| Ref | Part Number | Description |
|---|
| 1 |
27-6861 |
SHAFT-FLANGED AXLE, LH Price: $984.28 |
| 1 |
414803X428 |
Wheel, Steering Price: Call Us |
| 2 |
184706 |
Axle Asm., Front Price: Call Us |
| 2 |
99-6969 |
SEAL-OIL, WHEEL END This part replaces 92-1774. Price: $14.71 |
| 3 |
21-8180 |
BEARING ASM Price: $65.11 |
| 4 |
21-9450 |
SHIELD-DUST Price: $45.14 |
| 4 |
403087 |
Spindle Asm., LH Price: Call Us |
| 5 |
403088 |
Spindle Asm., RH Price: Call Us |
| 5 |
43-6810 |
SPIDER-TORQUE Price: $138.50 |
| 6 |
21-9390 |
SOCKET-SCREW, ADJUSTING Price: $5.56 |
| 6 |
6266H |
Bearing, Race Thrust Harden Price: Call Us |
| 7 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 7 |
21-9370 |
SCREW-ADJUSTING Price: $18.80 |
| 8 |
12000029 |
Ring, Klip #T5304-75 Price: Call Us |
| 8 |
21-9380 |
NUT-PIVOT Price: $26.77 |
| 9 |
121232X |
Cap, Spindle Price: Call Us |
| 9 |
242-34 |
STUD-DRIVE Price: $11.61 |
| 10 |
21-8360 |
CLIP-RETAINING Price: $1.29 |
| 11 |
28-0680-03 |
DRUM-BRAKE This part replaces 28-0680. Price: $358.84 |
| 12 |
94-6935 |
LOCKNUT Price: $1.09 |
| 13 |
121749X |
Washer 25/32 x 1-1/4 x 16 Ga. Price: Call Us |
| 13 |
28-0670 |
SEAL-GREASE Price: $19.74 |
| 14 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 14 |
21-9440 |
SPRING-SCREW, ADJUSTING Price: $11.92 |
| 15 |
21-9460 |
RETAINER-LEVER, BRAKE Price: $2.18 |
| 15 |
73540600 |
Nut, Crown Lock 3/8-24 unf Price: Call Us |
| 16 |
408219 |
Shaft Steering Price: Call Us |
| 16 |
84-8600 |
SET-SHOES, LINED Price: $131.50 |
| 17 |
21-9430 |
SPRING-RETURN, RH Price: $19.96 |
| 18 |
21-9420 |
SPRING-RETURN, LH Price: $19.96 |
| 19 |
194729 |
Plate Steering Price: Call Us |
| 19 |
24-9180 |
STRUT AND LEVER ASM Price: $86.76 |
| 20 |
199743X428 |
Boot, Steering Price: Call Us |
| 21 |
186737 |
Adapter, Wheel Steering Price: Call Us |
| 21 |
94-6934 |
SCREW-HH Price: $6.99 |
| 22 |
194845 |
Bushing, Strg. Blk Price: Call Us |
| 22 |
24-8840 |
RING-RETAINING, WHEEL BEARING Price: $37.15 |
| 23 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 26 |
414854X428 |
Insert, Wheel Steering Price: Call Us |
| 28 |
17000612 |
Screw 3/8-16 x 3/4 Price: Call Us |
| 35 |
194732 |
Gear, Sector Plate Price: Call Us |
| 45 |
19183812 |
Washer 9/16 ID x 2-3/8 OD 12 GZIN Price: Call Us |
| 50 |
73900600 |
Nut Lock 3/8-16unc Price: Call Us |
| 51 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 53 |
188967 |
Washer Hardened .793 x 1.637 x .060 Price: Call Us |
| 54 |
74760636 |
Bolt Hex 3/8-16 unc x 2-1/4 Price: Call Us |
| 55 |
414736 |
Spacer Brace Axle Price: Call Us |
| 57 |
407465 |
Bracket Upstop Price: Call Us |
| 58 |
194747 |
Bolt Shoulder Sector Pivot CFM Price: Call Us |
| 59 |
194748 |
Washer Thrust Sector Steering Price: Call Us |
| 60 |
73971000 |
Nut Flange Lock 5/8-11 Price: Call Us |
| 61 |
194740 |
Draglink LH Price: Call Us |
| 62 |
194741 |
Draglink, RH Price: Call Us |
| 63 |
17000512 |
Screw 5/16-18 x 3/4 Price: Call Us |
| 64 |
199849 |
Retainer Clip Spring Steering Price: Call Us |
| 65 |
194734 |
Brace Axle Front Price: Call Us |
| 66 |
71020748 |
Bolt Hex Fghd 7/16-14 x 3 Serr Price: Call Us |
| 67 |
194737 |
Bushing PM Front Axle Price: Call Us |
| 68 |
73900700 |
Nut Lock Flange 7/16-14 Gr. 5 Price: Call Us |
| 69 |
199162 |
Washer 1.5 x .505 x .118 Price: Call Us |
| 70 |
196197 |
Bracket Deck Susp. Front Price: Call Us |
