| Ref | Part Number | Description |
|---|
| 1 |
3234-7 |
SCREW-HHF Price: $1.99 |
| 2 |
119-9881-03 |
COVER-BRACKET, REAR Price: $12.90 |
| 3 |
94-2413 |
NUT-U Price: $1.79 |
| 4 |
48-7880 |
NUT-HEX Price: $0.25 |
| 5 |
43-5920 |
WASHER-LOCK, SPRING This part replaces 48-8000. Price: $0.25 |
| 6 |
119-9856-03 |
BRACKET-LAMP, REAR (RH) Price: $313.95 |
| 7 |
119-8093 |
TAIL LIGHT ASM Price: $184.00 |
| 8 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 9 |
110-9380 |
SCREW-HWH Price: $1.89 |
| 10 |
119-9851-03 |
BRACKET-PIVOT, RH Price: $128.92 |
| 11 |
104-9412 |
SPRING-COMPRESSION Price: $8.24 |
| 12 |
119-9875 |
WASHER Price: $6.65 |
| 13 |
32105-15 |
SCREW-HWH Price: $1.79 |
| 14 |
119-9850-03 |
BRACKET-PIVOT, LH Price: $135.69 |
