| Ref | Part Number | Description |
|---|
| 1 |
539130874 |
SEAT for units produced before Serial No. 074439861 This part replaces 539105211. Price: $449.95 |
| 2 |
21500065 |
KIT, HOUSING, SIDE, RH Price: $328.45 |
| 2 |
539105539 |
ARM REST CUSHION Price: $158.80 |
| 3 |
539105541 |
SEAT CUSHION Price: $171.22 |
| 4 |
539105951 |
SEAT MOUNT W/DECAL This part replaces 539105283. Price: $72.99 |
| 5 |
539104525 |
SEAT ROD Price: $9.99 |
| 6 |
539105039 |
STUD/PLATE MOUNT Price: $4.99 |
| 7 |
21543771 |
SEALANT TUBE 10.1OZ. Price: $132.95 |
| 7 |
539990761 |
NUT 1/4C CENTER LOCK This part replaces 539990372. Price: $2.99 |
| 8 |
539101341 |
HCS 3/8C X 3 Price: $4.99 |
| 9 |
595305901 |
Nuts This part replaces 539990546. Price: $2.99 |
| 10 |
539976975 |
NUT M8-1.25HX NYL RNGGR8.8 Price: $0.61 |
| 11 |
539104789 |
DECAL, CROWN H Price: $3.10 |
| 12 |
539105540 |
BACK CUSHION Price: $265.72 |
| 13 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 14 |
539105224 |
SEAT BRKT W/DECAL Price: $24.99 |
| 15 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 16 |
539105544 |
SEAT RAILS Price: $103.29 |
| 17 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 18 |
539104392 |
SEAT HARNESS This part replaces 539105545. Price: $14.99 |
| 19 |
539105542 |
SEAT SWITCH Price: $69.99 |
| 20 |
21548900 |
CENTER SECTION KIT R(03935200) Price: $334.95 |
| 27 |
3220-6 |
NUT-JAM Price: $1.25 |
| 28 |
21549100 |
HG SHOCK VALVE KIT Price: $34.95 |
| 28 |
66-9770 |
SEAL Price: $20.05 |
| 29 |
21549100 |
HG SHOCK VALVE KIT Price: $34.95 |
| 29 |
66-9780 |
BUSHING Price: $11.69 |
| 35 |
21549200 |
HG CHARGE RELIEF VALVE KIT Price: $9.45 |
| 36 |
93-3609 |
BOLT-SPECIAL Price: $23.98 |
| 37 |
66-9860 |
UPPER COVER AND JACKET ASM Price: $222.25 |
| 38 |
66-9870 |
PLATE-RETAINING Price: $9.64 |
| 39 |
66-9880 |
WASHER-PLATE, RETAINING Price: $0.98 |
| 40 |
66-9890 |
RING-RETAINING Price: $4.93 |
| 41 |
66-9900 |
SHAFT-INPUT Price: $170.42 |
| 56 |
21543854 |
TWHCS 5/16-24 X 1.00 Price: $2.45 |
| 58 |
21543870 |
SPACER Price: $9.95 |
| 59 |
21543866 |
ARM, NEUTRAL RIGHT Price: $20.45 |
| 60 |
08611200 |
WASHER Price: $3.45 |
| 61 |
21543843 |
SHCS 5/16-24X1 PATCH Price: $3.95 |
| 62 |
21543872 |
ARM, SCISSOR Price: $14.95 |
| 64 |
21544041 |
RTN SPRING HG 51605 Price: $5.45 |
| 66 |
08611200 |
WASHER Price: $3.45 |
| 70 |
21544040 |
INPUT SHAFT HG 71941 Price: $64.45 |
| 81 |
21543879 |
KIT, MOTOR BLOCK Price: $79.95 |
| 86 |
21544057 |
KIT, BLOCK, 16CC CYLINDER Price: $74.95 |
| 92 |
21543704 |
RING, RET 62 EXT Price: $1.45 |
| 100 |
21544048 |
BALL, .75 Price: $1.45 |
| 105 |
21544049 |
BEARING,BALL 35 X 80 X 21 6307 Price: $25.45 |
| 106 |
21549300 |
HG SEAL LIP 1.375X2.062X.250 Price: $12.95 |
| 110 |
21544044 |
KEY, WOODRUFF 5/16 X 1 Price: $10.45 |
| 111 |
21549400 |
HG 5 BOLT HUB KIT Price: $122.45 |
| 113 |
21549500 |
HG HEX NUT 1-20 SLOTED Price: Call Us |
| 114 |
21500008 |
HG AXLE HUB CAP - ZT5400 Price: $9.45 |
| 116 |
21544045 |
PIN, COTTER 9/64 X 2 EXTENDED Price: $2.45 |
| 130 |
21544038 |
BRAKE ARM HG 53018 Price: $6.95 |
| 131 |
21544007 |
CLIP,BRAKE ARM HYDROGEAR 52027 Price: $5.45 |
| 142 |
21549600 |
CHARGE COVER KIT Price: Call Us |
| 150 |
21548300 |
FILTER,HYD OIL W/ORING ZT-54OO Price: $32.95 |
| 152 |
21549700 |
HG FILTER PLUG KIT Price: $40.95 |
| 180 |
21544035 |
PULLEY/FAN KIT HG 71906 Price: $132.95 |
