| Ref | Part Number | Description |
|---|
| 1 |
67-3770 |
DISCONTINUED Price: Call Us |
| 2 |
532123583 |
SQUARE KEY Price: $3.99 |
| 2 |
67-3760 |
LOCK PLATE Price: $21.29 |
| 3 |
67-3740 |
NIPPLE Price: $62.56 |
| 4 |
67-3480 |
O-RING Price: $2.47 |
| 5 |
67-3490 |
SPRING Price: $5.86 |
| 6 |
93-3465 |
GASKET-DELIVERY V. This part replaces 42-8240. Price: $8.09 |
| 7 |
67-3500 |
SUB-ASSEMBLY VALVE Price: $99.95 |
| 8 |
75-4970 |
ELEMENT - SUB-ASSY Price: $224.06 |
| 9 |
67-3460 |
SUB-ASM PUMP HOUSING Price: $618.09 |
| 10 |
67-3520 |
SUB-ASSEMBLY SLEEVE Price: $47.39 |
| 11 |
67-3530 |
SEAT Price: $4.36 |
| 12 |
67-3540 |
SPRING Price: $12.47 |
| 13 |
67-3550 |
DISCONTINUED Price: Call Us |
| 15 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 15 |
67-3700 |
DISCONTINUED Price: Call Us |
| 16 |
67-3810 |
PIN Price: $4.69 |
| 17 |
532413678 |
SPRING.BRAKE.K46.GREEN Price: $6.99 |
| 17 |
67-3790 |
DISCONTINUED Price: Call Us |
| 18 |
67-3800 |
BRACKET Price: $27.34 |
| 19 |
67-3780 |
RACK ASSEMBLY Price: $154.27 |
| 20 |
70-3910 |
WASHER This part replaces 67-3750. Price: $3.15 |
| 21 |
67-3740 |
NIPPLE Price: $62.56 |
| 22 |
67-3730 |
DISCONTINUED Price: Call Us |
| 23 |
67-3720 |
DISCONTINUED Price: Call Us |
| 24 |
67-3710 |
AIR BLEED SCREW Price: $6.38 |
| 25 |
67-3970 |
NUT Price: $28.82 |
| 26 |
532199679 |
SPRING.RETURN.CRUISE Price: $3.99 |
| 26 |
67-3980 |
GASKET Price: $3.19 |
| 27 |
67-3960 |
NOZZLE ASSEMBLY Price: $167.76 |
| 28 |
67-3950 |
PIECE Price: $19.92 |
| 29 |
532403806 |
ROD.BRAKE.K46 Price: $17.99 |
| 29 |
93-3502 |
PIN-PRESSURE This part replaces 67-3940. Price: $3.22 |
| 30 |
67-3930 |
SPRING Price: $12.66 |
| 31 |
93-3491 |
WASHER-T=1.25 This part replaces 67-3830. Price: $8.80 |
| 32 |
75-5000 |
BODY SUB-ASSY Price: $147.67 |
| 33 |
812000001 |
E-RING LT Price: $3.99 |
| 35 |
583864502 |
Rods This part replaces 532199591. Price: $6.99 |
| 42 |
510089501 |
PAD, FOOT PEDAL This part replaces 532124872. Price: $4.99 |
| 49 |
596136201 |
Bolts This part replaces 872110614. Price: $3.99 |
| 50 |
532194327 |
IDLER.FLAT.910.OFFSET Price: $17.99 |
| 51 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 52 |
532194326 |
IDLER.V-GROOVE.910.OFFSET Price: $19.99 |
| 56 |
592855201 |
Belts This part replaces 532130969. Price: $27.99 |
| 64 |
532197865 |
SHAFT.ASM.PEDAL.BRK.CNTR Price: $44.99 |
| 73 |
595316601 |
Bolts This part replaces 874490544. Price: $3.99 |
| 80 |
531064101 |
SERVICE KIT TORQUE STRAP BLACK This part replaces 532410024. Price: $19.99 |
| 92 |
595305701 |
Screws This part replaces 874760520. Price: $3.99 |
| 99 |
532415742 |
ROD.SPRING.BYPASS.K46.LT.Z Price: $7.99 |
| 116 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 125 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 143 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 153 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 159 |
596029501 |
Pins This part replaces 876020412. Price: $2.99 |
| 160 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 161 |
532105709 |
SPRING, RETURN LT Price: $9.99 |
| 163 |
593861001 |
Rods This part replaces 532401034. Price: $22.99 |
| 166 |
532429164 |
NUT.PUSH.625 Price: $4.99 |
| 167 |
531152901 |
SERVICE KIT LATCH LATCH.BRAKE. This part replaces 532405257. Price: $2.99 |
| 170 |
532194322 |
KEEPER.V-IDLER.CENTER. Price: $5.99 |
| 171 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 183 |
532137057 |
SPACER AXLE Price: $5.99 |
| 184 |
532196439 |
HANDLE.PARKING.BRAKE.H (BLK) This part replaces 532403118. Price: $9.99 |
| 185 |
872110622 |
BOLT Price: $3.99 |
| 186 |
532194321 |
SPACER.RETAINER Price: $7.99 |
| 187 |
596135501 |
Washers This part replaces 819133210. Price: $4.99 |
| 188 |
582217001 |
LINK.CLUTCH.GROUND DRIVE.LONG This part replaces 532194323. Price: $4.99 |
| 189 |
531169001 |
SERVICE KIT BELLCRANK This part replaces 532194317. Price: $6.99 |
| 190 |
532194318 |
KEEPER.BELLCRANK.DRIVE Price: $5.99 |
| 196 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 197 |
532195804 |
LINK.CLUTCH.ANIT-ROTAT Price: $5.99 |
| 205 |
532121748 |
WASHER Price: $3.99 |
| 206 |
532448596 |
BRACKET.MOUNT.CRUISE.LATCH This part replaces 532197867. Price: $4.99 |
| 207 |
587031402 |
Latch This part replaces 532197868. Price: $5.99 |
| 208 |
596564101 |
Gears This part replaces 532197869. Price: $4.99 |
| 209 |
596869801 |
Rods This part replaces 532199592. Price: $5.99 |
| 210 |
532400980 |
ROCKER.ASM.PEDAL.CONTR Price: $32.99 |
| 211 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 213 |
532403119 |
KNOB.CONTROL.CRUSIE.HU Price: $8.99 |
| 214 |
532416863 |
PEDAL.FORWARD.HUSQVARNA.DEALER Price: $32.99 |
| 215 |
532401723 |
PEDAL.REVERSE.TEX.GT.4 Price: $12.99 |
| 216 |
532196131 |
BRACKET.PULLEY.IDLER.W/TEX Price: $6.99 |
| 221 |
532403187 |
RETAINER.SPRING.CLIP.H Price: $3.99 |
| 222 |
879212010 |
WASHER 21/32 X 1-1/4 X 10 GA. Price: $3.99 |
| 225 |
531149001 |
SERVICE KIT KEEPER BELT KEEPER This part replaces 532403319. Price: $5.99 |
| 226 |
531170501 |
SERVICE KIT BRACKET This part replaces 532401564. Price: $4.99 |
| 230 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 284 |
532417693 |
NUT.U-CHNL.1/4-20.550DP.350PNL Price: $3.99 |
