| Ref | Part Number | Description |
|---|
| 1 |
136-5887-03 |
PLATE-HOC, RWD (LH) Price: $16.24 |
| 2 |
136-5888-03 |
PLATE-HOC, RWD (RH) Price: $16.24 |
| 3 |
322-3 |
SCREW-HH Price: $0.79 |
| 4 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 5 |
108-9779 |
RETAINER-BUSHING, HOC Price: $9.09 |
| 6 |
104-8699 |
BEARING-BALL Price: $3.28 |
| 7 |
108-9782 |
BUSHING-SLEEVE Price: $2.32 |
| 8 |
136-9090 |
ARM-PIVOT, REAR This part replaces 132-4459. Price: $8.02 |
| 9 |
132-4486 |
ARM-SPRING Price: $9.32 |
| 10 |
110-0549 |
KNOB-HOC Price: $1.08 |
| 11 |
137-4825 |
TRANSMISSION-RWD (6:1) This part replaces 131-9696. Price: $75.32 |
| 12 |
91-2258 |
BELT-V Price: $17.50 |
| 13 |
132-4481-01 |
BRACKET-TRANSMISSION Price: $9.32 |
| 14 |
108-7476 |
SCREW-PLASTITE Price: $0.61 |
| 15 |
110-7191 |
WASHER-THRUST Price: $1.79 |
| 16 |
131-5399 |
GEAR-PINION, 15T Price: $2.67 |
| 17 |
32151-61 |
RING-RETAINING Price: $2.39 |
| 18 |
136-9059 |
GEAR COVER ASM This part replaces 132-4480. Price: $3.79 |
| 19 |
614650 |
BOLT-SHOULDER Price: $3.28 |
| 20 |
137-4843 |
WHEEL GEAR ASM (11IN) This part replaces 132-4458. Price: $39.96 |
| 23 |
139-6604 |
SHIELD-TRAILING This part replaces 120-7012. Price: $11.18 |
| 24 |
139-1692 |
SCREW-THD This part replaces 117-1092. Price: $0.32 |
| 25 |
3229-11 |
SCREW-CARR Price: $0.99 |
