| Ref | Part Number | Description |
|---|
| 1 |
532174620 |
CHASSIS Price: $119.99 |
| 2 |
583101001 |
DRAWBAR.CRD This part replaces 532180384. Price: $64.99 |
| 3 |
817000612 |
SCREW, 3/8-16X3/4 This part replaces 817060612. Price: $3.99 |
| 5 |
532407590 |
BUMPER DASH Price: $3.99 |
| 5 |
95-8960-0P |
BRACKET-NEUTRAL This part replaces 95-8960-03. Price: $47.94 |
| 6 |
32128-43 |
NUT-FLANGE Price: $0.94 |
| 6 |
583133601 |
SADDLE.FLAT.LT/YT/CRD.2003 This part replaces 532184419. Price: $12.99 |
| 7 |
3234-1 |
SCREW-HHF Price: $1.62 |
| 8 |
140-6168 |
NEUTRAL ARM ASM This part replaces 104-0422. Price: $115.71 |
| 8 |
532126471 |
CLIP,INSULATOR Price: $3.99 |
| 9 |
532409467 |
NEEDS DESCRIPTION Price: Call Us |
| 10 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 10 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 11 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 11 |
532174996 |
PANEL.DASH.LH.LTX Price: $9.99 |
| 12 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 13 |
100-4817 |
SPACER-BEARING Price: $4.03 |
| 13 |
532172106 |
PANEL ASM, DASH RH Price: $14.99 |
| 14 |
76-8640 |
STUD-TRACTION Price: $23.60 |
| 15 |
874180512 |
Screw, Machine, Truss Head 5/16-18 UNC x 3/4 Price: $3.99 |
| 16 |
33093-00 |
WASHER-FLAT Price: $0.70 |
| 16 |
596040501 |
Hardware This part replaces 873510500. Price: $2.99 |
| 17 |
532441267 |
HOOD.HUSQVARNA.LT.ORANGE Price: $79.99 |
| 18 |
532404742 |
BUMPER.HOOD.TEX.HUSQVARNA Price: $5.99 |
| 18 |
94-1369 |
SPRING-EXTENSION Price: $12.72 |
| 19 |
3210-6 |
SCREW-HH Price: $1.76 |
| 20 |
88-7200 |
WASHER-FLAT Price: $2.51 |
| 21 |
120-5566 |
HUB Price: $49.38 |
| 22 |
32128-44 |
NUT Price: $2.69 |
| 23 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 24 |
104-0464-03 |
BRACKET-SUPPORT, CABLE Price: $35.63 |
| 24 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 25 |
251-259 |
BEARING-BALL Price: $13.67 |
| 25 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 26 |
2411-41 |
ROD END-BALL JOINT Price: $40.28 |
| 26 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 27 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 28 |
3274-104 |
SCREW-HSBH Price: $0.54 |
| 28 |
584382301 |
GRILLE.SVC.HUSQVARNA.L This part replaces 532426963. Price: $54.99 |
| 30 |
532197376 |
CONSOLE.CRD.AUTO.GRY Price: $8.99 |
| 30 |
99-3556 |
HOSE Price: $12.50 |
| 31 |
532165156 |
BRACKET SUPPORT FENDER Price: $5.99 |
| 31 |
99-3594-0P |
LEVER-PUMP This part replaces 99-3594-03. Price: $53.70 |
| 32 |
321-8 |
SCREW-HH Price: $0.34 |
| 33 |
2844 |
WASHER Price: $2.69 |
| 33 |
532182507 |
FOOTREST.LH.BLACK This part replaces 532181057. Price: $37.99 |
| 34 |
532182508 |
FOOTREST.RH.BLACK This part replaces 532181058. Price: $22.99 |
| 34 |
95-3857 |
SCREW-HSBH Price: $4.09 |
| 35 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
| 35 |
63-9750 |
MOUNT Price: $18.92 |
| 36 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 37 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 37 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 38 |
583117401 |
BRACKET ARM.PIVOT.REAR This part replaces 532181748. Price: $9.99 |
| 39 |
532407807 |
BRACKET PIVOT Price: $27.99 |
| 58 |
