| Ref | Part Number | Description |
|---|
| 1 |
532059192 |
VALVE CAP Price: $4.99 |
| 1 |
603-04305 |
THROTTLE TAB ASSEMBLY Not Available This part replaces 603-0711A. Price: |
| 1 |
99-4753 |
DISCONTINUED,ORDER COMPLETE CYLINDER Price: Call Us |
| 2 |
532065139 |
VALVE STEM LT Price: $5.99 |
| 2 |
929-04058 |
DASH HARNESS PANEL Not Available This part replaces 629-04058. Price: |
| 3 |
532106732 |
RIM.ASM.6X4.5.FRONT.SILVER This part replaces 532138336. Price: $79.99 |
| 3 |
631-0076 |
STEERING TILT BOOT ASSEMBLY Not Available Price: |
| 4 |
66-1940 |
PISTON Price: $143.79 |
| 4 |
931-04007B |
DASH PANEL Not Available This part replaces 631-04007B. Price: |
| 5 |
532122073 |
TIRE.15X6-6.TURF.SAVER.FRONT This part replaces 532106222. Price: $59.99 |
| 5 |
703-05132A |
THROTTLE BRACKET Not Available This part replaces 703-05132. Price: |
| 6 |
710-0604A |
Screw, Hex Wash. Hd. Tapp 5/16-18 x .625 Price: $3.96 |
| 7 |
710-0924 |
Screw, Pan Hd., 1/4-20 x .75 Price: $4.02 |
| 7 |
92-6588 |
GLAND Price: $214.46 |
| 8 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .5 GR5 Price: $4.02 |
| 9 |
532138468 |
TIRE.20X8-8.TURF.SAVER Price: $99.99 |
| 9 |
712-0116 |
Nut, Hex Insert Jam Lock, 3/8-24 Price: $3.95 |
| 9 |
99-4754 |
DISCONTINUED,ORDER COMPLETE CYLINDER Price: Call Us |
| 10 |
712-0237 |
Nut, Hex Lock, 5/16-24 Price: $4.37 |
| 11 |
532106108 |
RIM.ASM.8X7.REAR.SILVER This part replaces 532138337. Price: $99.99 |
| 11 |
66-1930 |
LOCKNUT Price: $3.60 |
| 11 |
712-0292 |
Nut, Speed, 1/4-20 Price: $8.97 |
| 12 |
723-3013 |
FRICTION DISC Not Available Price: |
| 13 |
925-04076 |
PTO SWITCH This part replaces 725-04076. Price: $98.15 |
| 14 |
725-2017 |
SWITCH HOLE COVER Not Available Price: |
| 15 |
725-3274 |
SWITCH-HEADLAMP NLAUD Not Available Price: |
| 16 |
925-3277 |
IGNITION SWITCH This part replaces 725-3277. Price: $96.07 |
| 17 |
925-3288 |
GAUGES PANEL Not Available This part replaces 725-3288. Price: |
| 18 |
731-3209 |
STEERING WHEEL Not Available Price: |
| 19 |
731-06459 |
Cover, Steering Wheel This part replaces 731-3210. Price: $18.55 |
| 20 |
731-3298 |
THROTTLE HANDLE Not Available Price: |
| 21 |
731-3344 |
DASH PANEL INSERT Not Available Price: |
| 22 |
931-3372 |
DASH PANEL EXTENSION Not Available This part replaces 731-3372. Price: |
| 23 |
736-0112 |
Washer, Belleville, .531 x 1.62 x .045 Price: $8.48 |
| 24 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 25 |
936-04062 |
FLAT WASHER .344 IDX1.5X.1 Not Available This part replaces 736-04062. Price: |
| 26 |
736-3052 |
Washer, Flat, .406 x 1.0 x .105 Price: $4.02 |
| 27 |
959-3950 |
IGNITION KEY SET OF 2 Not Available This part replaces 759-3950. Price: |
| 28 |
736-04164 |
SPHERICAL WASHER Not Available Price: |
