| Ref | Part Number | Description |
|---|
| 1 |
588556701 |
SEAT.TH154.498GY.HUS.ARMRESTS This part replaces 532443263. Price: $279.99 |
| 1 |
95-0564 |
TUBE-RH, FRONT Price: $46.46 |
| 2 |
532180166 |
BRKT.PIVOT.FENDER Price: $11.99 |
| 2 |
95-0559 |
TUBE-RH, REAR Price: $46.46 |
| 3 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 3 |
532140675 |
STRAP Price: $5.99 |
| 4 |
22-4670 |
HOSE-VALVE/CYLINDER Price: $128.58 |
| 5 |
354-132 |
FITTING Price: $15.08 |
| 6 |
3272-23 |
PIN-COTTER Price: $0.28 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 7 |
83-7000 |
HYD CYLINDER ASM Price: $363.59 |
| 8 |
18-7310 |
PIN-CYLINDER Price: $32.29 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
95-0560 |
TUBE-LH, FRONT Price: $109.53 |
| 10 |
596768801 |
KIT.PLATE.SEAT This part replaces 532196977. Price: $49.99 |
| 10 |
95-0567 |
TUBE-LH, REAR Price: $109.53 |
| 11 |
353-426 |
FITTING-90 DEG Price: $29.88 |
| 12 |
75-9831 |
HYD MOTOR ASM Price: $1,646.04 |
| 13 |
18-7160 |
PIN-CYLINDER Price: $52.01 |
| 14 |
353-431 |
FITTING-45 DEG Price: $74.99 |
| 15 |
353-212 |
FITTING-ELBOW, 45 DEG Price: $22.12 |
| 16 |
75-9840 |
HYD MOTOR ASM Price: $2,000.57 |
| 17 |
95-0575 |
TUBE-VALVE, SHUTTLE Price: $45.57 |
| 19 |
325-5 |
SCREW-HH Price: $1.20 |
| 20 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 21 |
69-8930 |
WASHER Price: $0.81 |
| 22 |
69-8960 |
SPACER Price: $5.29 |
| 23 |
240-5 |
GROMMET Price: $13.66 |
| 24 |
116-4367 |
NUT-HEX This part replaces 95-0642. Price: $6.51 |
| 25 |
95-0577 |
FITTING-BULKHEAD Price: $53.24 |
| 26 |
95-0568-01 |
BRACKET-BULKHEAD This part replaces 95-0568. Price: $16.21 |
| 27 |
95-0562 |
DISCONTINUED Price: Call Us |
| 28 |
95-0563 |
TUBE-LH Price: $68.75 |
| 29 |
321-18 |
SCREW-HH Price: $1.89 |
| 30 |
51-0600 |
HOSE ASM Price: $68.83 |
| 31 |
56-7976 |
CLAMP-TUBE Price: $2.44 |
| 32 |
69-9760 |
COVERPLATE Price: $5.38 |
| 33 |
3296-8 |
NUT-HEX Price: $1.29 |
| 34 |
3256-78 |
WASHER-FLAT Price: $1.21 |
| 35 |
95-0595 |
HOSE-HYD Price: $104.29 |
| 36 |
237-78 |
O-RING Price: $3.85 |
| 37 |
237-79 |
O-RING Price: $5.46 |
| 37 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 38 |
3257-42 |
KEY-WOODRUFF Price: $5.99 |
| 39 |
237-42 |
O-RING Price: $2.78 |
| 40 |
52-2480 |
SPACER-WHEEL Price: $5.89 |
| 40 |
595088102 |
Handles This part replaces 532439871. Price: $4.99 |
| 41 |
532198200 |
SPRING.LATCH.SEAT.TEX Price: $3.99 |
| 43 |
874760612 |
BOLT Price: $3.99 |
| 44 |
583789501 |
WASHER.13/32x2 3/8x12GA This part replaces 819133812. Price: $4.99 |
