| Ref | Part Number | Description |
|---|
| 1 |
3219-1 |
NUT-HEX Price: $0.47 |
| 1 |
530015880 |
Screw Price: $1.99 |
| 2 |
530058982 |
Bolt-Muffler Price: $1.99 |
| 2 |
70-2160 |
BRACKET-STOP, SPEED Price: $65.93 |
| 3 |
72-5920 |
SCREW Price: $6.96 |
| 4 |
530015953 |
Screw-Cylinder Price: $1.99 |
| 4 |
67-8370 |
HUB-FAN Price: $108.86 |
| 5 |
18-5620 |
SCREW-COVER TO BODY Price: $8.96 |
| 5 |
952030249 |
Spark Plug (RCJ 6Y) Price: Call Us |
| 6 |
18-5630 |
LOCKWASHER Price: $7.56 |
| 6 |
530012541 |
Cylinder Price: $11.99 |
| 7 |
18-5580 |
DISCONTINUED Price: Call Us |
| 7 |
530071750 |
Seal-Cylinder (kit) Price: $8.99 |
| 8 |
104-2524 |
COVER Price: $268.04 |
| 8 |
545154001 |
RING PISTON This part replaces 530055120. Price: $1.99 |
| 9 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 9 |
530015162 |
Retainer-Piston Pin Price: $1.99 |
| 10 |
18-5640 |
DISCONTINUED Price: Call Us |
| 11 |
18-5790 |
DISCONTINUED Price: Call Us |
| 11 |
530057829 |
Assy-Crankshaft Price: $12.99 |
| 12 |
70-2140 |
DISCONTINUED Price: Call Us |
| 13 |
530071750 |
Seal-Cyl/Carb.(kit) Price: $8.99 |
| 14 |
18-5770 |
LOCKWASHER-BEARING/COVER Price: $1.33 |
| 14 |
530057547 |
Adapter-Carb. Price: $7.99 |
| 15 |
530016309 |
Screw Price: $1.99 |
| 15 |
70-2150 |
FLYWEIGHT Price: $61.78 |
| 16 |
32113-14 |
SCREW Price: $4.08 |
| 16 |
530071750 |
Gasket-Carb. (kit) Price: $8.99 |
| 17 |
70-2110 |
DISCONTINUED Price: Call Us |
| 18 |
530057585 |
Air Box Price: $7.99 |
| 18 |
70-2100 |
DISCONTINUED Price: Call Us |
| 19 |
18-5540 |
RETAINER-STOP, SLEEVE Price: $18.31 |
| 19 |
530016429 |
Screw Price: $1.99 |
| 20 |
530057781 |
Foam-Air Filter Price: $1.99 |
| 20 |
72-5940 |
BEARING-NEEDLE Price: $61.68 |
| 21 |
530057584 |
Cover-Air Box Price: $4.99 |
| 21 |
70-2070 |
LEVER-ADJUSTING, SPEED Price: $46.09 |
| 22 |
530039223 |
Ignition Module Price: $16.17 |
| 22 |
70-2090 |
STUD-PIVOT, LEVER Price: $14.07 |
| 23 |
3296-5 |
NUT-HEX Price: $3.09 |
| 23 |
530038604 |
Coupling-Drive Price: $1.99 |
| 24 |
530016357 |
Screw Price: $1.99 |
| 24 |
72-5860 |
SPRING-GOVERNOR Price: $69.31 |
| 25 |
530014663 |
Assy-Leadwire Price: $5.99 |
| 25 |
72-5850 |
PIN-FORCE, IDLE Price: $5.43 |
| 26 |
530014662 |
Assy-Ground Wire Price: $4.99 |
| 26 |
72-5930 |
SCREW Price: $3.38 |
| 27 |
530016392 |
Screw Price: $1.99 |
| 27 |
71-4780 |
DISCONTINUED Price: Call Us |
| 28 |
18-5750 |
PIN-SHAFT, LEVER Price: $1.53 |
| 28 |
530058600 |
Assy.-Fan Hsg Price: $14.99 |
| 29 |
3219-2 |
NUT-HEX Price: $0.37 |
| 29 |
530071356 |
Kit-Switch Price: $4.99 |
| 30 |
530027569 |
Handle-Starter Price: $1.99 |
| 30 |
72-5890 |
SHAFT-ROCKER Price: $67.37 |
| 31 |
18-5410 |
TORSION SPRING Price: $9.36 |
| 31 |
530071767 |
Kit - Rope Price: $3.99 |
| 32 |
530016386 |
Screw This part replaces 530015810. Price: $5.99 |
| 32 |
72-5880 |
THROTTLE LEVER ASM Price: $78.58 |
| 33 |
530016124 |
Nut Price: $1.99 |
| 33 |
72-5870 |
EYEBOLT Price: $42.76 |
| 34 |
530057588 |
Clip-Spring Price: $1.99 |
| 34 |
72-5910 |
BUMPER SCREW ASM Price: $49.84 |
| 35 |
18-5450 |
DISCONTINUED Price: Call Us |
| 35 |
530016430 |
Screw Price: $2.99 |
| 36 |
545008010 |
STARTER SPRING This part replaces 530042085. Price: $3.99 |
| 36 |
70-2080 |
BODY Price: $400.66 |
| 37 |
18-5520 |
DISCONTINUED Price: Call Us |
| 37 |
530071786 |
Kit-Pulley-Starter Price: $3.99 |
| 38 |
121-6270 |
SPACER-PLUG, EXPANSION This part replaces 18-5440. Price: $28.84 |
| 38 |
530027523 |
Retainer-Pulley Price: $2.99 |
| 39 |
18-5430 |
PLUG-EXPANSION Price: $7.96 |
| 39 |
530015775 |
Screw Price: $1.99 |
| 40 |
18-5530 |
SCREW-LEVER TO SHAFT Price: $2.11 |
| 40 |
530015828 |
Washer-Flat Price: $1.99 |
| 41 |
18-5670 |
RETAINER-PIN, PIVOT Price: $7.98 |
| 41 |
530054115 |
Assy-Flywheel Price: $27.99 |
| 42 |
18-5660 |
PIN-PIVOT, FLYWEIGHT Price: $31.58 |
| 43 |
530015941 |
Retain. Ring-C’shaft Price: $1.99 |
| 43 |
70-2120 |
DISCONTINUED Price: Call Us |
| 44 |
32121-51 |
PIN-ROLL Price: $0.70 |
| 44 |
530055728 |
Outer Bearing Price: $6.99 |
| 45 |
530019264 |
Seal-C’case Price: $2.99 |
| 46 |
738210101 |
BEARING BALL 6001 This part replaces 530032125. Price: $8.99 |
| 47 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 48 |
530071750 |
O-Ring-C’case (kit) Price: $8.99 |
| 50 |
530016386 |
Screw Price: $5.99 |
| 51 |
530057580 |
Shroud-Rear Price: $7.99 |
| 52 |
530016431 |
Retainer-Tank Price: $3.99 |
| 54 |
530014347 |
Assy-Fuel Cap Price: $4.49 |
| 55 |
530069247 |
Kit-Fuel Line (Small) Price: $3.69 |
| 56 |
530069216 |
Kit-Fuel Line (Large) Price: $3.99 |
| 57 |
530095646 |
Assy-Fuel Pickup Price: $2.69 |
