| Ref | Part Number | Description |
|---|
| 1 |
99-6810 |
SCREW-HHF Price: $3.09 |
| 2 |
324-5 |
SCREW-HH Price: $0.54 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 4 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 5 |
340-4 |
FITTING-STRAIGHT Price: $11.58 |
| 6 |
120-8935-03 |
BRACKET-FAN Price: $221.61 |
| 7 |
140-6482 |
HUB-FAN This part replaces 117-2364. Price: $160.95 |
| 8 |
114-3825 |
FAN Price: $353.82 |
| 9 |
340-70 |
NUT-LOCK Price: $2.10 |
| 9 |
532194319 |
KEEPER.BELT.ENGINE.3.25 (3 2) Price: $11.99 |
| 10 |
340-127 |
NUT-BULKHEAD Price: $2.24 |
| 11 |
121-1518 |
SHIM-SUPPORT Price: $5.04 |
| 11 |
532414336 |
KIT.SVC.CLUTCH.ELECTRIC. This part replaces 532179334. Price: $329.99 |
| 12 |
121-1554 |
TUBE-HYD Price: $75.61 |
| 12 |
532402980 |
PULLEY.ENGINE.ENX Price: $49.99 |
| 13 |
121-1555 |
TUBE ASM Price: $62.39 |
| 14 |
121-1553 |
TUBE-HYD Price: $79.36 |
| 15 |
115-8486 |
SCREW-HH Price: $0.68 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
80-6990 |
WASHER-HARDENED Price: $3.06 |
| 17 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 18 |
104-7201 |
NUT-HF Price: $0.69 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 19 |
117-4769 |
HYD MOTOR ASM Price: $932.88 |
| 20 |
340-129 |
FITTING-ELBOW, 90 DEG Price: $99.81 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
596321701 |
Screws This part replaces 532191611. Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 28 |
587044864 |
HOSE 1/4" LOW PERMEATION FUEL This part replaces 532401135. Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 43 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532150280. Price: $2.99 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 70 |
581881101 |
EXHAUST.TUBE.LH.BS/TWIN This part replaces 532159955. Price: $27.99 |
| 71 |
581881001 |
EXHAUST.TUBE.RH.B&S.TWIN.INTEK This part replaces 532160589. Price: $22.99 |
| 79 |
596134202 |
Screws This part replaces 532183906. Price: $2.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN This part replaces 532181654. Price: $14.99 |
| 84 |
817060624 |
SCREW 3/8-16 X 1-1/2 Price: $4.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
