| Ref | Part Number | Description |
|---|
| 1 |
496414 |
CYLINDER ASSY Price: Call Us |
| 2 |
399265 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 3 |
391086 |
SEAL, OIL Price: Call Us |
| 5 |
494240 |
HEAD, CYLINDER Price: Call Us |
| 7 |
271866 |
GASKET, CYLINDER HEAD Price: Call Us |
| 8 |
495735 |
BREATHER ASSY Price: Call Us |
| 9 |
27803 |
GASKET, VALVE COVER Price: Call Us |
| 10 |
94621 |
SCREW, STEMS Price: Call Us |
| 11 |
280100 |
TUBE, BREATHER Price: Call Us |
| 12 |
271916 |
GASKET, CRANKCASE COVER 1/64" Price: Call Us |
| 13 |
94622 |
SCREW, CYLINDER HEAD 3" Price: Call Us |
| 15 |
94239 |
PLUG, OIL DRAIN Price: Call Us |
| 16 |
495162 |
CRANKSHAFT Price: Call Us |
| 18 |
494238 |
BASE, ENGINE Price: Call Us |
| 20 |
291675 |
SEAL, OIL Price: Call Us |
| 22 |
94624 |
SCREW, SEMS, BASE MOUNTING Price: Call Us |
| 23 |
492326 |
FLYWHEEL & RING GEAR ASSY, MAGNETO Price: Call Us |
| 24 |
222698 |
KEY, FLYWHEEL Price: Call Us |
| 24 |
260924 |
LOCK, PISTON PIN Price: Call Us |
| 25 |
391285 |
PISTON ASSEMBLY, STANDARD Price: Call Us |
| 26 |
391780 |
RING SET, PISTON, STANDARD Price: Call Us |
| 28 |
299691 |
PIN ASSEMBLY, PISTON, STANDARD Price: Call Us |
| 29 |
490348 |
ROD ASSEMBLY, CONNECTING Price: Call Us |
| 32 |
94671 |
SCREW, CONNECTING ROD Price: Call Us |
| 33 |
262246 |
VALVE, EXHAUST Price: Call Us |
| 34 |
262247 |
VALVE, INTAKE Price: Call Us |
| 35 |
65906 |
SPRING, INTAKE VALVE Price: Call Us |
| 36 |
26828 |
SPRING, EXHAUST VALVE Price: Call Us |
| 37 |
224502 |
GUARD, FLYWHEEL Price: Call Us |
| 40 |
221596 |
RETAINER, INTAKE VALVE Price: Call Us |
| 41 |
292260 |
RETAINER, EXHAUST VALVE Price: Call Us |
| 42 |
494553 |
KEEPER VALVE Price: Call Us |
| 45 |
262248 |
TAPPET-VALVE Price: Call Us |
| 46 |
212897 |
GEAR, CAM Price: Call Us |
| 51 |
272465 |
GASKET, CARBURETOR (CARBURETOR TO ELBOW) Price: Call Us |
| 52 |
270872 |
GASKET, CARBURETOR Price: Call Us |
| 53 |
94637 |
STUD, CARBURETOR MOUNTING Price: Call Us |
| 75 |
224061 |
WASHER, SPRING Price: Call Us |
| 78 |
94626 |
SCREW, SEMS Price: Call Us |
| 95 |
94098 |
SCREW, THROTTLE Price: Call Us |
| 98 |
495800 |
SCREW, IDLE SPEED Price: Call Us |
| 104 |
231789 |
PIN, FLOAT HINGE Price: Call Us |
| 105 |
231855 |
VALVE ASSY, INLET NEEDLE Price: Call Us |
| 106 |
231854 |
INLET VALVE SEAT Price: Call Us |
| 108 |
224540 |
VALVE, CHOKE Price: Call Us |
| 118 |
494383 |
VALVE, NEEDLE Price: Call Us |
| 121 |
495735 |
BREATHER ASSY Price: Call Us |
| 123 |
94616 |
SCREW, ELBOW MOUNTING Price: Call Us |
| 125 |
495706 |
CARBURETOR ASSEMBLY Price: Call Us |
| 130 |
224539 |
VALVE, THROTTLE Price: Call Us |
| 131 |
494379 |
SHAFT & LEVER, THROTTLE Price: Call Us |
| 133 |
494381 |
FLOAT, CARBURETOR Price: Call Us |
| 137 |
281165 |
GASKET, FLOAT BOWL Price: Call Us |
| 138 |
281164 |
WASHER, FLOAT BOWL SCREW Price: Call Us |
| 141 |
495931 |
SHAFT & LEVER, CHOKE Price: Call Us |
| 142 |
494537 |
NOZZLE/JET, CARBURETOR Price: Call Us |
| 147 |
497472 |
PILOT, JET Price: Call Us |
