| Ref | Part Number | Description |
|---|
| 1 |
92-7531-03 |
TUBE-PUMP CONTROL This part replaces 92-7531. Price: $139.90 |
| 2 |
3220-3 |
NUT-HJ Price: $0.28 |
| 2 |
503479601 |
SCREW Price: $2.99 |
| 3 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 3 |
544836401 |
PUMP COVER Price: $17.99 |
| 4 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 4 |
503616601 |
GASKET Price: $2.99 |
| 5 |
323-9 |
SCREW-HH Price: $1.29 |
| 5 |
537380201 |
PUMP DIAPHRAGM This part replaces 506396001. Price: $14.99 |
| 6 |
506396501 |
SHAFT Price: $3.99 |
| 6 |
75-3270-03 |
HUB-PIVOT, TRACTION This part replaces 75-3270. Price: $144.73 |
| 7 |
544082201 |
SCREW Price: $2.99 |
| 7 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 8 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 8 |
537177001 |
THROTTLE FLAP Price: $14.99 |
| 9 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 9 |
506397101 |
SHAFT ASSY Price: $14.99 |
| 10 |
323-7 |
SCREW-HH Price: $0.65 |
| 10 |
506397501 |
SPRING Price: $2.08 |
| 11 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 11 |
506395401 |
COLLAR Price: $2.30 |
| 12 |
506396401 |
QUAD RING Price: $6.84 |
| 12 |
92-7608-03 |
BRACKET-SPRING This part replaces 92-7608. Price: $16.86 |
| 13 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 13 |
506397301 |
CHOKE SHAFT Price: $19.99 |
| 14 |
506399001 |
O-RING Price: $11.99 |
| 14 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 15 |
49-6440-03 |
PEDAL-FORWARD This part replaces 49-6440. Price: $84.90 |
| 15 |
503481801 |
SCREW Price: $2.99 |
| 16 |
506397801 |
VALVE Price: $7.99 |
| 16 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 17 |
506397401 |
CHOKE CHAFT Price: $14.99 |
| 17 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 18 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 18 |
503535701 |
STRAINER Price: $3.99 |
| 19 |
506395801 |
GASKET Price: $6.99 |
| 19 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 20 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 20 |
503481101 |
PLUG Price: $3.99 |
| 21 |
233-42 |
KNOB Price: $12.88 |
| 21 |
537012601 |
SPRING Price: $2.99 |
| 22 |
537012501 |
BALL Price: $2.99 |
| 22 |
75-6490 |
LEVER ASM Price: $78.45 |
| 23 |
544836501 |
SPRING Price: $5.99 |
| 23 |
75-6710 |
DECAL - FAST/SLOW Price: $5.87 |
| 23 |
84-3500 |
DECAL - SPEED CONTROL Price: $13.52 |
| 23 |
93-6699 |
DECAL-FAST / SLOW Price: $18.07 |
| 24 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 24 |
506397201 |
SCREW - THROTTLE ADJUST. Price: $7.99 |
| 25 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 25 |
506397001 |
SCREW Price: $14.99 |
| 26 |
32128-20 |
NUT-HF Price: $0.99 |
| 26 |
506396901 |
SCREW Price: $17.99 |
| 27 |
322-3 |
SCREW-HH Price: $0.79 |
| 27 |
537385101 |
SCREW Price: $2.99 |
| 28 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 28 |
506397901 |
WASHER Price: $2.30 |
| 29 |
537385201 |
CLIP Price: $2.99 |
| 29 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 30 |
506399101 |
PLUG Price: $3.99 |
| 30 |
92-7530 |
CABLE-BRAKE, LH Price: $132.98 |
| 31 |
506396101 |
NOZZLE ASSY CHECK VALVE Price: $22.99 |
| 31 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 32 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 32 |
503535601 |
PLUG Price: $3.99 |
| 33 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 33 |
537177801 |
PLUG Price: $3.99 |
| 34 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 34 |
537176201 |
VALVE Price: $12.99 |
| 35 |
537273401 |
SPRING Price: $4.99 |
| 35 |
75-1440-03 |
PEDAL-BRAKE, LH This part replaces 75-1440. Price: $207.74 |
| 36 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 36 |
537176401 |
LEVER Price: $6.99 |
| 37 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 37 |
544082101 |
SCREW Price: $2.99 |
| 38 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 38 |
537020801 |
PIN This part replaces 503480001. Price: $2.99 |
| 39 |
256-42 |
BUSHING Price: $7.03 |
| 39 |
506396201 |
GASKET, METERING Price: $9.99 |
| 40 |
506395701 |
DIAPHRAM ASSY MET. Price: $14.99 |
| 40 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 41 |
32121-11 |
PIN-ROLL Price: $0.47 |
| 41 |
506395501 |
COVER, COMPENSATOR Price: $7.99 |
| 42 |
506395601 |
COVER METERING Price: $11.99 |
| 42 |
92-7610 |
RETAINER-SPRING Price: $26.52 |
| 43 |
506396601 |
SCREW Price: $1.51 |
| 43 |
60-5700 |
SPRING Price: $27.02 |
| 44 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 45 |
92-7609 |
SHAFT-SPRING Price: $62.79 |
| 46 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 47 |
5-0652 |
SPACER Price: $5.35 |
| 48 |
3290-378 |
TIE-CABLE Price: $0.79 |
