| Ref | Part Number | Description |
|---|
| 1 |
163-3530 |
CYLINDER-HYDRAULIC This part replaces 119-6988. Price: $515.30 |
| 1 |
532439740 |
WHEEL.STEER.HUSQ.SR.498.OVMLD Price: $69.99 |
| 2 |
163-3534 |
CYLINDER-HYDRAULIC This part replaces 119-6987. Price: $558.76 |
| 3 |
340-132 |
FITTING-ELBOW, 90 DEG Price: $24.64 |
| 4 |
106-3692 |
HOSE-HYD Price: $93.73 |
| 5 |
106-3693 |
HOSE-HYD Price: $115.35 |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 6 |
93-6887 |
HOSE-HYD Price: $68.37 |
| 7 |
532121748 |
WASHER Price: $3.99 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 8 |
85-4940 |
HOSE-HYD Price: $103.60 |
| 9 |
2412-137 |
CLAMP-R, DOUBLE Price: $5.08 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 11 |
3234-38 |
SCREW-HHF Price: $3.33 |
| 12 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 13 |
117-0148 |
PIN-CYLINDER Price: $52.54 |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
32120-93 |
RING-RETAINING Price: $2.49 |
| 14 |
596238701 |
Washers This part replaces 539990118. Price: $3.99 |
| 15 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
104-0046 |
PIN-SLIDE, CYLINDER Price: $10.19 |
| 16 |
587738904 |
KIT.SRVC.STEERINGSHAFT.2HISHFT This part replaces 587016002. Price: $34.99 |
| 17 |
3290-379 |
TIE-CABLE Price: $0.31 |
| 18 |
110-9012 |
CAPLUG Price: $3.94 |
| 19 |
110-9013 |
CAPLUG Price: $3.94 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
95-9495 |
CAP Price: $5.02 |
| 21 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 586840201. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 585029901. Price: $14.99 |
| 23 |
323-9 |
SCREW-HH Price: $1.29 |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM Price: $8.99 |
| 27 |
596933401 |
Washers This part replaces 819211616. Price: $2.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 45 |
587016401 |
WASHER.3/8ID.2-3/8OD.12GA.PLTD Price: $2.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 585338801. Price: $14.99 |
| 75 |
587738906 |
KIT.SRVC.STEERINGSHAFT.PINION This part replaces 580683702. Price: $4.99 |
| 76 |
580683601 |
SCREW HEAD SOCKET LRVB Price: $2.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
| 122 |
583576601 |
CAP.GEAR.SECTOR.TEX This part replaces 532444962. Price: $4.99 |