| 164 |
213819 |
ELBOW, INTAKE Price: Call Us |
| 171 |
281051 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 187 |
393815 |
HOSE (CUT TO SUIT) Price: Call Us |
| 188 |
94627 |
SCREW, SEMS 3/4" Price: Call Us |
| 201 |
262767 |
LINK, GOVERNOR Price: Call Us |
| 209 |
260871 |
SPRING, GOVERNOR Price: Call Us |
| 216 |
262766 |
LINK, CHOKE Price: Call Us |
| 219 |
490815 |
GOVERNOR GEAR Price: Call Us |
| 222 |
495611 |
PLATE, GOVERNOR CONTROL Price: Call Us |
| 224 |
94729 |
SCREW, SEMS, HEX HEAD Price: Call Us |
| 225 |
231058 |
CRANK, GOVERNOR Price: Call Us |
| 227 |
493935 |
LEVER ASSY, GOVERNOR Price: Call Us |
| 230 |
94742 |
WASHER, GOVERNOR CRANK, 1/4" I.D. Price: Call Us |
| 232 |
262785 |
SPRING, GOVERNOR LINK Price: Call Us |
| 240 |
394358 |
FILTER, FUEL Price: Call Us |
| 265 |
221535 |
CLAMP Price: Call Us |
| 284 |
94704 |
SCREW, AIR CLEANER Price: Call Us |
| 284A |
94073 |
SCREW, HEX HEAD Price: Call Us |
| 304 |
496319 |
HOUSING, BLOWER Price: Call Us |
| 305 |
94729 |
SCREW, SEMS, HEX HEAD Price: Call Us |
| 306 |
224545 |
SHIELD, CYLINDER Price: Call Us |
| 307 |
94623 |
SCREW, SEMS, CYLINDER SHIELD MTG. Price: Call Us |
| 308 |
491490 |
COVER, CYLINDER HEAD Price: Call Us |
| 309 |
497595 |
MOTOR, STARTING, 12 VOLT Price: Call Us |
| 310 |
497602 |
BOLT, THRU Price: Call Us |
| 311 |
497608 |
BRUSH SET Price: Call Us |
| 333 |
492341 |
ARMATURE, MAGNETO Price: Call Us |
| 334 |
93381 |
SCREW, SEM, ARMATURE MOUNTING Price: Call Us |
| 337 |
802592 |
PLUG, SPARK Price: Call Us |
| 346 |
93705 |
SUB= 69485 Price: Call Us |
| 356 |
494328 |
WIRE, GROUND Price: Call Us |
| 358 |
494241 |
GASKET SET Price: Call Us |
| 363 |
19203 |
PULLER, FLYWHEEL Price: Call Us |
| 383 |
89838 |
WRENCH SPARK PLUG Price: Call Us |
| 423 |
94073 |
SCREW, HEX HEAD Price: Call Us |
| 445 |
493909 |
CARTRIDGE, AIR CLEANER Price: Call Us |
| 455 |
222561 |
CUP, SCREEN MOUNTING Price: Call Us |
| 467 |
493903 |
KNOB, AIR CLEANER Price: Call Us |
| 468 |
222562 |
SCREEN, FLUSH ROTATING Price: Call Us |
| 474 |
393474 |
STATOR, ALTERNATOR, DUAL CIRCUIT Price: Call Us |
| 482 |
93621 |
SCREW, SEMS Price: Call Us |
| 510 |
497606 |
DRIVE, STARTER Price: Call Us |
| 523 |
495230 |
CAP AND DIPSTICK, OIL FILLER Price: Call Us |
| 524 |
68838 |
SEAL, FILLER TUBE Price: Call Us |
| 525 |
496113 |
TUBE, OIL FILLER Price: Call Us |
| 537 |
281106 |
O-RING, AIR CLEANER Price: Call Us |
| 544 |
497603 |
ARMATURE, STARTER Price: Call Us |
| 552 |
231597 |
BUSHING, GOVERNOR CRANK, 1/4" I.D. Price: Call Us |
| 562 |
92613 |
BOLT, GOVERNOR LEVER Price: Call Us |
| 592 |
231082 |
NUT, HEX Price: Call Us |
| 601 |
93053 |
CLAMP, HOSE, GREEN Price: Call Us |
| 611 |
493496 |
ELBOW, FUEL PIPE Price: Call Us |
| 614 |
93306 |
COTTER, HAIR PIN Price: Call Us |
| 615 |
93307 |
RETAINER, E-RING Price: Call Us |
| 618 |
262803 |
SPRING, CHOKE RETURN Price: Call Us |
| 634 |
281168 |
SEAL, CHOKE SHAFT Price: Call Us |
| 634A |
281168 |
SEAL, CHOKE SHAFT Price: Call Us |
| 634B |
