| Ref | Part Number | Description |
|---|
| 1 |
304406 |
Tube Assembly, Shift Pivot Price: Call Us |
| 1 |
93-3351 |
GEAR-IND. PUMP Price: $373.60 |
| 2 |
304024 |
Tube Assembly, Shift Price: Call Us |
| 2 |
93-3352 |
GEAR ASSY-IDLER Price: $292.36 |
| 3 |
302538 |
Clip, Shift Lever Price: Call Us |
| 3 |
93-3364 |
DISCONTINUED Price: Call Us |
| 4 |
35497 |
Screw, Hx Hd, Wshr Tap, 5/16-18 x 1/2 In. Price: Call Us |
| 4 |
93-3363 |
DISCONTINUED Price: Call Us |
| 5 |
304086 |
Shoulder Bolt Price: Call Us |
| 5 |
42-7190 |
DISCONTINUED Price: Call Us |
| 6 |
1502 |
Nut, Hx, Ctrlk, 1/4-20 Thd. Price: Call Us |
| 6 |
42-9440 |
BOLT/WASHER Price: $4.52 |
| 7 |
71046 |
Nut, Hx, Nylon, Lock 3/8-16 Thd. Price: Call Us |
| 7 |
93-3360 |
COVER Price: $20.74 |
| 8 |
1499 |
Nut, Hx, Ctrlk, 3/8-16 Thd. Price: Call Us |
| 8 |
93-3361 |
GASKET-COVER Price: $4.72 |
| 9 |
122145 |
Screw, 3/8-16 x 1-1/4 In. Price: Call Us |
| 9 |
93-3365 |
PIN-DOWEL Price: $3.29 |
| 10 |
315823 |
Main Frame Price: Call Us |
| 10 |
93-3688 |
SHIPPING CAP(TACHOMETER) This part replaces 93-3366. Price: $5.36 |
| 11 |
93-3356 |
DISCONTINUED Price: Call Us |
| 12 |
305555 |
Exhaust Tube, L.H. Price: Call Us |
| 12 |
93-3355 |
WASHER SPRING Price: $2.71 |
| 13 |
42-9810 |
WASHER Price: $5.44 |
| 14 |
305554 |
Exhaust Tube, R.H. Price: Call Us |
| 14 |
93-3357 |
DISCONTINUED Price: Call Us |
| 15 |
93-3359 |
DISCONTINUED Price: Call Us |
| 16 |
305553 |
Muffler Price: Call Us |
| 16 |
93-3370 |
BRG-CON-ROD Price: $38.90 |
| 17 |
306577 |
Bracket Muffler Price: Call Us |
| 17 |
93-3373 |
BOLT CONNECTING Price: $25.55 |
| 18 |
104-0552 |
PIN,PISTON This part replaces 93-3374. Price: $40.18 |
| 18 |
995346 |
Screw, Hx Hd, Tap 1/4-20 X 1/2 In. Price: Call Us |
| 19 |
308144 |
Heat Shield, Muffler Price: Call Us |
| 19 |
93-3375 |
RING SET-PISTON Price: $181.55 |
| 20 |
93-3596 |
DISCONTINUED Price: Call Us |
| 20 |
9796 |
Bracket, Transaxle Price: Call Us |
| 21 |
126211 |
Bolt, Carriage, 5/16-18 X 5/8 In. Price: Call Us |
| 22 |
55273 |
Nut, Hx, Wd Fl, Lk 5/16-18 Thd. Price: Call Us |
| 22 |
93-3376 |
PISTON STD Price: $250.91 |
| 23 |
104-0553 |
CONNECTING ROD ASM This part replaces 93-3371. Price: $734.57 |
| 23 |
309388 |
Pulley Assembly, Engine Price: Call Us |
| 24 |
302879 |
Bearing, Sleeve Sector Gear Price: Call Us |
| 24 |
43-1810 |
GEAR RING Price: $269.80 |
| 25 |
120383 |
Washer, Split, Lock 7/8 In. Price: Call Us |
| 25 |
93-3358 |
FLYWHEEL SUB-ASSY Price: $1,601.02 |
| 26 |
215649 |
Screw, Hx Hd, 7/16-20 X 5-1/2 In. Price: Call Us |
| 26 |
54-8670 |
BOLT Price: $6.00 |
| 27 |
303241 |
V-Belt, 90 In. Long Price: Call Us |
| 27 |
93-3354 |
DISCONTINUED Price: Call Us |
| 28 |
310162 |
Belt Guide Price: Call Us |
| 28 |
42-7730 |
DISCONTINUED Price: Call Us |
