| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 2 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 2 |
62-7240 |
DISCONTINUED Price: Call Us |
| 3 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 5 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 5 |
532154734 |
SCREW, SHIFT LEVER Price: $2.66 |
| 6 |
532110111 |
LEVER ASM CRT Price: $11.99 |
| 6 |
93-6912 |
DISCONTINUED Price: Call Us |
| 7 |
283-75 |
PIN-CLEVIS Price: $1.56 |
| 7 |
872110404 |
BOLT Price: $7.99 |
| 8 |
532008700 |
PANEL.INDICATOR.SHIFT.BLACK Price: $3.99 |
| 9 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 9 |
532170488 |
SCREW.HEX.WSH.SLT.#10-24X.50 Price: $2.99 |
| 10 |
532009484 |
CONDUIT.CLIP.PLATED Price: $4.99 |
| 10 |
92-1818-01 |
ARM-SPRING, TENSION This part replaces 92-1818. Price: $13.39 |
| 11 |
323-9 |
SCREW-HH Price: $1.29 |
| 11 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
| 12 |
32144-109 |
SCREW-THD Price: $1.29 |
| 12 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 13 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 13 |
823230506 |
SET SCREW Price: $2.99 |
| 14 |
532008382 |
SPACER, SPLIT Price: $2.38 |
| 14 |
93-6893 |
PIN-PIVOT, RAM Price: $49.13 |
| 15 |
596204101 |
WASHER 11/32 X 11/16 X 14 GA T This part replaces 819111116. Price: $2.99 |
| 15 |
92-1812 |
SHAFT-PIVOT, LIFT Price: $51.90 |
| 16 |
532145102 |
SHEAVE, TRANSMISSION Price: $59.99 |
| 17 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 17 |
596436301 |
Nuts This part replaces 873220500. Price: $2.99 |
| 18 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 18 |
532008381 |
SPACER Price: $2.99 |
| 19 |
812000028 |
RETAINING RING LT Price: $1.99 |
| 19 |
94-5009 |
HOSE ASM Price: $102.32 |
| 20 |
94-5008 |
HOSE ASM Price: $102.26 |
| 21 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 22 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 23 |
532005015 |
TIRE.16X4-8.CHEVRON.TILLER Price: $99.99 |
| 23 |
532065139 |
VALVE STEM LT This part replaces 532124718. Price: $5.99 |
| 23 |
532128952 |
RIM ASM.2.75 X 8.00.WHITE This part replaces 532124366. Price: $89.99 |
| 23 |
93-6869 |
HYD CYLINDER ASM Price: $638.61 |
| 24 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 24 |
532004929 |
RIVET TI Price: $5.99 |
| 25 |
532004921 |
COTTER PIN This part replaces 532124961. Price: $4.99 |
| 26 |
583641801 |
GUARD.BELT This part replaces 532145518. Price: $23.99 |
| 26 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 27 |
532138399 |
BELT, DRIVE Price: $44.99 |
| 28 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 28 |
532104679 |
PULLEY-IDLER TI Price: $14.99 |
| 29 |
812000032 |
KLIP RING Price: $3.99 |
| 29 |
93-6926 |
PIN-CLEVIS Price: $33.72 |
| 30 |
322-4 |
SCREW-HH Price: $0.35 |
| 30 |
584289401 |
BRACKET.IDLER.ASM.SHORT This part replaces 532159229. Price: $12.99 |
| 31 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 32 |
322-26 |
SCREW-HH Price: $2.36 |
| 32 |
532139401 |
SHAFT, IDLER ARM Price: $12.99 |
| 33 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 34 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 35 |
94-3635 |
CENTER LIFT ARM ASM Price: $280.94 |
| 36 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 37 |
532004368 |
SHEAVE, ENGINE Price: $13.99 |
| 37 |
99-2338 |
SHAFT-PIVOT Price: $101.09 |
| 38 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 39 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 39 |
532140062 |
CAP.PLUNGER.BLACK Price: $4.99 |
| 40 |
237-78 |
O-RING Price: $3.85 |
| 41 |
237-21 |
O-RING Price: $0.70 |
| 42 |
532106160 |
O-RING TI Price: $3.99 |
| 42 |
98-3445 |
SPACER Price: $6.02 |
| 43 |
532069180 |
LOCKNUT Price: $2.99 |
| 43 |
98-3446 |
PLATE-REINFORCEMENT Price: $11.38 |
| 44 |
323-4 |
SCREW-HH Price: $1.02 |
| 47 |
532004914 |
KEY, SQUARE Price: $2.99 |
| 48 |
532157486 |
SPACER Price: $2.99 |
| 50 |
596040101 |
Washers This part replaces 819171616. Price: $2.99 |
| 54 |
532104214 |
NUT TI Price: $3.99 |
| 57 |
874770844 |
Bolt, Hex Head 1/2-20 x 2-3/4 Price: $2.99 |