398970 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 635 |
66538 |
ELBOW, SPARK PLUG Price: Call Us |
| 646 |
224546 |
BRACE, AIR CLEANER Price: Call Us |
| 657 |
93496 |
SCREW, SEMS Price: Call Us |
| 663 |
94620 |
SCREW, HEX HEAD Price: Call Us |
| 668 |
280848 |
SPACER Price: Call Us |
| 726 |
392134 |
GEAR, RING Price: Call Us |
| 727 |
490324 |
COVER, STARTER Price: Call Us |
| 728 |
94627 |
SCREW, SEMS 3/4" Price: Call Us |
| 729 |
281159 |
CLIP, LEAD WIRE Price: Call Us |
| 729A |
224723 |
RETAINER, WIRE Price: Call Us |
| 741 |
262932 |
GEAR, TIMING Price: Call Us |
| 757 |
213998 |
LINK, COUNTERWEIGHT Price: Call Us |
| 758 |
399891 |
COUNTERWEIGHT ASSY Price: Call Us |
| 759 |
298909 |
PIN ASSY, PISTON, STD Price: Call Us |
| 761 |
94593 |
SCREW, COUNTERWEIGHT Price: Call Us |
| 783 |
280104 |
GEAR, STARTER Price: Call Us |
| 801 |
394856 |
CAP, DRIVE Price: Call Us |
| 802 |
497605 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 803 |
497604 |
HOUSING, STARTER Price: Call Us |
| 842 |
270920 |
SEAL, OIL FILLER CAP Price: Call Us |
| 847 |
496415 |
P/N CONFLICT - CHECK WITH SUPPLIER Price: Call Us |
| 851 |
221798 |
TERMINAL, IGNITION CABLE Price: Call Us |
| 869 |
261463 |
SEAT, INTAKE VALVE, STANDARD Price: Call Us |
| 870 |
213316 |
SEAT, EXHAUST VALVE, STANDARD Price: Call Us |
| 871 |
261961 |
GUIDE, EXHAUST VALVE Price: Call Us |
| 872 |
281104 |
COVER, AIR CLEANER Price: Call Us |
| 875 |
494237 |
BODY, AIR CLEANER Price: Call Us |
| 877 |
393456 |
DIODE & CONNECTOR ASSY Price: Call Us |
| 955 |
94642 |
SCREW, FUEL BOWL Price: Call Us |
| 965 |
94010 |
LOCKNUT, AIR CLEANER MOUNTING Price: Call Us |
| 975 |
494378 |
BOWL ASSEMBLY, CARBURETOR Price: Call Us |
| 977 |
494385 |
CARBURETOR GASKET KIT Price: Call Us |
| 987 |
281166 |
SEAL, THROTTLE SHAFT Price: Call Us |
| 1005 |
280687 |
FAN, FLYWHEEL Price: Call Us |
| 1006 |
224413 |
RETAINER, FAN Price: Call Us |
| 1044 |
94673 |
SCREW, SHOULDER, HEX HEAD Price: Call Us |
| 94196 |
KEY, |
TIMING GEAR Price: Call Us 94196 |
| 231218 |
GUIDE, |
INTAKE VALVE Price: Call Us 231218 |
| 271996 |
GASKET, |
CRANKCASE COVER .009" Price: Call Us 271996 |
| 271997 |
GASKET, |
CRANKCASE COVER .005" Price: Call Us 271997 |
| 391286 |
PIN |
ASSEMBLY, PISTON .005" OVER Price: Call Us 391286 |
| 391287 |
PISTON |
ASSEMBLY Price: Call Us 391287 |
| 391288 |
PISTON |
ASSEMBLY Price: Call Us 391288 |
| 391289 |
PISTON |
ASSEMBLY Price: Call Us 391289 |
| 391781 |
RING |
SET, PISTON .010" OVERSIZE Price: Call Us 391781 |
| 391782 |
RING |
SET, PISTON .020" OVERSIZE Price: Call Us 391782 |
| 391783 |
RING |
SET, PISTON .030" OVERSIZE Price: Call Us 391783 |
| 392331 |
RING |
SET, PISTON, STANDARD SIZE Price: Call Us 392331 |
| 490469 |
ROD |
ASSEMBLY, CONNECTING .020" UNDERSIZE CRANKPIN Price: Call Us 490469 |
| 494241 |
GASKET |
SET Price: Call Us 494241 |
| 494385 |
CARBURETOR |
GASKET KIT Price: Call Us 494385 |
| 494499 |
HIGH |
ALTITUDE KIT Price: Call Us 494499 |
| 495735 |
BREATHER |
ASSY Price: Call Us 495735 |
