| Ref | Part Number | Description |
|---|
| 1 |
112-1403 |
ADAPTER ASM Price: $437.59 |
| 2 |
130-7823 |
ARM-LIFT Price: $286.60 |
| 3 |
110-3362 |
BAR-PIVOT Price: $71.83 |
| 4 |
3272-17 |
PIN-COTTER Price: $1.79 |
| 5 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 6 |
112-7686 |
LATCH Price: $40.54 |
| 7 |
112-7695-03 |
HANDLE Price: $53.91 |
| 8 |
114-4320 |
ROD-HANDLE Price: $9.07 |
| 9 |
99-7984 |
KNOB-SOFT GRIP, PUSH-ON Price: $11.31 |
| 10 |
75-5270 |
SPACER-KNOB, SEAT This part replaces 99-2058. Price: $4.61 |
| 11 |
92-2651 |
WASHER Price: $1.83 |
| 12 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 13 |
144-7093 |
LINK ASM This part replaces 110-8105. Price: $105.96 |
| 14 |
323-12 |
SCREW-HH Price: $1.14 |
| 15 |
323-10 |
SCREW-HH Price: $0.89 |
| 16 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 17 |
120-3499-03 |
BRACKET-STOP Price: $23.48 |
| 18 |
325-22 |
SCREW-HH Price: $4.26 |
| 19 |
121-9065-03 |
HITCH ASM Price: $39.94 |
| 20 |
47-2910 |
WASHER-THRUST Price: $12.99 |
| 21 |
121-9062-03 |
TUBE-TONGUE Price: $85.05 |
| 22 |
92-2739 |
PIN-CLEVIS Price: $8.48 |
| 23 |
325-7 |
SCREW-HH Price: $1.53 |
| 24 |
112-0038 |
SPACER Price: $7.34 |
| 25 |
115-2090 |
PAD-WEAR Price: $43.56 |
| 26 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 27 |
66-9300 |
SCREW-HHF Price: $4.69 |
| 28 |
3233-14 |
SCREW-CARR Price: $1.95 |
| 29 |
3218-5 |
NUT-JAM Price: $0.27 |
| 30 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 31 |
110-6894 |
WASHER-PIVOT Price: $0.59 |
| 32 |
100-5024 |
PIN-CLEVIS Price: $7.44 |
| 33 |
119-8969 |
NUT-HEX Price: $1.29 |
| 34 |
130-7839-03 |
BRACKET-ADAPTER Price: $47.41 |
| 35 |
127-7864-03 |
BRACKET-CENTER GROOMER, RH Price: $39.90 |
| 36 |
127-7865-03 |
BRACKET-CENTER GROOMER, LH Price: $39.90 |
| 37 |
130-7838-03 |
TUBE-LIFT Price: $108.01 |
| 38 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 39 |
323-14 |
SCREW-HH Price: $1.34 |
| 40 |
125-2446 |
SHACKLE Price: $31.96 |
| 41 |
110-3469 |
PLUG-HEAD, BALL Price: $3.17 |
| 42 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 43 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 44 |
130-7840 |
CHAIN-LIFT Price: $16.26 |
| 45 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 46 |
32128-49 |
NUT-HHF Price: $1.04 |
| 47 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
