| Ref | Part Number | Description |
|---|
| 1 |
94-9141-01 |
SCREEN Price: $546.46 |
| 2 |
119-8016 |
TOP PANEL ASM This part replaces 94-9135-01. Price: $1,587.76 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $39.99 |
| 3 |
119-6051 |
PANEL-HOPPER, LH This part replaces 94-9129-01. Price: $1,356.99 |
| 5 |
94-9128-01 |
PANEL-FRONT Price: $168.03 |
| 6 |
13-6760 |
DECAL-CAUTION Price: $41.90 |
| 7 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 8 |
3256-27 |
WASHER-FLAT Price: $0.47 |
| 9 |
32128-32 |
NUT-HHF Price: $2.69 |
| 9 |
596501502 |
Keepers This part replaces 532194320. Price: $9.99 |
| 10 |
13-2930 |
DISCONTINUED Price: Call Us |
| 11 |
119-6242 |
PIN-HINGE This part replaces 283-39. Price: $27.18 |
| 12 |
532405097 |
PULLEY.ENGINE.TUFFTORQ Price: $49.99 |
| 13 |
93-4003-01 |
TAILGATE ASM Price: $3,420.04 |
| 14 |
13-7430 |
DECAL-WARNING Price: $67.40 |
| 15 |
3229-7 |
SCREW-CARR Price: $0.87 |
| 15 |
532193499 |
TANK.FUEL.4GAL Price: $69.99 |
| 16 |
13-7340-01 |
STIFFENER-LH Price: $300.82 |
| 18 |
584248702 |
CAP.ASSY.FUEL.3".N-EPA.GRY.498 This part replaces 532194267. Price: $14.99 |
| 18 |
93-4031-01 |
STRAP-HOPPER, TOP Price: $74.75 |
| 19 |
93-4042-01 |
SUPPORT-HOPPER Price: $310.58 |
| 20 |
3256-55 |
WASHER-FLAT Price: $3.69 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $24.99 |
| 21 |
12-8810 |
SPRING-EXTENSION Price: $26.98 |
| 21 |
596321701 |
Screws This part replaces 532416358. Price: $2.99 |
| 22 |
32122-42 |
SCREW Price: $1.69 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 23 |
94-9139-01 |
PANEL-BOTTOM, LH Price: $489.00 |
| 24 |
3296-23 |
NUT-LOCK, NI Price: $0.52 |
| 25 |
13-3710 |
WASHER Price: $3.05 |
| 26 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 27 |
325-6 |
SCREW-HH Price: $1.42 |
| 28 |
587044854 |
HOSE.1/4".LOW.PERM.FUEL.LN.54" This part replaces 532142158. Price: $14.99 |
| 28 |
94-9138-01 |
PANEL-BOTTOM, CENTER Price: $244.33 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 29 |
94-9137-01 |
PANEL-BOTTOM, RH Price: $489.00 |
| 30 |
3250-32 |
SCREW-PPH Price: $0.54 |
| 31 |
93-4030-01 |
STRAP-HOPPER, FRONT Price: $22.13 |
| 32 |
3274-54 |
SCREW-HSH Price: $1.41 |
| 33 |
93-0184 |
DECAL-HOPPER Price: $41.42 |
| 34 |
106-9665 |
TUBE & CAP ASM This part replaces 65-5871. Price: $17.71 |
| 35 |
65-5890 |
CAP-END Price: $8.09 |
| 36 |
2412-102 |
CLAMP-R Price: $6.85 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 38 |
323-6 |
SCREW-HH Price: $0.66 |
| 39 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 40 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 41 |
325-7 |
SCREW-HH Price: $1.53 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers This part replaces 810040700. Price: $2.99 |
| 42 |
93-7708 |
STRIP-SEAL Price: $10.93 |
| 43 |
120-6199 |
HOPPER ASM This part replaces 92-2409. Price: $8,949.33 |
| 45 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532146629. Price: $11.99 |
| 69 |
532178591 |
GASKET, MUFFLER This part replaces 532178084. Price: $4.99 |
| 70 |
532181444 |
EXHAUST TUBE LH KAWI Price: $54.99 |
| 71 |
532181442 |
EXHAUST TUBE RH KAWI Price: $59.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 85 |
501606501 |
BOLT.HEX.7/16-20X4.GR5.1.5BLUE This part replaces 532173937. Price: $2.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 87 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK Price: $4.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
