| Ref | Part Number | Description |
|---|
| 1 |
127-3071 |
WATER PUMP ASM Price: $827.54 |
| 1 |
532170803 |
CONTROL, THROTTLE Price: $24.99 |
| 2 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 3 |
125-6998 |
GASKET Price: $12.33 |
| 4 |
125-6999 |
PLATE Price: $58.91 |
| 4 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 5 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 6 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 8 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 9 |
127-3017 |
JOINT Price: $71.31 |
| 10 |
125-7123 |
PLUG Price: $9.86 |
| 10 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532162797. Price: $11.99 |
| 11 |
127-3175 |
PLUG Price: $2.87 |
| 12 |
125-7195 |
PLUG Price: $2.71 |
| 13 |
125-7234 |
SCREW Price: $2.32 |
| 13 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 14 |
125-7047 |
GASKET Price: $5.13 |
| 14 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 15 |
125-6986 |
JOINT Price: $24.66 |
| 16 |
125-7048 |
O-RING Price: $2.87 |
| 17 |
125-6978 |
GASKET Price: $2.00 |
| 17 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 18 |
125-7192 |
GASKET Price: $1.14 |
| 19 |
93-0362 |
BOLT Price: $3.89 |
| 20 |
125-7214 |
BOLT Price: $3.77 |
| 21 |
125-7219 |
BOLT Price: $4.58 |
| 22 |
125-7222 |
BOLT Price: $4.99 |
| 23 |
125-7039 |
V-PULLEY Price: $23.56 |
| 23 |
531150701 |
SERVICE KIT SHIELD SHIELD.BROW This part replaces 532169837. Price: $19.99 |
| 24 |
127-2998 |
V-BELT Price: $20.88 |
| 25 |
125-7206 |
BOLT Price: $1.97 |
| 25 |
532145996 |
CONTROL, CHOKE Price: $19.99 |
| 26 |
125-7029 |
THERMOSTAT Price: $56.77 |
| 26 |
873920600 |
Nut Keps 3/8 - 24 UNF Price: $3.99 |
| 27 |
125-7026 |
GASKET Price: $2.90 |
| 28 |
125-7034 |
COVER Price: $78.09 |
| 29 |
125-7110 |
GASKET Price: $3.76 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
125-7594 |
BOLT Price: $3.00 |
| 31 |
125-6953 |
PLUG Price: $7.59 |
| 32 |
125-7124 |
SENSOR-THERMOSTAT, CW Price: $96.15 |
| 32 |
532179124 |
FUEL CAP This part replaces 532181803. Price: $29.99 |
| 33 |
125-6979 |
GASKET Price: $2.55 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 34 |
125-7176 |
WASHER-SEAL Price: $7.31 |
| 35 |
127-3017 |
JOINT Price: $71.31 |
| 36 |
127-3072 |
WATER IN PIPE ASM Price: $51.67 |
| 37 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 38 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 38 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 40 |
127-3115 |
WATER OUT PIPE ASM Price: $21.26 |
| 41 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 43 |
127-3116 |
WATER OUT PIPE ASM Price: $47.67 |
| 44 |
127-3020 |
CLIP-HOSE Price: $2.92 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 47 |
127-3117 |
PIPE-OUT, CW Price: Call Us |
| 72 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 112 |
532003645 |
BUSHING OUTLET T This part replaces 532124952. Price: $3.99 |