| 29 |
57157 |
Washer, Special Price: Call Us |
| 30 |
1498 |
Nut, Hex, Ctrlk, 5/16-18 Thd. Price: Call Us |
| 30 |
93-3372 |
DISCONTINUED Price: Call Us |
| 31 |
57569 |
Cable Clip Price: Call Us |
| 31 |
93-3369 |
DISCONTINUED Price: Call Us |
| 32 |
50947 |
Screw, Hx Hd Tap, 3/8-16 X 1-1/4 In. Price: Call Us |
| 32 |
93-3367 |
DISCONTINUED Price: Call Us |
| 33 |
138489 |
Washer, 3/8 In. Price: Call Us |
| 33 |
42-9250 |
BOLT Price: $1.63 |
| 34 |
304490 |
Pad, Clutch/Brake, Molded Price: Call Us |
| 34 |
93-3362 |
DISCONTINUED Price: Call Us |
| 35 |
306083 |
Assembly, Clutch/Brake Arm Price: Call Us |
| 35 |
93-3350 |
GEAR-CAMSHAFT Price: $385.01 |
| 36 |
313271 |
Bracket, Clutch/Brake Arm Price: Call Us |
| 37 |
304208 |
Lever, Park Brake Price: Call Us |
| 38 |
304217 |
Rod, Parking Brake Price: Call Us |
| 39 |
304367 |
Knob, Park Brake Price: Call Us |
| 40 |
25086 |
Shoulder Bolt, 5/16-18 Thd. Price: Call Us |
| 41 |
120385 |
Washer, 9/16 In. Price: Call Us |
| 42 |
121223 |
Cotter Pin Price: Call Us |
| 43 |
304209 |
Spring, Clutch Price: Call Us |
| 44 |
304125 |
Bracket, Brake Rod Price: Call Us |
| 45 |
271184 |
Nut, Hx, Keps, 5/16-18 Thd. Price: Call Us |
| 46 |
304212 |
Rod, Clutch Price: Call Us |
| 47 |
304049 |
Arm, Idler Price: Call Us |
| 48 |
51189 |
Shoulder Bolt, 3/8-16 Thd. Price: Call Us |
| 49 |
274517 |
Washer, Flat, 13/32 In. Price: Call Us |
| 50 |
36368 |
Hairpin Price: Call Us |
| 51 |
304083 |
Rod, Shift-On-The-Go Price: Call Us |
| 52 |
57325 |
Carriage Bolt, 3/8-16 x 2 In. Price: Call Us |
| 53 |
40223 |
Idler Sheave, Backside Price: Call Us |
| 54 |
304105 |
Belt Retainer Price: Call Us |
| 55 |
304130 |
Spring, Brake Price: Call Us |
| 56 |
45171 |
Nut, Flange, 3/8-16 Thd Price: Call Us |
| 57 |
22053 |
Retaining Ring Price: Call Us |
| 58 |
3021 |
Key, Woodruff, #606 Price: Call Us |
| 59 |
303109 |
Pulley Price: Call Us |
| 60 |
309546 |
Shift Link Price: Call Us |
| 61 |
120394 |
Washer, Flat, 13/32 In. Price: Call Us |
| 62 |
302582 |
Shift Lever, Transaxle Price: Call Us |
| 63 |
56255 |
Screw, Hx Hd, 1/4-28 X 3/4 In. Price: Call Us |
| 64 |
120392 |
Flatwasher Price: Call Us |
| 65 |
30289 |
Washer, Wave Price: Call Us |
| 66 |
309436 |
Push Nut, 5/16 Bolt Retainer Price: Call Us |
| 67 |
995338 |
Screw, Hex Hd Tap, 1/4-20 x 5/8 In. Price: Call Us |
| 68 |
305562 |
Key, Square 1/4 Price: Call Us |
| 69 |
313044 |
Air Deflector Price: Call Us |
| 70 |
121222 |
Pin, Cotter Price: Call Us |
| 71 |
308188 |
Washer Price: Call Us |
| 72 |
56472 |
Deflector Price: Call Us |
| 73 |
35287 |
Screw, Hx Wa Hd, #8-32 x 3/8 In. Price: Call Us |
| 74 |
307174 |
Nipple, 3/8-18 x 4 In. Price: Call Us |
| 75 |
47828 |
Cap, Pipe Price: Call Us |
| 76 |
308950 |
Electric Clutch Price: Call Us |
