| Ref | Part Number | Description |
|---|
| 1 |
539102075 |
TRANSMISSION CASE Price: $119.60 |
| 1 |
60-6230 |
SCREW-HH Price: $4.80 |
| 2 |
539100371 |
TRANSMISSION COVER Price: $83.34 |
| 2 |
60-6200 |
ADAPTER Price: $537.89 |
| 3 |
539102179 |
OUTPUT & BRAKE SHAFT Price: $24.99 |
| 3 |
70-1240 |
PLUG ASM Price: $51.46 |
| 4 |
539102077 |
SPUR GEAR (27 TEETH) Price: $71.69 |
| 5 |
539100377 |
SPUR GEAR (30 TEETH) Price: $43.35 |
| 5 |
99-8708 |
O-RING This part replaces 60-6180. Price: $21.71 |
| 6 |
539102078 |
SPUR GEAR (32 TEETH) Price: $78.05 |
| 6 |
63-4390 |
BEARING-NEEDLE Price: $51.67 |
| 7 |
539100376 |
SPUR GEAR (35 TEETH) Price: $53.70 |
| 7 |
60-6350 |
DISCONTINUED Price: Call Us |
| 8 |
33-4970 |
DISCONTINUED Price: Call Us |
| 8 |
539102079 |
SPUR GEAR (37 TEETH) Price: $103.11 |
| 9 |
539977561 |
SHIFT COLLAR Price: $14.97 |
| 9 |
60-6040 |
DISCONTINUED Price: Call Us |
| 10 |
539977562 |
SPROCKET (18 TEETH) Price: $25.44 |
| 10 |
60-6130 |
GASKET Price: $19.03 |
| 11 |
539977563 |
SPROCKET (9 TEETH) Price: $24.99 |
| 11 |
95-6050 |
PIN-DOWEL This part replaces 60-6370. Price: $2.59 |
| 12 |
539977564 |
COUNTERSHAFT Price: $120.63 |
| 12 |
60-6030 |
KIT Price: $1,481.34 |
| 13 |
539977565 |
GEAR, BEVEL (42 TEETH) Price: $128.05 |
| 13 |
60-6310 |
KEY Price: $8.97 |
| 14 |
539102080 |
SPUR GEAR (12 TEETH) Price: $28.95 |
| 14 |
60-6020 |
CAMPLATE Price: $784.96 |
| 15 |
539102081 |
SPUR GEAR (15 TEETH) Price: $28.97 |
| 15 |
60-6120 |
COVER-SEAL Price: $17.87 |
| 16 |
104-4861 |
SEAL-SHAFT This part replaces 42-2720. Price: $28.44 |
| 16 |
539100382 |
SPUR GEAR (20 TEETH) Price: $70.31 |
| 17 |
539102082 |
SPUR GEAR (23 TEETH) Price: $99.26 |
| 17 |
60-6250 |
WASHER Price: $9.70 |
| 18 |
539977571 |
INPUT SHAFT Price: $49.99 |
| 18 |
60-6110 |
BEARING Price: $47.19 |
| 19 |
539100372 |
INPUT BEVEL PINION Price: $56.10 |
| 19 |
60-6000 |
HOUSING Price: $924.77 |
| 20 |
539102083 |
SPUR GEAR (18 TEETH) Price: $87.24 |
| 20 |
60-5990 |
RACE Price: $51.48 |
| 21 |
60-6190 |
O-RING Price: $3.76 |
| 22 |
60-6210 |
COVER Price: $12.31 |
| 23 |
539100374 |
THRUST BEARING Price: $11.66 |
| 23 |
60-6010 |
COVER-TRUNNION Price: $11.26 |
| 24 |
60-6330 |
SCREW Price: $6.91 |
| 25 |
76-7010 |
RING-RETAINING This part replaces 60-6260. Price: $3.66 |
| 26 |
105-3331 |
SEAL-SHAFT This part replaces 60-6300. Price: $35.63 |
| 27 |
539977573 |
BUSHING, FLANGED Price: $14.99 |
| 27 |
60-6240 |
WASHER Price: $15.20 |
| 28 |
539977574 |
CHAIN, ROLLER #41 24 LINK Price: $35.98 |
| 28 |
60-6270 |
RING Price: $2.40 |
| 29 |
539977575 |
THRUST WASHER Price: $2.99 |
| 29 |
76-6950 |
RACE-THRUST This part replaces 60-6160. Price: $25.65 |
| 30 |
539977592 |
NEEDLE BEARING Price: $69.99 |
| 30 |
76-6960 |
BEARING-THRUST This part replaces 60-6170. Price: $23.23 |
| 31 |
539977576 |
NEEDLE BEARING Price: $74.99 |
| 31 |
60-6140 |
SHAFT Price: $420.62 |
| 32 |
539977577 |
RETAINING RING Price: $2.26 |
| 32 |
68-6460 |
RELIEF VALVE KIT Price: $545.19 |
| 33 |
539102084 |
WASHER, THRUST Price: $2.64 |
| 33 |
60-5980 |
O-RING Price: $1.95 |
| 34 |
539977579 |
RETAINING RING Price: $2.99 |
| 35 |
539102180 |
SHIFT ROD & FORK Price: $32.34 |
| 35 |
60-6320 |
KEY Price: $5.45 |
| 36 |
539977581 |
W-FLANGED HEX HD THREADFOR Price: $4.69 |
| 36 |
60-6220 |
SCREW-HH Price: $5.33 |
| 37 |
539977582 |
KEY Price: $24.70 |
| 37 |
60-6060 |
CARTRIDGE Price: $31.94 |
| 38 |
60-6080 |
RING Price: $1.46 |
| 39 |
60-6090 |
SPRING Price: $8.73 |
| 40 |
539977583 |
STEEL BALL 5/16" Price: $1.91 |
| 40 |
60-6070 |
POPPET Price: $15.52 |
| 41 |
539977584 |
SET SCREW 3/8-16 X 3/8" Price: $3.03 |
| 42 |
33-4990 |
POPPET Price: $11.08 |
| 42 |
539977585 |
SPRING Price: $2.59 |
| 43 |
39-2140 |
SPRING Price: $24.34 |
| 43 |
539977586 |
WASHER THRUST Price: $3.43 |
| 44 |
39-2130 |
RETAINER-SPRING Price: $23.51 |
| 44 |
539977587 |
O RING Price: $4.54 |
| 45 |
237-114 |
DISCONTINUED Price: Call Us |
| 45 |
539100148 |
SWITCH, TRANS Price: $34.99 |
| 46 |
539100388 |
SEAL, SQUARE CUT Price: $1.91 |
| 46 |
60-5950 |
WASHER Price: $11.55 |
| 47 |
60-6150 |
BEARING Price: $37.91 |
| 48 |
60-6050 |
BEARING Price: $50.76 |
