| Ref | Part Number | Description |
|---|
| 1 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 2 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 2 |
53269180 |
Nut, Crownlock #10-24 Price: Call Us |
| 3 |
11-0160 |
ROLLER SHAFT SCREW ASM Price: $28.16 |
| 3 |
532127533 |
SUB= 127533 Price: $11.99 |
| 4 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 4 |
532171061 |
COVER ASM Price: $79.99 |
| 5 |
3220-3 |
NUT-HJ Price: $0.28 |
| 5 |
532126840 |
SUB= 126840 Price: $74.99 |
| 6 |
147-3120 |
BALL JOINT RECEIVER ASM This part replaces 99-1460. Price: $16.35 |
| 6 |
818021008 |
SCREW, SPECIAL #10-14X1/2 Price: $3.99 |
| 7 |
532140572 |
SUB= 140572 Price: $4.99 |
| 8 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $5.99 |
| 9 |
5-1226 |
WASHER Price: $3.90 |
| 9 |
819061216 |
WASHER 3/16X3/4X16 GA Price: $2.69 |
| 10 |
10-8110 |
WASHER-THRUST Price: $1.09 |
| 10 |
532007206 |
SUB= 7206J Price: $3.99 |
| 11 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 11 |
539108086 |
NUT.#10-24 ACORN.ZD This part replaces 532060867. Price: $1.99 |
| 12 |
810071000 |
WASHER, LOCK Price: $2.99 |
| 12 |
HY4486 |
NUT UNF 1/2"NYLOC EXT THIN5/16 This part replaces 283-8. Price: $1.36 |
| 13 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 13 |
532109808 |
SUB= 109808X Price: $2.69 |
| 14 |
105-3822 |
HYD CYLINDER ASM Price: $533.45 |
| 14 |
532002029 |
NUT.WELD.#10-24 This part replaces 532125004. Price: $2.69 |
| 15 |
322-1 |
SCREW-HH Price: $0.22 |
| 15 |
532160793 |
Latch Hook Asm. This part replaces 532130760. Price: $7.99 |
| 16 |
105-3828 |
SPACER Price: $5.10 |
| 16 |
532160793 |
Latch Hook Asm. This part replaces 532130759. Price: $7.99 |
| 17 |
140-5248 |
PIN-PIVOT RAM, WELDED This part replaces 10-6060. Price: $25.64 |
| 18 |
115-3259 |
KIT-SERVICE, PIN This part replaces 10-6110. Price: $39.21 |
| 18 |
532162803 |
CHUTE, LOWER Price: $67.99 |
| 19 |
10-7820 |
PIVOT HINGE ASM Price: $504.57 |
| 20 |
137-9706 |
DECAL-WARNING This part replaces 93-8064. Price: $4.48 |
| 20 |
871081010 |
Screw #10-24 x 5/8 This part replaces 871161010. Price: $3.49 |
| 21 |
136-8484 |
FRAME-PULL, LH This part replaces 104-2054. Price: $382.66 |
| 21 |
532132796 |
SUB= 132796 Price: $2.99 |
| 22 |
138-6311 |
ARM-PULL-ASSEMBLY-LH This part replaces 92-0586. Price: $29.91 |
| 22 |
532133235 |
SUB= 133235 Price: $3.99 |
| 23 |
133-2337 |
ROLLER ASM This part replaces 99-4277. Price: $176.14 |
| 23 |
532132983 |
SUB= 132983 Price: $2.99 |
| 24 |
3290-317 |
WASHER-SPRING Price: $1.40 |
| 24 |
532180925 |
POST.SUPPORT.BAGGER.2BIN This part replaces 532126813. Price: $28.99 |
| 25 |
131-4295 |
PIN-PIVOT This part replaces 10-6090. Price: $51.39 |
| 25 |
532063124 |
SUB= 73690500 Price: $0.99 |
| 26 |
138-6303 |
ARM-PULL-ASSEMBLY-RH This part replaces 92-0585. Price: $29.91 |
| 26 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 27 |
21-8470 |
SHAFT-ROLLER Price: $62.10 |
| 27 |
539976934 |
HCS.5/16-18X3/4 This part replaces 874760512. Price: $1.99 |
| 28 |
532170053 |
BRACKET, MOUNTING Price: $9.99 |
| 28 |
74-3730 |
SPACER-SPINDLE, REAR Price: $5.06 |
| 29 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 29 |
532170165 |
BOLT SHOULDER Price: $2.99 |
| 30 |
532131137 |
SUB= 131137 Price: $6.99 |
| 30 |
83-1690 |
HOSE-HYD Price: $68.48 |
| 31 |
532174083 |
Plug, Tubing End This part replaces 532134496. Price: $3.99 |
| 31 |
63-3850 |
HOSE ASM Price: $83.26 |
| 32 |
532126919 |
SUB= 126919X Price: $59.99 |
| 32 |
94-4548 |
BUMPER-RECESSED Price: $4.68 |
| 33 |
532192786 |
Pin, Hinge This part replaces 532128600. Price: $7.99 |
| 34 |
532127534 |
SUB= 127534 Price: $8.99 |
| 35 |
532183286 |
Container, Top This part replaces 532129585. Price: $17.99 |
| 36 |
532129586 |
SUB= 129586 Price: $62.99 |
| 38 |
532130895 |
SUB= 130895 Price: $3.99 |
| 39 |
532104419 |
SUB= 105070X Price: $16.05 |
| 39 |
532155042 |
STRIP.REINFORCEMENT Price: $11.99 |
