| Ref | Part Number | Description |
|---|
| 1 |
18-7050 |
RH PAD FOOTREST Price: $115.53 |
| 1 |
530015880 |
SCREW Price: $1.99 |
| 2 |
256-155 |
BUSHING-FLANGE Price: $1.76 |
| 2 |
530058982 |
BOLT MUFFLER Price: $1.99 |
| 3 |
27-9410 |
DISCONTINUED Price: Call Us |
| 4 |
2412-37 |
MUFFLER CLAMP Price: $4.21 |
| 4 |
530015953 |
SCREW Price: $1.99 |
| 5 |
32104-60 |
SCREW-HWH Price: $0.68 |
| 5 |
952030249 |
PLUG-SPARK (RCJ-6Y) Price: $3.99 |
| 6 |
233-32 |
DISCONTINUED Price: Call Us |
| 6 |
530012541 |
CYLINDER MACHINED 25CC LO Price: $11.99 |
| 7 |
256-185 |
BUSHING Price: $19.18 |
| 8 |
18-7130 |
DISCONTINUED Price: Call Us |
| 8 |
545154001 |
RING PISTON Price: $1.99 |
| 9 |
22-7320 |
DISCONTINUED Price: Call Us |
| 9 |
530015162 |
WRIST PIN RET. Price: $1.99 |
| 10 |
19-7370 |
DISCONTINUED Price: Call Us |
| 11 |
3217-7 |
NUT-HEX Price: $0.28 |
| 11 |
545145802 |
ASSY CRANKSHAFT This part replaces 530012579. Price: $17.99 |
| 12 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 13 |
32152-2 |
NUT-LOCK, CONE Price: $1.79 |
| 14 |
323-6 |
SCREW-HH Price: $0.66 |
| 14 |
530057547 |
ADAPTOR CARBURETOR Price: $7.99 |
| 15 |
323-11 |
SCREW-HH Price: $1.08 |
| 15 |
530016441 |
SCREW Price: $1.99 |
| 16 |
49-9780 |
FELT STRAP This part replaces 18-6850. Price: $24.45 |
| 17 |
222-8 |
CAP-GAS Price: $65.84 |
| 17 |
530071811 |
KIT CARB ASSY Price: $32.99 |
| 18 |
18-7040 |
DISCONTINUED Price: Call Us |
| 18 |
545077501 |
BASE AIR BOX PP GOLD Price: $7.99 |
| 19 |
17-4730 |
DISCONTINUED Price: Call Us |
| 19 |
530016428 |
SCREW Price: $1.99 |
| 20 |
289-26 |
DISCONTINUED Price: Call Us |
| 20 |
530036575 |
AIR FILTER Price: $1.99 |
| 21 |
224-1 |
DISCONTINUED Price: Call Us |
| 21 |
530057545 |
COVER AIR BOX FE Price: $3.99 |
| 22 |
304-73 |
FITTING-STRAIGHT Price: $12.59 |
| 22 |
545081826 |
Kit - Ignition Module This part replaces 530039229. Price: $32.99 |
| 23 |
18-6870 |
DISCONTINUED Price: Call Us |
| 23 |
530059758 |
SPACER FLYWHEEL Price: $4.99 |
| 24 |
18-7060 |
DISCONTINUED Price: Call Us |
| 24 |
530016357 |
SCREW Price: $1.99 |
| 25 |
530047278 |
LEAD WIRE ASSEMBLY Price: $4.99 |
| 26 |
2412-39 |
CLAMP-R Price: $1.70 |
| 26 |
530016386 |
SCREW Price: $5.99 |
| 27 |
321-8 |
SCREW-HH Price: $0.34 |
| 27 |
530054834 |
HANDLE STARTER BLK Price: $1.99 |
| 28 |
21-5330 |
DISCONTINUED Price: Call Us |
| 28 |
530071798 |
KIT ROPE Price: $3.99 |
| 29 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 29 |
530055122 |
ASSEMBLY CLUTCH Price: $8.99 |
| 30 |
3217-5 |
NUT-HEX Price: $0.25 |
| 30 |
530094189 |
