| Ref | Part Number | Description |
|---|
| 1 |
98-2354-03 |
LATCH-SEAT Price: $41.34 |
| 2 |
737-0224 |
Fitting, Lube Price: $6.56 |
| 2 |
98-2353 |
BRACKET-LATCH, SEAT Price: $17.71 |
| 3 |
32128-25 |
NUT-HF Price: $3.19 |
| 3 |
934-0255 |
Tubeless Air Valve This part replaces 734-0255. Price: $3.83 |
| 4 |
777-8680 |
Label, Inflation Price: Call Us |
| 4 |
98-9342 |
DECAL-SOLENOID, INFORMATION Price: $69.36 |
| 5 |
941-3002 |
FRONT WHEEL BEARING ASSEMBLY Not Available This part replaces 741-3002. Price: |
| 5 |
98-9302 |
PLATE-STOP, IDLER Price: $12.42 |
| 6 |
66-4190-03 |
SPRING-IDLER, CLUTCH Price: $7.20 |
| 6 |
931-3020 |
Hubcap This part replaces 731-3020. Price: $7.77 |
| 7 |
736-0179 |
Washer, Flat, .531 X 1.25 X .100 Thk Price: $4.02 |
| 7 |
92-5524 |
DISCONTINUED Price: Call Us |
| 8 |
63-9920 |
DISCONTINUED Price: Call Us |
| 8 |
736-3095 |
Washer, Flat, .535 X 1.92 X .060 Thk Price: $6.01 |
| 9 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 10 |
25-8640 |
SCREW-HH Price: $1.09 |
| 11 |
3296-3 |
NUT-LOCK Price: $0.54 |
| 12 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
| 14 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 15 |
322-3 |
SCREW-HH Price: $0.79 |
| 16 |
75-3400 |
SHAFT-PIVOT, SEAT Price: $21.81 |
| 17 |
110-4149 |
KIT-SEAT PLATE This part replaces 98-2350-03. Price: $166.30 |
| 18 |
93-8060 |
DECAL-REELS Price: $53.80 |
| 19 |
2412-93 |
CLAMP-R Price: $1.02 |
| 20 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 21 |
98-9303 |
CABLE-THROTTLE Price: $21.41 |
| 22 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 24 |
98-2352-03 |
FRAME-SEAT Price: $456.00 |
| 25 |
32121-38 |
PIN-ROLL Price: $0.53 |
| 26 |
93-0021 |
SWIVEL-CABLE, THROTTLE Price: $33.15 |
| 27 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 28 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
321-4 |
SCREW-HH Price: $0.99 |
| 30 |
66-2920 |
WASHER-FRICTION Price: $2.58 |
| 31 |
75-3680-03 |
ROD-SEAT Price: $38.90 |
| 32 |
75-3430-03 |
LEVER-THROTTLE Price: $29.18 |
