| Ref | Part Number | Description |
|---|
| 1 |
1-513051 |
SWITCH-OPEN, NORMALLY Price: $17.99 |
| 2 |
1-633181 |
PLATE-TAPPED Price: $6.09 |
| 3 |
93-2092 |
CLAMP-CABLE Price: $3.46 |
| 4 |
104-7201 |
NUT-HF Price: $0.69 |
| 5 |
HY03355 |
WASHER 3/8 X 7/8 X 15G PLATED Price: $1.49 |
| 6 |
ZWQ1J000U |
PLAIN HEAVY WASHER M10 Price: $1.38 |
| 7 |
ZNN1J000U |
HEX.NUT NYLOC M10 Price: $1.42 |
| 9 |
131-6350 |
BUSHING-PIVOT Price: $11.63 |
| 10 |
132-4844 |
MOTION PEDAL ASM Price: $71.89 |
| 11 |
132-9224 |
ROD-PEDAL Price: $10.48 |
| 12 |
132-9236 |
PEDAL ROD PIVOT ASM Price: $70.43 |
| 13 |
132-4795 |
ARM Price: $2.89 |
| 14 |
132-4796 |
ARM Price: $2.89 |
| 15 |
132-9226 |
BUSHING-PIVOT Price: $12.52 |
| 16 |
111-5727 |
PEDAL Price: $21.04 |
| 17 |
09475 |
WASHER M8 X 17 X 1.6 ZN & PASS Price: $1.40 |
| 18 |
03469 |
WASHER M8 SC SPRING Price: $1.40 |
| 19 |
03162 |
STEEL BOLT Price: $1.39 |
| 20 |
132-4797 |
PUMP-HYDRAULIC Price: $628.06 |
| 21 |
09447 |
NUT M10 X 1.5 NYL INS Price: $1.40 |
| 22 |
132-4798 |
BUSHING Price: $7.16 |
| 23 |
132-4807 |
DAMPER Price: $46.00 |
| 25 |
132-7098 |
CABLE-TRACTION Price: $39.63 |
| 28 |
321-8 |
SCREW-HH Price: $0.34 |
| 29 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 30 |
3256-78 |
WASHER-FLAT Price: $1.21 |
| 35 |
09368 |
SCREW Price: $1.40 |
| 36 |
09397 |
BOLT M10 X 60 Price: $1.40 |
| 39 |
09611 |
BOLT M10 X 40 Price: $1.40 |
| 40 |
32105-8 |
SCREW-SHH Price: $1.99 |
| 42 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 43 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 44 |
ZNH1H000U |
HEX.NUT M8 Price: $1.40 |
| 45 |
32105-18 |
SCREW-HHF Price: $0.47 |
| 47 |
132-9237 |
BUSHING Price: $8.32 |
| 48 |
ZBH1J075U |
HEX HD.BOLT M10*75 Price: $1.31 |
| 50 |
3220-1 |
NUT-JAM Price: $0.99 |
| 51 |
321-6 |
SCREW-HH Price: $0.25 |