WASHER-CLUTCH Price: $2.99 |
| 31 |
18-7880 |
DISCONTINUED Price: Call Us |
| 31 |
545016004 |
HSG FAN W/EYELET PP GOLD Price: $17.99 |
| 32 |
353-460 |
DISCONTINUED Price: Call Us |
| 32 |
545008014 |
KIT STARTER SPRING This part replaces 545054901. Price: $3.99 |
| 33 |
3217-6 |
NUT-HEX Price: $1.19 |
| 33 |
545050407 |
KIT STARTER PULLEY Price: $11.99 |
| 34 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 34 |
545080601 |
BAFFLE FAN Price: $6.99 |
| 35 |
3272-4 |
PIN-COTTER Price: $0.25 |
| 35 |
530015880 |
SCREW Price: $1.99 |
| 36 |
19-2830 |
REV. LOCKOUT STOP *B Price: $3.53 |
| 36 |
530016463 |
WASHER CLUTCH Price: $1.99 |
| 37 |
3230-10 |
BOLT-CARR Price: $0.50 |
| 37 |
530039243 |
ASSY FLYWHEEL Price: $27.99 |
| 38 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 39 |
18-7940 |
REV LOCKOUT LATCH *B Price: $62.36 |
| 39 |
530015941 |
RETAINING RING Price: $1.99 |
| 40 |
18-7950 |
DISCONTINUED Price: Call Us |
| 40 |
530055728 |
OUTER BEARING Price: $6.99 |
| 41 |
323-10 |
SCREW-HH Price: $0.89 |
| 41 |
530019264 |
SEAL Price: $2.99 |
| 42 |
21-5340 |
DISCONTINUED Price: Call Us |
| 42 |
530032125 |
BEARING Price: $11.99 |
| 43 |
322-3 |
SCREW-HH Price: $0.79 |
| 43 |
530071785 |
PISTON KIT Price: $29.99 |
| 44 |
19-8600 |
DISCONTINUED Price: Call Us |
| 44 |
530049817 |
CONNECTING ROD ASSY This part replaces 530069945. Price: $6.99 |
| 45 |
19-8590 |
DISCONTINUED Price: Call Us |
| 46 |
3256-2 |
WASHER-FLAT Price: $0.39 |
| 47 |
32140-79 |
Screw Price: Call Us |
| 47 |
530016386 |
SCREW Price: $5.99 |
| 48 |
22-7420 |
SHIELD WA *R Price: $198.89 |
| 48 |
530057539 |
SHROUD REAR BLACK Price: $7.99 |
| 49 |
19-8580 |
DISCONTINUE Price: Call Us |
| 49 |
530016445 |
SCREW FUEL TANK RETAINER Price: $1.99 |
| 50 |
237-88 |
GROMMET Price: $2.96 |
| 50 |
581281901 |
Price: Call Us |
| 51 |
3218-4 |
NUT-JAM Price: $0.49 |
| 51 |
578931603 |
FUEL CAP ASSY Price: $3.99 |
| 52 |
18-6650 |
DISCONTINUED Price: Call Us |
| 52 |
581648601 |
KIT LINE CARB .188 Price: $4.99 |
| 53 |
530095646 |
FUEL PICK-UP ASSY Price: $2.99 |
| 53 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 54 |
32121-74 |
DISCONTINUED Price: Call Us |
| 55 |
18-6600 |
DISCONTINUED Price: Call Us |
| 55 |
530150247 |
ASSY CLUTCH DRUM W/ADPT Price: $17.99 |
| 56 |
18-7070 |
DISCONTINUED Price: Call Us |
| 57 |
18-6640 |
DISCONTINUED Price: Call Us |
| 57 |
530016319 |
SCREW Price: $1.99 |
| 58 |
530015772 |
SCREW-10-24 X 1" (TAP.) Price: $1.99 |
| 59 |
530016381 |
SCREW 12-24 X 5/8 Price: $2.99 |
| 60 |
530016382 |
NUT SQUARE 12-24 Price: $2.99 |
