| Ref | Part Number | Description |
|---|
| 2 |
1983718 |
IGN. SWITCH 96 Not Available Price: |
| 3 |
1981046 |
UPPER HANDLE ASSEMBLY Not Available Price: |
| 3A |
1983728 |
GRIP 97 Not Available Price: |
| 4 |
1983649 |
PAD-ISOLAT Not Available Price: |
| 5 |
1766998 |
HARNESS-WI Not Available Price: |
| 6 |
712-0127 |
FLAT WELD NUT Not Available This part replaces 1185490. Price: |
| 7 |
1983646 |
ASSEMBLY TRIGGER & CABLE Not Available Price: |
| 9 |
1983650 |
WASHER-BOW 1.0X.328X.059 Price: Call Us |
| 10 |
1763767 |
KNOB Not Available Price: |
| 11 |
1984509001 |
H/BAR-LOWE Not Available Price: |
| 12 |
1984510001 |
HANDLE LOWER LEFT Not Available Price: |
| 15 |
N/A |
ENGINE, TECUMSEH TC-200-2026C |
| 18 |
1185590 |
HAIRPIN COTTER Price: $4.26 |
| 19 |
1983630 |
CLUTCH ROTOR Price: Call Us |
| 20 |
H213773 |
SPRING, CLUTCH Price: Call Us |
| 21 |
1981014001 |
DRAG STAKE Not Available Price: |
| 22 |
1983723 |
CLEVIS PIN Not Available Price: |
| 23 |
1981010001 |
DRAG STAKE Not Available Price: |
| 24 |
714-0145 |
Click Pin This part replaces 1703011. Price: $4.42 |
| 25 |
1984430 |
TINE ASSEMBLY (RH) OUTER Not Available Price: |
| 26 |
1984429 |
TINE, INNER RIGHT HAND SIDE Price: Call Us |
| 28 |
1985791 |
HOOD W/DECAL 85056 SPEEDYHOE Not Available Price: |
| 29 |
1981022010 |
PLATE REAR Not Available Price: |
| 29A |
1981018010 |
SHIELD-ROCK PNT Not Available Price: |
| 32 |
90021 |
BOLT, 1/4-20 X 2" Price: Call Us |
| 33 |
90030 |
BOLT, 1/4-20 X 7/8 Price: Call Us |
| 34 |
1904183 |
KIT-DUST CAP Not Available Price: |
| 34A |
N/A |
AIR VENT SCREW/FILL HOLE SCREW |
| 35 |
1984427 |
TINE, INNER LEFT HAND SIDE Price: Call Us |
| 36 |
1984428 |
TINE, OUTER LEFT HAND SIDE Price: Call Us |
| 37 |
1983713 |
WASHER, FELT Price: $4.53 |
| 38 |
1984514 |
CLUTCH-DRUM & HUB Not Available Price: |
| 39 |
1983631 |
TRANSMISSION ASSEMBLY Price: Call Us |
| 11073 |
BRAKE |
DISC Not Available Price: 11073 |
| 1982393 |
KIT-TINE |
REPLACE 85059 Price: Call Us 1982393 |
| 1983094 |
DECAL-CAUTION |
Not Available Price: 1983094 |
| 1983095 |
DECAL-WARNING |
Not Available Price: 1983095 |
| 1983096 |
DECAL-THROTTLE |
HHT Not Available Price: 1983096 |
| 1983097 |
DECAL-ENGINE |
ON/OF Not Available Price: 1983097 |
| 1983647 |
CUP-MEASUR |
Not Available Price: 1983647 |
| 1981012001 |
SWITCH |
BRACKET AS/850 Not Available This part replaces 1981012. Price: 1981012001 |
