| Ref | Part Number | Description |
|---|
| 1 |
93-7974-03 |
PLATE-BOX, BATTERY This part replaces 93-7974. Price: $87.76 |
| 2 |
33105-030 |
SCREW-HHF Price: $1.56 |
| 3 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 4 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 5 |
33005-00 |
NUT-HF Price: $0.68 |
| 6 |
108-3282 |
HOSE-FUEL This part replaces 92-7522. Price: $36.93 |
| 7 |
66-8121 |
STANDPIPE Price: $23.18 |
| 8 |
46-6550 |
FITTING-ELBOW, 90 DEG Price: $37.39 |
| 9 |
46-6560 |
BUSHING Price: $2.94 |
| 10 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 11 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 12 |
304-46 |
DRAINCOCK Price: $7.55 |
| 13 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 14 |
63-8410 |
WASHER Price: $1.76 |
| 15 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 16 |
105-7949 |
TANK-FUEL This part replaces 92-7422. Price: $768.96 |
| 17 |
62-7650 |
GASKET Price: $4.28 |
| 18 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 19 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 20 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 21 |
110-6184 |
HOSE-FUEL This part replaces 92-7521. Price: $49.59 |
| 23 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 501466901 |
501466901 |
SCREW Price: $7.99 |
| 501468401 |
501468401 |
SPRING Price: $6.99 |
| 501468701 |
501468701 |
SCREW Price: $6.99 |
| 501666101 |
501666101 |
FUEL INLET SCREEN Price: $12.99 |
| 501667801 |
530035121 |
IDLE SCREW SPRING This part replaces 501667801. Price: $2.99 |
| 502102101 |
502102101 |
Pump Cover Price: $3.48 |
| 502102801 |
502102801 |
HI-SPEED NEEDLE Price: $2.31 |
| 502102901 |
502102901 |
LO-SPEED NEEDLE Price: $2.31 |
| 502103001 |
502103001 |
SPACER Price: $11.99 |
| 502103101 |
502103101 |
BUSHING Price: $9.99 |
| 502103201 |
502103201 |
Choke Flap Price: $3.35 |
| 502103501 |
502103501 |
REPAIR KIT DIAPHRAGM SET Price: $19.99 |
| 502114401 |
502114401 |
Throttle Flap Price: $1.03 |
| 502119401 |
502119401 |
CHOKE SHAFT Price: $3.99 |
| 502119601 |
502119601 |
SPRING Price: $0.59 |
| 502119701 |
502119701 |
SPRING Price: $0.99 |
| 502119801 |
502119801 |
CLIPS Price: $7.99 |
| 503082001 |
503082001 |
NIPPLE Price: $4.99 |
| 503108701 |
503584601 |
SCREW This part replaces 503108701. Price: $2.99 |
| 503281320 |
503281320 |
CARBURETOR Price: $89.99 |
| 503563401 |
503563401 |
INLET NEEDLE Price: $14.99 |
| 503570201 |
503570201 |
SHAFT ASS'Y/THROTTLE Price: $3.58 |
| 503574201 |
503574201 |
WELCH PLUG Price: $6.99 |
| 504130608 |
504130608 |
Price: Call Us |
| 504130807 |
504130807 |
PUMP DIAPHRAGM Price: $27.99 |
| 504130906 |
504130906 |
GASKET Price: $9.99 |
| 504210049 |
504210049 |
SPRING, H-NEEDLE Price: $11.99 |
| 504210050 |
530035293 |
NEEDLE SPRING This part replaces 504210050. Price: $2.99 |
| 504350905 |
504350905 |
Spring Price: $0.53 |
| 505313717 |
505313717 |
Price: Call Us |
| 505316754 |
505316754 |
DIAPHRAGM COVER Price: $3.99 |
| 505316782 |
505316782 |
STARTER LEVER Price: $2.99 |
| 505520110 |
505520110 |
GASKET, METERING SIDE Price: $3.99 |
| 505520125 |
505520125 |
FULCRUM PIN Price: $6.99 |
| 505520127 |
505520127 |
LEVER Price: $4.99 |
| 506028001 |
506028001 |
STARTER LEVER Price: $2.99 |
| 506028301 |
506028301 |
WASHER Price: $11.99 |
