| Ref | Part Number | Description |
|---|
| 1 |
98-0649 |
HOSE-HYD Price: $67.35 |
| 2 |
237-22 |
O-RING Price: $2.43 |
| 2 |
532137352 |
MUFFLER.LT.BRIGGS.14HP.IC/OHV Price: $39.99 |
| 3 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 4 |
237-42 |
O-RING Price: $2.78 |
| 5 |
340-82 |
FITTING-ELBOW, 90 DEG Price: $20.57 |
| 6 |
237-21 |
O-RING Price: $0.70 |
| 7 |
83-1350 |
HOSE-HYD Price: $71.15 |
| 8 |
107-9519 |
HYD HOSE ASM This part replaces 98-2151. Price: $83.34 |
| 9 |
107-2577 |
GEAR PUMP KIT - 5 SECTION This part replaces 92-9764. Price: $3,024.03 |
| 9 |
596501502 |
Keepers This part replaces 501832601. Price: $9.99 |
| 10 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 11 |
83-0910 |
HOSE-INLET, PUMP Price: $78.97 |
| 12 |
5-0946 |
KEY-SQUARE Price: $1.76 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
3241-6 |
SCREW-SQH Price: $4.80 |
| 14 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 15 |
125-9249 |
SPACER-COUPLER, RUBBER This part replaces 27-6600. Price: $2.15 |
| 15 |
581289901 |
FUEL.TANK.ASM.NON-EPA Price: $44.99 |
| 16 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 17 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 18 |
322-6 |
SCREW-HH Price: $0.45 |
| 18 |
581075501 |
CAP.2.25'.VENTED.RATCHET.EPA This part replaces 532430220. Price: $22.99 |
| 19 |
3241-7 |
SCREW-SQH This part replaces 3241-2. Price: $3.39 |
| 20 |
10-7070 |
KEY-SQUARE Price: $1.02 |
| 20 |
587242604 |
THROTTLE CABLE This part replaces 587242601. Price: $27.99 |
| 21 |
110-5236 |
HUB-ENGINE This part replaces 27-1960. Price: $30.97 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
27-1970 |
HUB-PUMP Price: $75.91 |
| 23 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 24 |
323-8 |
SCREW-HH Price: $1.20 |
| 25 |
237-80 |
O-RING Price: $6.10 |
| 26 |
340-105 |
FITTING-ELBOW, 90 DEG Price: $39.67 |
| 27 |
237-30 |
O-RING Price: $2.50 |
| 28 |
587044820 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532137040. Price: $9.99 |
| 28 |
98-2150 |
HOSE-HYD Price: $75.17 |
| 29 |
32128-20 |
NUT-HF Price: $0.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 30 |
83-1940 |
DISCONTINUED Price: Call Us |
| 31 |
322-1 |
SCREW-HH Price: $0.22 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 69 |
532272293 |
GASKET.ENG.1.313 ID.TIN PLATED This part replaces 532165291. Price: $8.99 |
| 79 |
596134201 |
Screws This part replaces 532192334. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $5.99 |
| 85 |
501606601 |
BOLT.HEX.7/16-20X3.75.GR5.RED Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 96 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
| 97 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 108 |
587179510 |
COVER ENGINE PULLEY COVER WITH This part replaces 587179502. Price: $69.99 |
