| Ref | Part Number | Description |
|---|
| 1 |
47-3010-01 |
TRAILER ASM Price: $3,956.22 |
| 2 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 3 |
5-2942 |
SHACKLE Price: $16.99 |
| 3 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 4 |
47-3650 |
CHAIN-LIFT, NO. 2 AND 3 Price: $119.48 |
| 5 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 6 |
3-2196-01 |
SHEAVE Price: $141.72 |
| 7 |
32153-5 |
NUT-HEX Price: $1.59 |
| 8 |
51-0850-01 |
SUPPORT-PULLEY Price: $306.47 |
| 9 |
47-3930-01 |
LOCKUP BRACKET ASM Price: $270.92 |
| 10 |
325-17 |
SCREW-HH Price: $2.90 |
| 11 |
322-3 |
SCREW-HH Price: $0.79 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 13 |
60-9110-01 |
LIFT BAIL PIN ASM Price: $84.41 |
| 14 |
47-3230-01 |
NO. 1 LIFT ARM ASM Price: $907.15 |
| 14 |
532442396 |
HOOD.ASM.HUSQVARNA.GT.TEX.ORAN This part replaces 532411046. Price: $149.99 |
| 15 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 15 |
532198907 |
LENS.LH.TEX.GT.HUSQ.CL Price: $22.99 |
| 17 |
13-6200 |
PIN-HITCH, POINTED Price: $40.83 |
| 18 |
42-3550-01 |
COVER-MOUNT, CYLINDER Price: $108.41 |
| 18 |
532408607 |
GRILL.ASM.HUSQ.TG/CRD.W/TRIM Price: $129.99 |
| 19 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 20 |
32104-17 |
SCREW-HWH Price: $0.99 |
| 21 |
20-4390 |
SPACER Price: $12.54 |
| 22 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 23 |
3-0144 |
SHAFT Price: $53.89 |
| 24 |
115-4949 |
HYD CYLINDER ASM Price: Call Us |
| 25 |
26-8590 |
PIN-CYLINDER Price: $23.00 |
| 25 |
532198906 |
LENS.RH.TEX.GT.HUSQ.CL Price: $32.99 |
| 26 |
47-3870-01 |
RH CHANNEL ASM Price: $235.39 |
| 27 |
47-3860-01 |
LH CHANNEL ASM Price: $215.68 |
| 28 |
325-6 |
SCREW-HH Price: $1.42 |
| 29 |
3290-216 |
WASHER Price: $3.83 |
| 30 |
47-3640-01 |
CYLINDER REST ASM Price: $44.42 |
| 31 |
32128-23 |
NUT-HF Price: $1.51 |
| 32 |
353-537 |
FITTING-ELBOW, 90 DEG Price: $12.91 |
| 33 |
47-3660 |
CHAIN-LIFT, NO. 1 Price: $197.71 |
| 34 |
325-7 |
SCREW-HH Price: $1.53 |
| 34 |
580910801 |
PLATE.ENGINE.WELDED.CHASSIS This part replaces 532196125. Price: $59.99 |
| 36 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 37 |
532441208 |
FENDER.PNT.TX.GT.CH/FW/DL.HUSQ This part replaces 532401825. Price: $219.99 |
| 58 |
532412281 |
DRAWBAR.UPPER.2PC,LRG.FENDER Price: $37.99 |
| 68 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 130 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 137 |
532407590 |
BUMPER DASH Price: $3.99 |
| 150 |
532198512 |
AIR.DUCT.HOOD.TEX.GT.HUSQ Price: $29.99 |
| 152 |
531169901 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532199535. Price: $19.99 |
| 161 |
532401801 |
FUEL WINDOW This part replaces 532401826. Price: $5.99 |
| 162 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 165 |
532196826 |
SUPPORT.TANK.REAR.W/TEX Price: $22.99 |
| 175 |
590607702 |
PLATE.PNT.CROSSMEMBER.HUSQ/PRE This part replaces 532196304. Price: $32.99 |
| 176 |
532400776 |
SCREW.#10-24X5/8.RN.QU Price: $4.99 |
| 177 |
532195227 |
BUSHING, STEERING Price: $5.99 |
| 178 |
532199782 |
CARGO.ASM.NET.TXGT.W/C Price: $29.99 |
| 180 |
532415063 |
CHASS.WLDMNT.TL.12GA/2P.48/54 Price: $169.99 |
| 181 |
532403025 |
BUSHING.MNT.FEND.CRGO. Price: $4.99 |
| 182 |
532406859 |
DASH.LOWER.COMMON.12V.ADAPTOR Price: $84.99 |
| 183 |
595305701 |
Screws This part replaces 874520520. Price: $3.99 |
| 189 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 194 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 195 |
532405137 |
NEEDS DESCRIPTION Price: Call Us |
| 196 |
532400299 |
RP CONSOLE.ASM.DECKLFT.W/ Price: $69.99 |
| 199 |
532198259 |
PLATE.DECK.LIFT.HUSQVARNA.GT Price: $17.99 |
| 202 |
532403048 |
VENT.SIDE.HOOD.HUSQ.RH.GREY Price: $7.99 |
| 203 |
532403076 |
VENT.SIDE.HOOD.HUSQ.LH.GRAY Price: $7.99 |
| 204 |
532416615 |
VENT.ASM.TORPHD.HUSQGT.LOGO.CL This part replaces 532416613. Price: $16.99 |
| 205 |
532401709 |
SKIRT.HOOD.SIDE.HUSQ.RH.GREY Price: $6.99 |
| 206 |
532401711 |
SKIRT.HOOD.SIDE.HUSQ.LH.GREY Price: $5.99 |
| 207 |
532197198 |
BEZEL.RH.TEX.GT.HUSQ Price: $19.99 |
| 208 |
532197199 |
BEZEL.LH.TEX.GT.HUSQ Price: $17.99 |
| 209 |
532199130 |
INSERT.HEX.GRILL.HUSQ.GREY Price: $4.99 |
| 210 |
532199131 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 211 |
532199132 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 212 |
532199133 |
INSERT.HEX.GRILL.HUSQ. Price: $2.99 |
| 213 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 214 |
532199145 |
CLIP.RETAINER.TINNER. Price: $2.99 |
| 217 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 218 |
532196395 |
X-PIECE.HOOD.STOP.NON/ Price: $6.99 |
| 221 |
532198909 |
REFLECTOR.LH.TEX GT HU Price: $14.99 |
| 228 |
593824001 |
STUD.W/"D"ANTI-ROTATION This part replaces 532195161. Price: $3.99 |
| 233 |
532196539 |
BOLT.SHOULDER Price: $5.99 |
| 234 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 235 |
596564201 |
Spacers This part replaces 532406129. Price: $4.99 |
| 236 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 238 |
532408606 |
TRIM.HUSQ.TG/CRD.SERVICE Price: $17.99 |
| 279 |
532402680 |
ROD UPSTOP Price: $13.99 |
| 280 |
532402681 |
ROD UPSTOP Price: $14.99 |
| 281 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 298 |
532110452 |
NUT PUSH M Price: $2.99 |
| 307 |
583413101 |
SHIELD.UPPER.PEDAL.TEX.FRENCH This part replaces 532424570. Price: $9.99 |
