-01 |
SHIELD-FRONT Price: $144.32 |
| 26 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 27 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 28 |
RS224-01 |
SKIRT-SHIELD, FRONT Price: $168.12 |
| 29 |
105-8460 |
SCREW-STD Price: $1.83 |
| 30 |
3233-26 |
SCREW-CARR, SHORT NECK Price: $2.21 |
| 31 |
322-3 |
SCREW-HH Price: $0.79 |
| 32 |
106-0125-01 |
RH GUARD ASM Price: $138.00 |
