| Ref | Part Number | Description |
|---|
| 1 |
13-2670-01 |
SHEAVE This part replaces 13-2670. Price: $1,182.76 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
120-5914-03 |
GUARD-SHEAVE Price: $581.15 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
93-4032 |
SHAFT-JACK Price: $245.00 |
| 4 |
56-6230 |
BEARING-ROLLER Price: $72.34 |
| 5 |
140-2208 |
PULLEY-DRIVE This part replaces 93-4033-01. Price: $163.75 |
| 7 |
114-8417 |
NUT-HF, NI Price: $0.87 |
| 8 |
117-8538-03 |
BRACKET-IDLER ARM Price: $44.63 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 9 |
117-8469-03 |
BRACKET-PULLEY Price: $20.10 |
| 10 |
3-8448 |
WASHER-THRUST Price: $2.58 |
| 11 |
100-7631 |
PULLEY-IDLER Price: $146.29 |
| 12 |
328-25 |
SCREW-HH Price: $4.07 |
| 13 |
3296-51 |
NUT-LOCK, NI Price: $3.23 |
| 14 |
13-2680 |
BUSHING Price: $217.68 |
| 15 |
3232-3 |
BOLT-CARR Price: $2.14 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
68-3220 |
KEY-STOCK Price: $4.60 |
| 17 |
13-3710 |
WASHER Price: $3.05 |
| 18 |
3247-6 |
SCREW-SET Price: $1.02 |
| 20 |
121-2780-03 |
GUARD-LOWER, BELT Price: $142.41 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
321-4 |
SCREW-HH Price: $0.99 |
| 24 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 25 |
323-6 |
SCREW-HH Price: $0.66 |
| 25 |
585555501 |
CABLE.STARTER.8GA.17.5 This part replaces 532412895. Price: $7.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 26 |
93-4034 |
V-BELT Price: $204.67 |
| 27 |
322-7 |
SCREW-HH Price: $0.89 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532198885 |
CABLE.BLACK.18"REAR.BA Price: $17.99 |
| 29 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
117-8506-03 |
MOUNT-GUARD Price: $49.01 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT This part replaces 532411933. Price: $8.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532401098 |
HARNESS IGN. DASH Price: $69.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
532400449 |
HARNESS.IGN.CHASS.TEX.REAR.BAT Price: $32.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532400725. Price: $4.99 |
| 102 |
532404454 |
HARNESS PIGTAIL PCH TEX ROS Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
