| Ref | Part Number | Description |
|---|
| 1 |
05050450 |
COVER, RADIATOR CAP Price: $32.85 |
| 2 |
07534800 |
KNOB-CLAMPING, .312-18 NYLOC This part replaces 07531700. Price: $3.45 |
| 3 |
05128700 |
LIGHT, INDICATOR (RED) This part replaces 08841200. Price: $6.95 |
| 4 |
09497400 |
HOUR METER This part replaces 03492700. Price: $22.45 |
| 5 |
05052850 |
GUARD, RADIATOR Price: $121.85 |
| 6 |
07060800 |
MOUNT, STUD/PLATE Price: $13.25 |
| 7 |
07532500 |
ISOLATOR .42X1.25X.25 Price: $2.95 |
| 9 |
05037500 |
FILTER, AIR DIESEL Price: $33.50 |
| 10 |
05056200 |
FILTER, FUEL-KUBOTA DIESEL Price: $14.55 |
| 11 |
05056300 |
FILTER, OIL-KUBOTA DIESEL Price: $32.45 |
| 12 |
05057051 |
WELDMENT, GOVERNOR Price: $79.05 |
| 13 |
05050751 |
MOUNT, ENGINE RH (KUBOTA) Price: $40.35 |
| 14 |
05050951 |
PLATE, TIE Price: $6.60 |
| 15 |
05056750 |
BRACKET, UPPER ENGINE (DIESEL) Price: $51.80 |
| 16 |
05034800 |
MOUNT, ENGINE, VIBRATION ISO Price: $23.45 |
| 17 |
05042750 |
TANK, FUEL DIESEL RH Price: $540.55 |
| 18 |
05052750 |
BRACKET, MUFFLER WELDMENT Price: $55.30 |
| 19 |
05042650 |
TANK, FUEL DIESEL LH Price: $540.55 |
| 20 |
05049700 |
MUFFLER ASSEMBLY Price: $179.05 |
| 21 |
09032400 |
TANK,PLASTIC 1.5 QT Price: $86.55 |
| 22 |
08967800 |
CAP,1-5/8 VENTED Price: $7.95 |
| 23 |
06500925 |
NUT-STD M6-1.0 ZCC This part replaces 06539800. Price: $0.95 |
| 24 |
05960500 |
BLT-HEX M10-1.25X20 G8.8 ZCC Price: $3.45 |
| 25 |
06500817 |
NUT,NYL M8-1.25 G8.8 ZCC This part replaces 06541700. Price: $1.45 |
| 26 |
05975000 |
BLT-HEX .50-20X1.00 GR5 YWZC Price: $3.45 |
| 27 |
06300115 |
WSHR,LK-REG .500X.125 ZCC This part replaces 06307300. Price: $0.95 |
| 28 |
06401015 |
WSHR,FLT .531X1.062X.095 ZCC This part replaces 06441900. Price: $0.95 |
| 29 |
05048400 |
HOUSING, BELL KUBOTA ASSEMBLY Price: $586.25 |
| 30 |
03604100 |
SWIVEL ASSY Price: $8.45 |
| 31 |
05976400 |
BLT,HEX M10-1.25X40 W/LK HOLE Price: $9.80 |
| 32 |
06922100 |
CLAMP-HOSE WRM .44/.78X.53 F06 Price: $4.45 |
| 33 |
05047600 |
HOSE, OIL DRAIN Price: $26.80 |
| 34 |
07060600 |
ADAPTER, FEMALE SWIVEL Price: $5.95 |
| 35 |
07060700 |
PLUG, HOSE SWIVEL Price: $2.95 |
| 36 |
05901628 |
BLT, HEX M8-1.25X20 G8.8 ZCC This part replaces 05973300. Price: $1.45 |
| 37 |
06401017 |
WSHR,FLT .344X.688X.065 ZCC This part replaces 06437200. Price: $0.45 |
| 38 |
05042800 |
CAP, FUEL LOCKING Price: $52.80 |
| 39 |
07057500 |
FTG,BARB EL .12-27MX.25ID HOSE Price: $4.95 |
| 41 |
06300119 |
WSHR-LK-REG .312X.078 ZCC This part replaces 06308600. Price: $0.95 |
| 42 |
07057400 |
FTG,BARBED .12-27MX.25 ID HOSE Price: $2.95 |
| 44 |
06924300 |
HOSE CLAMP Price: $6.95 |
| 45 |
05955200 |
BLT M10 X 1.5X40 YWZC Price: $1.30 |
| 46 |
06401013 |
WSHR-FLT .406X.812X.065 ZCC This part replaces 06436200. Price: $0.95 |
| 47 |
06300121 |
WSHR, LK-REG .438X.109 ZCC This part replaces 06309300. Price: $2.45 |
| 49 |
05049800 |
PIPE, EXHAUST Price: $143.15 |
| 50 |
06922300 |
CLAMP,MUFFLER U-BOLT Price: $7.35 |
| 51 |
06946200 |
CLAMP, MUFFLER 3.50 Price: $37.05 |
| 52 |
06538600 |
NUT-HEX M8-1.25 YWZC Price: $1.95 |
| 53 |
00922600 |
HOSE,5/16 ID Price: $0.75 |
| 54 |
05037300 |
HOSE, FLEXIBLE Price: $45.15 |
| 55 |
06923600 |
CLAMP,2.25 DIA. HOSE Price: $5.95 |
| 56 |
05037600 |
FILTER, PRE DIESEL Price: $101.25 |
| 57 |
00922600 |
HOSE,5/16 ID Price: $0.75 |
| 58 |
05050300 |
FILTER, FUEL .312 ID HOSE Price: $18.95 |
| 60 |
06945900 |
CABLE, THROTTLE DIESEL Price: $79.20 |
| 61 |
05049600 |
CLAMP, CABLE Price: $6.35 |
| 65 |
06401001 |
WSHR,FLT .281X.625X.065 ZCC This part replaces 06437300. Price: $0.45 |
| 67 |
07059400 |
ADPT, CONN .56-18MX.12-27M Price: $2.95 |
| 69 |
07506400 |
GROMMET .50IDX.812OD Price: $5.45 |
| 70 |
05044000 |
TUBE, FUEL LINE - LONG Price: $61.75 |
| 71 |
05044100 |
TUBE, FUEL LINE - SHORT Price: $35.85 |
| 72 |
07021500 |
ADPT-TEE .56-18 Price: $27.45 |
| 73 |
07057200 |
FTG-HOSE .375-M6 JIC30682-6-4B Price: $4.95 |
| 74 |
05000151 |
BRACKET, LOCK Price: $1.95 |
| 75 |
07061200 |
WASHER, WAVE .346 X .562 X .08 Price: $4.40 |
| 76 |
05056400 |
SOLENOID, KUBOTA FUEL Price: $329.40 |
| 77 |
07064700 |
NUT, EYE M10-1.5 Price: $19.35 |
| 78 |
05902026 |
BLT, HEX M6-1X16 G8.8 ZCC This part replaces 05975900. Price: $0.95 |
| 79 |
06401009 |
WSHR-LK-REG .250X.062 ZCC This part replaces 06308400. Price: $0.45 |
| 05050851 |
MOUNT, |
ENGINE LH (KUBOTA) Price: $40.35 05050851 |