532407537 |
DUCT.AIR. Price: $34.99 |
| 64 |
532408127 |
Price: Call Us |
| 69 |
596134101 |
Screws This part replaces 532142432. Price: $2.99 |
| 89 |
532441574 |
CONSOLE.CRD.AUTO.GRY This part replaces 532197377. Price: $8.99 |
| 141 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 145 |
532409167 |
ROD.PIVOT.HOOD Price: $9.99 |
| 154 |
532408122 |
Price: Call Us |
| 155 |
532408123 |
Price: Call Us |
| 162 |
583100801 |
BRKT.EXTEN.CHASSIS.LH.CRD This part replaces 532180382. Price: $48.99 |
| 163 |
583100901 |
BRKT.EXTEN.CHASSIS.RH.CRD This part replaces 532180383. Price: $43.99 |
| 164 |
532165605 |
SUPPORT Price: $59.99 |
| 165 |
532441516 |
COVER.BATT.CUPHOLDER.CRD This part replaces 532181100. Price: $17.99 |
| 170 |
532199488 |
Price: Call Us |
| 171 |
596337801 |
Bolts This part replaces 872140620. Price: $4.99 |
| 172 |
596134901 |
GSPH This part replaces 819132016. Price: $2.99 |
| 173 |
873510600 |
NUT Price: $4.99 |
| 175 |
583707801 |
DOOR.TRAP.FBI.CRD.2004 This part replaces 532188203. Price: $17.99 |
| 179 |
583100601 |
ROD.PIVOT.FBI.CRD This part replaces 532188202. Price: $17.99 |
| 184 |
532174662 |
BRACKET.ACTUATOR.BAGGER.SRD Price: $4.99 |
| 185 |
532181101 |
Price: Call Us |
| 186 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532160793. Price: $5.99 |
| 187 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 188 |
819061216 |
WASHER Price: $3.99 |
| 189 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 190 |
596039001 |
Screws This part replaces 871081010. Price: $2.99 |
| 198 |
532168937 |
NUT Price: $2.99 |
| 205 |
596564001 |
Bolts This part replaces 817490608. Price: $2.99 |
| 207 |
817670508 |
SCREW, 5/16-18 X 1/2 Price: $7.99 |
| 208 |
817670608 |
SCREW 3/8-16X1/2 Price: $3.99 |
| 209 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 213 |
532441345 |
SKIRT.SIDE.HUSQVARNA.LT.LEFT This part replaces 532411077. Price: $11.99 |
| 214 |
532406668 |
SKIRT.SIDE.HUSQVARNA.LT.RH.GRE This part replaces 532411076. Price: $11.99 |
| 216 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 256 |
532181361 |
COVER FENDER CRD Price: $3.99 |
| 258 |
532406663 |
LENS.HUSQVARNA LT.RH This part replaces 532411078. Price: $14.99 |
| 259 |
532406664 |
LENS.HUSQVARNA LT.LH This part replaces 532411079. Price: $14.99 |
| 265 |
583146701 |
SEAL.SIDE.RH.BAGGER.CRD This part replaces 532185704. Price: $17.99 |
| 266 |
583146601 |
SIDE.SEAL.LH.BAGGER.CRD This part replaces 532185703. Price: $17.99 |
| 272 |
532406670 |
VENT SIDE HOOD This part replaces 532411075. Price: $5.99 |
| 273 |
532406671 |
VENT SIDE HOOD This part replaces 532411074. Price: $8.99 |
| 278 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 295 |
532411768 |
NEEDS DESCRIPTION Price: Call Us |
| 296 |
532407881 |
TRIM.HUSQ LT.668 This part replaces 532411119. Price: $19.99 |
| 298 |
532110452 |
NUT PUSH M Price: $2.99 |
| 299 |
532430771 |
LOGO.HUSQ.GT.LT.CROWN.H This part replaces 532405012. Price: $5.99 |
| 305 |
532406665 |
INSERT REFLECTIVE Price: $6.99 |
| 306 |
532415600 |
NEEDS DESCRIPTION Price: Call Us |
| 307 |
532425125 |
Price: Call Us |
| 309 |
596136001 |
Bolts This part replaces 872110606. Price: $3.99 |
