| Ref | Part Number | Description |
|---|
| 1 |
127-3189 |
GASKET KIT Price: $835.82 |
| 1 |
532170803 |
CONTROL, THROTTLE Price: $24.99 |
| 2 |
127-3126 |
GASKET-HEAD, CYLINDER Price: $178.72 |
| 2 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 3 |
127-3106 |
GASKET-COVER Price: $49.95 |
| 4 |
127-2986 |
SEAL-STEM, VALVE Price: $6.38 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
127-3027 |
SEAL-STEM, VALVE Price: $6.79 |
| 5 |
532176067 |
EXHAUST.TUBE.LH.KAWASAKI. Price: $99.99 |
| 6 |
127-3021 |
GASKET-INJECTOR Price: $4.54 |
| 6 |
532176068 |
EXHAUST.TUBE.RH.KAWASAKI. Price: $99.99 |
| 7 |
127-3107 |
GASKET-MANIFOLD, INTAKE Price: $21.63 |
| 8 |
127-3032 |
O RING-SENSOR, PRESSURE Price: $18.19 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
127-3033 |
O-RING Price: $13.39 |
| 10 |
127-3034 |
GASKET-COLLECTOR Price: $9.66 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 11 |
127-3037 |
GASKET-THROTTLE Price: $2.87 |
| 12 |
127-3108 |
GASKET-MANIFOLD, EXHAUST Price: $14.96 |
| 13 |
121-3058 |
GASKET-EXHAUST This part replaces 127-3019. Price: $19.54 |
| 14 |
127-2987 |
GASKET-SILENCER Price: $13.97 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
127-3043 |
GASKET-COOLER, E G R Price: $3.64 |
| 16 |
127-3046 |
GASKET-E G R Price: $4.88 |
| 17 |
127-3016 |
GASKET Price: $3.83 |
| 18 |
127-3050 |
GASKET-INTAKE VALVE, E G R Price: $5.09 |
| 19 |
127-3051 |
GASKET-OUT VALVE, E G R Price: $4.47 |
| 20 |
127-3162 |
GASKET-D P F Price: $19.60 |
| 21 |
127-3056 |
GASKET-SENSOR Price: $2.23 |
| 22 |
125-7070 |
GASKET Price: $4.75 |
| 23 |
125-7071 |
GASKET Price: $7.59 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
127-3069 |
GASKET-IDLE, SHAFT B Price: $4.14 |
| 25 |
127-3004 |
GASKET Price: $2.73 |
| 25 |
532187768 |
CONTROL.CHOKE.ERGO.BLACK This part replaces 532189541. Price: $27.99 |
| 26 |
125-6909 |
O-RING Price: $2.55 |
| 27 |
127-2973 |
O-RING Price: $3.16 |
| 28 |
125-7022 |
GASKET Price: $7.07 |
| 29 |
125-7024 |
GASKET Price: $3.16 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
125-7047 |
GASKET Price: $5.13 |
| 31 |
125-7048 |
O-RING Price: $2.87 |
| 31 |
581289901 |
FUEL.TANK.ASM.NON-EPA This part replaces 532185534. Price: $44.99 |
| 32 |
125-6979 |
GASKET Price: $2.55 |
| 32 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532197725. Price: $22.99 |
| 33 |
125-7110 |
GASKET Price: $3.76 |
| 34 |
125-7026 |
GASKET Price: $2.90 |
| 35 |
125-6978 |
GASKET Price: $2.00 |
| 36 |
127-3074 |
O-RING Price: $29.78 |
| 37 |
125-7174 |
WASHER-SEAL Price: $5.45 |
| 37 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 38 |
125-7175 |
WASHER-SEAL Price: $6.16 |
| 39 |
125-7176 |
WASHER-SEAL Price: $7.31 |
| 40 |
127-3166 |
WASHER-SEAL Price: $6.77 |
| 41 |
125-7177 |
WASHER-SEAL Price: $6.86 |
| 42 |
125-7192 |
GASKET Price: $1.14 |
| 43 |
125-7193 |
GASKET Price: $1.28 |
| 44 |
127-3174 |
GASKET Price: $1.28 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 45 |
93-0418 |
O-RING Price: $7.29 |
| 46 |
125-7197 |
O-RING Price: $2.55 |
| 46 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 47 |
125-7198 |
O-RING Price: $7.26 |
| 48 |
127-3176 |
O-RING Price: $2.87 |
| 49 |
127-3000 |
HONE Price: $654.34 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 101 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 105 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
