| Ref | Part Number | Description |
|---|
| 1 |
532106108 |
RIM.ASM.8X7.REAR.SILVER This part replaces 532124999. Price: $99.99 |
| 1 |
93-3523 |
HOSE ASSY-FUEL Price: $24.72 |
| 2 |
532138756 |
TIRE.TURF.SAVER.23X8.5-12. This part replaces 532124106. Price: $199.99 |
| 2 |
93-3528 |
PLUG Price: $40.02 |
| 2A |
532007154 |
TUBE.23X9.5-12 Price: $54.99 |
| 3 |
532108097 |
SPACER HYT Price: $4.99 |
| 3 |
67-4510 |
GUAGE-TEMP, WATER Price: $151.90 |
| 4 |
532009396 |
SQ KEY This part replaces 532124762. Price: $3.99 |
| 4 |
56-2020 |
DISCONTINUED Price: Call Us |
| 5 |
532123797 |
TRANSAXLE NLA Price: $764.80 |
| 5 |
56-1360 |
WATER OUTLET FITTING Price: $48.11 |
| 6 |
42-7550 |
GASKET Price: $12.51 |
| 7 |
93-3524 |
THERMOSTAT Price: $88.41 |
| 8 |
532121274 |
KNOB.DUCKHEAD.1/2 Price: $8.99 |
| 8 |
93-3521 |
GASKET-THERMOCASE Price: $11.29 |
| 9 |
93-3527 |
GASKET Price: $4.82 |
| 10 |
812000008 |
KLIP RING Price: $2.99 |
| 10 |
93-3526 |
SWITCH Price: $177.42 |
| 11 |
532141002 |
SHIFT ROD This part replaces 532123781. Price: $16.58 |
| 11 |
93-3519 |
CASE ASSY THERMOSTAT Price: $186.27 |
| 12 |
51-8670 |
NUT This part replaces 93-3509. Price: $1.65 |
| 12 |
532123782 |
SPRING,TORSION Price: $3.99 |
| 13 |
93-3510 |
SPRING-WASHER Price: $1.49 |
| 14 |
596029601 |
Pins This part replaces 876020416. Price: $1.99 |
| 14 |
93-3511 |
WASHER PLAIN Price: $3.46 |
| 15 |
532105701 |
WASH-SHFT PLT LT Price: $3.99 |
| 15 |
93-3512 |
BOLT-ALTERNATOR Price: $34.48 |
| 16 |
596204201 |
Washers This part replaces 819091216. Price: $2.99 |
| 16 |
93-3508 |
PLATE-ADJUSTING Price: $34.43 |
| 17 |
54-8660 |
WASHER Price: $2.23 |
| 17 |
596136601 |
Bolts This part replaces 871040412. Price: $1.99 |
| 18 |
532123791 |
KEEPER BELT LH Price: $6.99 |
| 18 |
67-4660 |
BOLT-FLANGE Price: $2.64 |
| 19 |
532123794 |
ARM,SHIFT Price: $2.38 |
| 19 |
93-3522 |
DISCONTINUED Price: Call Us |
| 20 |
532126909 |
SPRING,ROD BRAKE Price: $4.99 |
| 20 |
56-1400 |
CLIP-HOSE Price: $2.00 |
| 21 |
532123786 |
ROD BRAKE Price: $27.99 |
| 24 |
532146682 |
SPRING,BRAKE RETURN This part replaces 532110422. Price: $5.99 |
| 25 |
532002751 |
CLIP T This part replaces 532124996. Price: $2.42 |
| 26 |
532123772 |
SHAFT,SHIFTER Price: $13.22 |
| 27 |
734117771 |
BUSHING This part replaces 819171216. Price: $3.99 |
| 28 |
532166230 |
LINK, TRANSAXLE This part replaces 532123793. Price: $29.99 |
| 29 |
532150360 |
NUT LOCK CENTER 1/4 -28 FNTHD This part replaces 873530400. Price: $2.99 |
| 30 |
532123787 |
STRAP TORQUE Price: $3.99 |
| 31 |
532071208 |
BUSHING.STEERING.ROD LTB-WSL Price: $3.99 |
| 32 |
532123780 |
BRKT TRANS LH Price: $4.99 |
| 33 |
819212016 |
WASHER D Price: $4.99 |
| 34 |
812000053 |
E RING HYT Price: $3.99 |
| 35 |
532123800 |
WASHER Price: $3.99 |
| 37 |
532121327 |
PULLEY TRANSAXLE Price: $22.03 |
| 38 |
532059192 |
VALVE CAP Price: $4.99 |
| 39 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 40 |
532123792 |
KEEPER,BELT RH Price: $4.99 |
| 41 |
812000004 |
Ring, Retainer Price: $3.99 |
| 42 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 43 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 45 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 46 |
532123776 |
BRKT TRANS RH Price: $4.06 |
| 47 |
532124579 |
COVER,WHEEL Price: $19.57 |
