| Ref | Part Number | Description |
|---|
| 1 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 1 |
539109660 |
DRAW LATCH Price: $13.99 |
| 1 |
725-3216 |
WIRE HARNESS Not Available Price: |
| 2 |
539110740 |
RIVET, BLIND, 5/32 DIA Price: $2.99 |
| 2 |
925-3161A |
Bulb, Head Lamp This part replaces 759-3693. Price: $49.01 |
| 3 |
581724301 |
DECAL.DECK.6MIL.EURO.NOSTEP This part replaces 539105743. Price: $3.99 |
| 3 |
725-3185 |
HARNESS-INDICATOR Not Available Price: |
| 4 |
539105744 |
DECAL, BELT DRIVE Price: $5.99 |
| 4 |
925-1365 |
Bulb, Indicator This part replaces 725-1365. Price: $9.56 |
| 4 |
98-0666 |
DISCONTINUED Price: Call Us |
| 5 |
539111270 |
PIN Price: $7.99 |
| 5 |
925-3159 |
HOUR METER Not Available This part replaces 725-3159. Price: |
| 6 |
539111264 |
BLOWER DECK PLATE WLDMT, 52 Price: $219.99 |
| 6 |
710-0936 |
SCREW #6-20 x .625 Not Available Price: |
| 7 |
725-3066 |
SWITCH Not Available Price: |
| 7 |
98-0664 |
HEAD Price: $83.64 |
| 8 |
539111273 |
BELT SHIELD ASSY 52" Price: $179.99 |
| 8 |
712-3052 |
LOCK NUT #4-40 Not Available Price: |
| 9 |
539112138 |
HCS, 7/16-20 X 2 1/2, GR8 Price: $32.99 |
| 9 |
711-3259 |
SCREW-SWITCH Not Available Price: |
| 10 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 10 |
925-3163 |
Switch, Ignition This part replaces 725-3163. Price: $44.93 |
| 11 |
539102563 |
LANYARD Price: $7.99 |
| 11 |
712-3013 |
NUT-IGNITION SWITCH Not Available Price: |
| 11 |
98-0665 |
PISTON Price: $77.53 |
| 12 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
| 12 |
925-0201 |
Key This part replaces 759-3476A. Price: $8.70 |
| 13 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 13 |
925-0893 |
Switch, PTO This part replaces 725-0893. Price: $72.43 |
| 14 |
32152-10 |
LOCKNUT This part replaces 43-5130. Price: $0.81 |
| 14 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539108120. Price: $1.99 |
| 14 |
712-3014 |
HEX NUT 1/2-27 x .100 THK Not Available Price: |
| 15 |
539111306 |
BELT Price: $19.99 |
| 15 |
925-3164A |
Switch, Interlock This part replaces 725-3164. Price: $37.67 |
| 16 |
735-3036 |
BOOT-SWITCH Not Available Price: |
| 16 |
82-5740 |
NUT-JAM This part replaces 69-1980. Price: $29.95 |
| 17 |
82-5730-01 |
END-ROD, TIE This part replaces 69-1970. Price: $310.82 |
| 17 |
925-3166 |
Switch, Snap Mount Normally Closed (Grey) This part replaces 725-3166. Price: $15.61 |
| 18 |
32121-34 |
PIN-ROLL Price: $1.31 |
| 18 |
925-3167 |
Switch, Snap Mount Normally Open (Black) This part replaces 725-3167. Price: $13.53 |
| 19 |
725-3019 |
CABLE ASSEMBLY-TAIL LAMP Not Available Price: |
| 20 |
725-3020 |
BULB Not Available Price: |
| 21 |
725-3018 |
Lens Assy, Tail Light Price: Call Us |
| 539111240 |
BLOWER |
DECK PLATE WLDMNT, 61" Price: $399.99 539111240 |
| 539111257 |
61 |
LNG DBL HEX STK PULLEY Price: $89.99 539111257 |
| 539111274 |
BELT |
SHIELD ASSY 61" Price: $179.99 539111274 |
