| Ref | Part Number | Description |
|---|
| 1 |
108-3282 |
HOSE-FUEL This part replaces 92-7522. Price: $36.93 |
| 1 |
169160 |
HOUSING ASM MOWER Price: Call Us |
| 2 |
66-8121 |
STANDPIPE Price: $23.18 |
| 2 |
72140506 |
BOLT Price: Call Us |
| 3 |
104-5228 |
FITTING-ELBOW, 90 DEG Price: $17.50 |
| 3 |
165569 |
BRKT.ASM.S-BAR.CHASSIS Price: Call Us |
| 4 |
169167 |
BRKT BAR SWAY DECK Price: Call Us |
| 4 |
46-6560 |
BUSHING Price: $2.94 |
| 5 |
4939M |
SUB= 85902 Price: Call Us |
| 5 |
93-3102 |
CAP-FUEL Price: $24.02 |
| 6 |
105-7949 |
TANK-FUEL Price: $768.96 |
| 6 |
165557 |
BAR.SWAY.92.CRD Price: Call Us |
| 7 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 8 |
63-8410 |
WASHER Price: $1.76 |
| 8 |
850857 |
BLADE BOLT Price: Call Us |
| 9 |
10030600 |
SUB= 10040600 Price: Call Us |
| 9 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 10 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 10 |
62-7650 |
GASKET Price: $4.28 |
| 11 |
168720 |
BLADE Price: Call Us |
| 11 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 12 |
129895 |
BEARING.BALL Price: Call Us |
| 12 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 13 |
137645 |
SUB= 137646 Price: Call Us |
| 13 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 14 |
110-4102 |
HOSE-FUEL This part replaces 75-4700. Price: $39.17 |
| 14 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 15 |
110485X |
BEARING Price: Call Us |
| 15 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 16 |
168721 |
BLADE Price: Call Us |
| 18 |
72110608 |
BOLT D Price: Call Us |
| 19 |
132827 |
BOLT SHD 5/16-18 Price: Call Us |
| 20 |
165484 |
BOLT.3/8-24X1.25 Price: Call Us |
| 21 |
73680500 |
SUB= 73690500 Price: Call Us |
| 22 |
169165 |
BRKT IDLER SPRT Price: Call Us |
| 23 |
169166 |
BRKT IDLER SPRT Price: Call Us |
| 24 |
169170 |
BRKT SUSPENSION Price: Call Us |
| 25 |
169171 |
BRKT SUSPENSION Price: Call Us |
| 26 |
165237 |
BRACE.SUPT.SUSP.FRT.CRD Price: Call Us |
| 27 |
169172 |
BRKT ASM SUSP Price: Call Us |
| 28 |
169168 |
BRKT ASM SUSP Price: Call Us |
| 31 |
129963 |
WASHER Price: Call Us |
| 32 |
153535 |
PULLEY.MANDREL.42 Price: Call Us |
| 33 |
137266 |
SUB= 139729 Price: Call Us |
| 34 |
169174 |
BRKT GAUGE WHEEL Price: Call Us |
| 35 |
169175 |
BRKT GAUGE WHEEL Price: Call Us |
| 36 |
146763 |
PULLEY.IDLER.4.25 Price: Call Us |
| 37 |
19131316 |
WASHER Price: Call Us |
| 38 |
169851 |
SPACER HUB ARM IDLER Price: Call Us |
| 39 |
72110622 |
BOLT Price: Call Us |
| 40 |
73680600 |
SUB= 73690600 Price: Call Us |
| 44 |
169180 |
COVER MANDREL Price: Call Us |
| 45 |
169179 |
COVER MANDREL Price: Call Us |
| 46 |
137729 |
SCREW.1/4-20X5/8 Price: Call Us |
| 55 |
169849 |
ARM IDLER Price: Call Us |
| 61 |
165945 |
SPRING.TENSION.BELT Price: Call Us |
| 67 |
106932X |
KNOB T(3/8 HOLE) Price: Call Us |
| 68 |
169178 |
HEX-BELT Price: Call Us |
| 69 |
165482 |
SHAFT.ASM.W/LWR.BRG.RH.THD Price: Call Us |
| 116 |
137644 |
BOLT.SHOULDER Price: Call Us |
| 117 |
133957 |
WHEEL GAGE DONUT Price: Call Us |
| 118 |
73930600 |
LOCKNUT Price: Call Us |
| 119 |
19121414 |
WASHER Price: Call Us |
| 124 |
72110612 |
BOLT.3/8-16X1.50 Price: Call Us |
| 128 |
153390 |
WASHER.FELT. Price: Call Us |
| 130 |
72110506 |
SUB= 72270506 Price: Call Us |
| 131 |
165661 |
CHUTE.BAGGER.CRD Price: Call Us |
| 151 |
169670 |
BRKT CLUTCH CABLE Price: Call Us |
| 152 |
170300 |
CABLE CLUTCH CRD SERVICE Price: Call Us |
| 153 |
169674 |
WASHER FLAT Price: Call Us |
| 154 |
169675 |
SPRING RETAINER Price: Call Us |
| 155 |
169671 |
SPRING RETENTION LVR CLUTCH CAB Price: Call Us |
| 156 |
169672 |
SPACER Price: Call Us |
| 157 |
169669 |
ROD.CLUTCH.CABLE.3/8 Price: Call Us |
| 158 |
17720410 |
SCREW LT Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
| 165579 |
MANDREL.ASM.CRD.LH.THREADS |
Price: Call Us 165579 |
