Housing Type 1
Parts (43)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 120-4625 | LIGHT-LED Price: $229.52 |
| 1 | 530071459 | Air Dam (kit) Price: $4.99 |
| 2 | 115-7264-03 | BAR-LIGHT, LH Price: $48.03 |
| 2 | 530071458 | Gasket-Adapter (kit) Price: $5.99 |
| 3 | 115-7265-03 | BAR-LIGHT, RH Price: $48.03 |
| 3 | 530035502 | Carburetor Adaptor Price: $1.24 |
| 4 | 115-7109 | WASHER-FLAT Price: $0.88 |
| 4 | 530016309 | Screw Price: $1.99 |
| 5 | 115-5142 | SCREW-HHF Price: $0.82 |
| 5 | 530071458 | Gasket-Carburetor (kit) Price: $5.99 |
| 6 | 119-4041 | NUT-HF Price: $0.48 |
| 6 | 530071465 | Kit-Carb Ass'y. (C1Q-W11) Price: $19.40 |
| 7 | 119-4036 | SCREW-HHF Price: $0.53 |
| 7 | 530055103 | Air Box Price: $1.80 |
| 8 | 107-0747 | SWITCH-ROCKER Price: $28.45 |
| 8 | 530016340 | Screw-Carb. Price: $1.99 |
| 9 | 3290-379 | TIE-CABLE Price: $0.31 |
| 9 | 530049383 | Filter-Air Price: $1.99 |
| 10 | 132-9547 | HARNESS-LIGHT, LED Price: $89.45 |
| 10 | 530055104 | Cover-Air Filter Price: $2.99 |
| 11 | 530016354 | Screw-Air Box Cover Price: $3.33 |
| 12 | 530015880 | Screw Price: $1.99 |
| 13 | 530056257 | Assy-Muffler Cover Price: $3.33 |
| 14 | 530095469 | Handle Price: $7.99 |
| 15 | 530015886 | Screw Price: $1.99 |
| 16 | 530049323 | Isolator Price: $2.99 |
| 17 | 530071459 | Foam 25.4mm (kit) Price: $4.99 |
| 18 | 530016324 | Clamp-Blower Tube Price: $4.99 |
| 19 | 530016322 | Knob-Tube Clamp Price: $1.99 |
| 20 | 530055146 | Housing-Right Price: $22.99 |
| 21 | 530402044 | Spring-Cover Latch Price: $3.99 |
| 22 | 530049617 | Guide-Starter Rope Price: $1.99 |
| 23 | 530055145 | Housing-Left Price: $22.99 |
| 24 | 530016207 | Nut Price: $1.99 |
| 25 | 530036792 | Isolator-Crankcase Price: $4.99 |
| 26 | 545058007 | Assy-Fuel Tank This part replaces 530049491. Price: $22.99 |
| 27 | 530049527 | Gasket-Fuel Tank Price: $1.99 |
| 28 | 530057973 | Assy - Fuel Cap w/retainer This part replaces 530049386. Price: $7.99 |
| 29 | 530049656 | Grommet-Shroud Price: $1.99 |
| 30 | 530069247 | Kit-Line Carb/Purge Price: $3.99 |
| 31 | 530069216 | Kit-Line Tank/Purge Price: $3.99 |
| 32 | 530095646 | Assy-Fuel Pick-up Price: $2.99 |
| 33 | 530071459 | Grommet-Fuel line (kit) Price: $4.99 |
