| Ref | Part Number | Description |
|---|
| 1 |
147-0901 |
ARM-PITCH This part replaces 119-9307-01. Price: $179.09 |
| 2 |
117-9456 |
CROSSLINK Price: $54.18 |
| 2 |
532445962 |
MUFFLER.ASM.TWN.EXTNDED.DFLCTR Price: $54.99 |
| 3 |
119-4012 |
SCREW-HWHTF Price: $0.61 |
| 4 |
120-3221 |
LH REEL NUT ASM Price: $33.34 |
| 5 |
115-3340 |
WEIGHT ASM Price: $136.76 |
| 6 |
115-5227 |
MOTOR ADAPTER ASM Price: $98.96 |
| 7 |
117-6706 |
CLAMP-MOTOR Price: $34.81 |
| 8 |
120-9738 |
SCREW-HH This part replaces 322-11. Price: $0.84 |
| 9 |
117-6849 |
SHIELD-SPRING Price: $48.38 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 This part replaces 584911602. Price: $7.99 |
| 10 |
3274-18 |
SCREW-HSH Price: $8.88 |
| 11 |
119-4038 |
NUT-HEX Price: $0.31 |
| 11 |
587241601 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH07 Price: $199.99 |
| 12 |
532402980 |
PULLEY.ENGINE.ENX Price: $54.99 |
| 15 |
532433007 |
TANK.ASM.FRT.2.5 GAL.W/CAP.EPA Price: $119.99 |
| 18 |
581176101 |
CAP.FUEL.2 WAY VENT Price: $34.99 |
| 20 |
532423502 |
CONTROL.TH/CK.COBRA.B&S.TWN. Price: $19.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 28 |
532401137 |
LINE.FUEL.20"FRONT.EMI Price: $9.99 |
| 29 |
532131780 |
Kit Spark Arrestor 1 25 Price: Call Us |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
532159955 |
RP.EXHAUST.TUBE.LH.BS/TWIN This part replaces 581881101. Price: $27.99 |
| 71 |
532160589 |
RP.EXHAUST.TUBE.RH.BS/TWIN This part replaces 581881001. Price: $39.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 96 |
819091416 |
WASHER Price: $3.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $2.99 |
