| Ref | Part Number | Description |
|---|
| 1 |
120-3801-03 |
FRAME-ARM, CONTROL Price: $445.78 |
| 1 |
532140064 |
SPRING-MOWER CLUTCH Price: $14.99 |
| 2 |
120-6310 |
LCD DISPLAY ASM Price: $584.72 |
| 2 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 3 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 3 |
95-8999 |
SWITCH Price: $42.14 |
| 4 |
105-4232 |
SWITCH Price: $88.64 |
| 4 |
531165101 |
SERVICE KIT BRAKE ASSEMBLY BRA This part replaces 532130840. Price: $6.99 |
| 5 |
32144-86 |
SCREW-HWHTF Price: $1.29 |
| 5 |
532131251 |
IDLER BELT GUIDE Price: $3.99 |
| 6 |
3230-23 |
SCREW-CARR Price: $0.89 |
| 6 |
532121316 |
PULLEY.IDLER.FLAT.MOWER.BLK.PT Price: $44.99 |
| 7 |
125-1938 |
LATCH Price: $27.46 |
| 7 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 8 |
120-5280 |
BRACKET-JOYSTICK Price: $203.76 |
| 8 |
596134901 |
GSPH This part replaces 819131410. Price: $2.99 |
| 9 |
104-7201 |
NUT-HF Price: $0.69 |
| 9 |
532140092 |
IDLER ARM ASSY This part replaces 532127744. Price: $8.78 |
| 10 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 10 |
595901101 |
Bolts This part replaces 872140610. Price: $3.99 |
| 11 |
532130841 |
BRAKE ROD Price: $24.99 |
| 11 |
74-5950 |
LATCH-SWELL Price: $21.28 |
| 12 |
104-2065 |
SCREW-HWH Price: $0.28 |
| 12 |
532127356 |
BRKT LIFT REAR Price: $3.99 |
| 13 |
256-257 |
BUSHING-NYLINER Price: $3.19 |
| 13 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 14 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 15 |
108-7605 |
COVER-RH Price: $55.56 |
| 15 |
532127357 |
BRKT LIFT REAR LH Price: $4.99 |
| 16 |
108-7604 |
COVER-LH Price: $55.56 |
| 16 |
532153298 |
BELT KEEPER Price: $11.99 |
| 17 |
233-42 |
KNOB Price: $12.88 |
| 17 |
532128508 |
MOWER LINK STABILIZER Price: $41.84 |
| 18 |
532128511 |
PIN GROOVE Price: $2.99 |
| 18 |
93-5961 |
BOOT-LEVER Price: $56.35 |
| 19 |
112-9181 |
PLATE-BOOT Price: $4.90 |
| 19 |
532127380 |
BRKT LINK STABILIIZER Price: $7.99 |
| 20 |
161-7350 |
IGNITION SWITCH ASM This part replaces 106-5269. Price: $56.32 |
| 20 |
532138496 |
BLADE, HI-LIFT 36" PREMIUM Price: $22.99 |
| 21 |
121-5644 |
DECAL-CONTROL PANEL Price: $30.69 |
| 21 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 22 |
120-4158 |
DECAL-CONSOLE, UPPER Price: $23.98 |
| 22 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 23 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 23 |
532850857 |
BLADE BOLT Price: $3.99 |
| 24 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532140329. Price: $6.99 |
| 25 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532138776. Price: $3.99 |
| 27 |
532174082 |
DECK SVCX1 KIT MOWER.36.LR This part replaces 532156600. Price: $119.99 |
| 27 |
99-8970 |
KEY-LATCH, HOOD Price: $15.13 |
| 28 |
3250-22 |
SCREW-PPH Price: $4.09 |
| 28 |
532173434 |
MANDREL PULLEY This part replaces 532153531. Price: $14.99 |
| 29 |
114-0446 |
PANEL-ACCESS Price: $18.13 |
| 29 |
532139729 |
KIT.NUT.FLANGE This part replaces 532137266. Price: $7.99 |
| 30 |
117-0169 |
DECAL-FUSES Price: $17.49 |
| 31 |
114-3321 |
CONTROLLER-TEC Price: $1,515.96 |
| 31 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 32 |
32144-87 |
SCREW-HWHTF Price: $0.49 |
| 32 |
532122051 |
SUPT,IDLER ARM Price: $4.99 |
| 33 |
108-7602 |
REST-ARM Price: $158.43 |
| 33 |
532175029 |
SHIELD.DEFL.MWR.36" This part replaces 532131560. Price: $24.99 |
| 34 |
110-8912 |
SEAL-FOAM Price: $2.23 |
| 35 |
110-5331 |
SPRING-COMPRESSION Price: $22.18 |
| 36 |
283-88 |
PIN-CLEVIS Price: $5.77 |
| 36 |
593885101 |
Rods This part replaces 532121980. Price: $5.99 |
| 37 |
32144-41 |
SCREW-TAPTITE Price: $4.79 |
| 37 |
532123713 |
SPRING TORSION Price: $6.99 |
| 38 |
4-2390 |
WASHER-FLAT Price: $0.62 |
| 38 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 39 |
110-5313-03 |
BRACKET-RETAINER Price: $35.01 |
| 39 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 40 |
283-73 |
PIN-CLEVIS Price: $0.95 |
| 40 |
532110452 |
NUT PUSH M Price: $2.99 |
| 41 |
322-7 |
SCREW-HH Price: $0.89 |
| 41 |
532131264 |
BELT Price: $34.99 |
| 42 |
110-5314 |
LATCH Price: $22.89 |
| 42 |
596040101 |
Washers This part replaces 819171616. Price: $2.99 |
| 43 |
3272-1 |
PIN-COTTER Price: $0.25 |
| 43 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 44 |
110-8856 |
SPACER Price: $10.25 |
| 44 |
532140608 |
KEEPER LH Price: $22.99 |
| 45 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 45 |
532110485 |
BEARING Price: $11.99 |
| 46 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 46 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 47 |
133-2929 |
CONTROL-THROTTLE Price: $69.01 |
| 47 |
532129895 |
BEARING.BALL.#6204.(MANDREL) Price: $9.99 |
| 48 |
3290-134 |
SCREW Price: $0.27 |
| 48 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 49 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 62 |
532153390 |
WASHER FELT Price: $3.99 |
| 532130794 |
KIT.MANDREL.ASM.3.BOLT |
Price: $49.99 532130794 |
| 532156866 |
DECK |
ASM SVCX 36" HI PERF Price: $599.99 532156866 |
