| Ref | Part Number | Description |
|---|
| 1 |
3234-12 |
SCREW-HHF Price: $0.61 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $149.99 |
| 2 |
69-8890 |
CAP-SPINDLE Price: $13.32 |
| 3 |
32151-10 |
RING-RETAINING Price: $0.81 |
| 4 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 5 |
69-6470 |
BUSHING-CASTOR Price: $5.82 |
| 6 |
82-9850-03 |
AXLE-REAR This part replaces 82-9850. Price: $1,614.33 |
| 7 |
98-4434 |
LH WHEEL SPINDLE ASM This part replaces 69-7370. Price: $631.93 |
| 8 |
532193228 |
BOX.BATTERY.MNT.REAR.L Price: $24.99 |
| 8 |
69-2990 |
STUD-WHEEL Price: $4.85 |
| 9 |
117-8969 |
HUB ASM This part replaces 69-2960. Price: $336.24 |
| 10 |
254-72 |
BEARING-CUP, TAPERED Price: $9.67 |
| 11 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 12 |
58-5570 |
DISCONTINUED Price: Call Us |
| 12 |
69-9880 |
TIRE (23X10.5-12) 6-PLY Price: $189.93 |
| 13 |
23-7270 |
NUT-LUG Price: $10.37 |
| 14 |
217-116 |
WHEEL Price: $258.19 |
| 14 |
58-5590 |
RIM Price: $307.81 |
| 15 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 16 |
69-2970 |
CAP-HUB Price: $20.74 |
| 17 |
32136-5 |
NUT-HEX, SLOTTED Price: $2.71 |
| 18 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 19 |
5108 |
VALVE This part replaces 232-27. Price: $6.29 |
| 20 |
254-107 |
CUP-BEARING, TAPERED Price: $9.93 |
| 21 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 21 |
532400252 |
HARNESS.LIGHT W/4152J BULBS Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 22 |
69-2980 |
SEAL Price: $33.94 |
| 23 |
110-6141-03 |
RH TIE ROD END ASM This part replaces 2116-4. Price: $148.18 |
| 24 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 25 |
2412-7 |
CLAMP ASM Price: $23.32 |
| 25 |
581498001 |
CABLE.BATT.RED.8GA.17 Price: $7.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
110-9719-03 |
TIE ROD ASM This part replaces 82-9260. Price: $380.21 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
583390701 |
CABLE.GROUND.REAR.BATTERY.8GA This part replaces 532421686. Price: $8.99 |
| 29 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
32136-2 |
NUT-SHH Price: $3.55 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
32136-13 |
NUT-SHH Price: $2.85 |
| 32 |
3296-49 |
NUT-LOCK, NI Price: $4.93 |
| 33 |
48-6640 |
BEARING Price: $10.04 |
| 33 |
532411935 |
KEY.CHAIN.BLISTER.PACK.GEN.INT Price: $8.99 |
| 34 |
48-6660 |
WASHER Price: $5.22 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
82-9840 |
DISCONTINUED Price: Call Us |
| 36 |
115-8014 |
CYLINDER-HYDRAULIC This part replaces 77-4800. Price: $1,015.97 |
| 37 |
82-9841 |
DISCONTINUED Price: Call Us |
| 38 |
237-22 |
O-RING Price: $2.43 |
| 39 |
340-97 |
FITTING-ELBOW, 90 DEG Price: $36.21 |
| 40 |
237-78 |
O-RING Price: $3.85 |
| 40 |
581023101 |
HARNESS.TEX.DASH.MAN.REAR BATT Price: $32.99 |
| 41 |
60-3670 |
PIN Price: $12.56 |
| 42 |
82-9210 |
SHAFT-PIVOT Price: $187.73 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 44 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 45 |
106-6895-03 |
BALL JOINT ASM This part replaces 69-9810. Price: $258.08 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532401763. Price: $19.99 |
| 55 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 71 |
581023001 |
HARNESS.TEX.CHSSIS.REAR.BATT Price: $54.99 |
| 79 |
532175242 |
BULB HOLDER ASM. Price: $8.99 |
| 87 |
532197802 |
SWITCH.INTRLCK.CLUTCH. Price: $14.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY Price: $4.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 102 |
581023401 |
HARNESS.PIGTAIL.VARIATOR.SD Price: $14.99 |
| 105 |
532407568 |
REVERSE SWITCH Price: $12.99 |
