| Ref | Part Number | Description |
|---|
| 1 |
29-5590-03 |
BRACKET-PIVOT Price: $23.25 |
| 2 |
40-6230 |
SPRING Price: $37.99 |
| 3 |
100-8003 |
DEFLECTOR/DECAL ASM Price: $207.21 |
| 4 |
104-3646-01 |
COVER-BELT, LH Price: $41.76 |
| 5 |
46-8560 |
SCREW-HHFTF Price: $1.79 |
| 6 |
104-3645-01 |
COVER-BELT, RH Price: $41.76 |
| 7 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 8 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 9 |
133-9289 |
FITTING-WASHOUT This part replaces 95-2747. Price: $3.86 |
| 10 |
46-6290 |
O-RING Price: $2.59 |
| 11 |
95-3270 |
CONNECTOR-HOSE Price: $22.99 |
| 12 |
9335054 |
PIN-HAIR Price: $1.49 |
| 13 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 14 |
88-5570-03 |
LINK-ADJUSTING, HOC Price: $8.71 |
| 15 |
105-3437 |
ROD-HANGER Price: $18.44 |
| 22 |
32128-25 |
NUT-HF Price: $3.19 |
| 23 |
5-4460 |
WASHER-PIVOT Price: $6.19 |
| 24 |
88-4230 |
TRUNNION-HOC Price: $9.21 |
| 25 |
7-0030 |
SCREW-SHOULDER, HH Price: $7.99 |
| 26 |
3229-1 |
BOLT-CARR Price: $3.39 |
| 27 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 28 |
3296-38 |
NUT-LOCK, NI Price: $1.89 |
| 29 |
93-9950-03 |
BAFFLE Price: $94.92 |
| 30 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 31 |
3230-19 |
BOLT-CARR Price: $5.59 |
| 32 |
3230-18 |
SCREW-CARR Price: $4.09 |
| 33 |
3219-4 |
NUT-HEX Price: $2.65 |
| 34 |
283-2 |
PIN-CLEVIS Price: $12.99 |
| 35 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 36 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 37 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 39 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 40 |
93-8010 |
PLATE-GAGE WHEEL Price: $43.82 |
| 41 |
701756 |
WHEEL-GAGE Price: $7.59 |
| 42 |
56-6591 |
SCREW-SHOULDER, HWH Price: $7.99 |
| 43 |
94-1981 |
SPRING-GAGE WHEEL Price: $4.83 |
| 44 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 45 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 46 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 47 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 48 |
3256-4 |
WASHER-FLAT Price: $0.28 |
| 49 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 50 |
3211-15 |
SCREW-HH Price: $7.99 |
