| Ref | Part Number | Description |
|---|
| 1 |
3290-384 |
PIN-LYNCH Price: $18.43 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT This part replaces 532195223. Price: $69.99 |
| 2 |
69-1510 |
SPACER Price: $4.48 |
| 3 |
32128-23 |
NUT-HF Price: $1.51 |
| 3 |
594018001 |
Levers This part replaces 532195231. Price: $17.99 |
| 4 |
69-8790-01 |
PLATE-REINFORCING Price: $21.41 |
| 5 |
69-7290-01 |
MOUNT-JOINT, BALL Price: $105.61 |
| 6 |
325-15 |
SCREW-HH Price: $3.19 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK Price: $7.99 |
| 7 |
69-8860 |
DISCONTINUED Price: Call Us |
| 8 |
32151-48 |
E-RING Price: $1.41 |
| 9 |
283-70 |
PIN-HITCH Price: $29.52 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 10 |
98-3047-01 |
MACHINING - PIVOT ARM This part replaces 98-3047. Price: $355.96 |
| 11 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 13 |
93-4241 |
SPACER-BEARING, INNER Price: $26.72 |
| 14 |
120-5378 |
BEARING-BALL This part replaces 93-4237. Price: $13.84 |
| 15 |
327-24 |
SCREW-HH Price: $7.99 |
| 16 |
3296-53 |
NUT-LOCK, NI Price: $1.47 |
| 17 |
323-15 |
SCREW-HH Price: $1.53 |
| 18 |
5-0838 |
WASHER Price: $1.09 |
| 19 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 20 |
327-25 |
SCREW-HH Price: $11.16 |
| 21 |
93-5630 |
SPACER-BEARING, INNER Price: $45.74 |
| 22 |
98-7313 |
TIRE-12 INCH Price: $72.29 |
| 24 |
98-7302-01 |
FORK-CASTOR Price: $418.77 |
| 25 |
69-6860 |
WASHER-THRUST Price: $3.15 |
| 26 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 27 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 28 |
32128-16 |
NUT-HHF Price: $0.54 |
| 29 |
69-9260 |
CLEVIS PIN Price: $49.47 |
| 30 |
95-0818 |
DECAL-TORQUE Price: $22.79 |
| 31 |
13-5069 |
DISCONTINUED Price: Call Us |
| 32 |
30-8770 |
WASHER Price: $3.43 |
| 33 |
93-4242 |
PLATE Price: $11.21 |
| 34 |
93-4243 |
TIRE Price: $54.25 |
| 35 |
93-4239 |
RIM-WHEEL, HALF Price: $29.68 |
| 36 |
93-5980 |
HUB Price: $67.14 |
| 37 |
93-4244 |
TUBE-INNER (W/VALVE) Price: $14.42 |
| 40 |
95-2741 |
RIM-WHEEL, HALF Price: $25.01 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 532195181. Price: $14.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 |
581506903 |
Links This part replaces 532195270. Price: $9.99 |
| 100 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
