| Ref | Part Number | Description |
|---|
| 1 |
140117 |
Seat Price: Call Us |
| 2 |
140551 |
Bracket Pivot Seat 8 720 Price: Call Us |
| 3 |
71110616 |
Bolt Fin Hex 3/8-16unc X 1 Price: Call Us |
| 4 |
115-4523 |
COUPLING-RUBBER This part replaces 44-2230. Price: $52.81 |
| 4 |
19131610 |
Washer 13/32 X 1 X 10 Ga Price: Call Us |
| 5 |
145006 |
Clip Push-In Price: Call Us |
| 5 |
32152-1 |
NUT-LOCK, CONE Price: $1.49 |
| 6 |
71-4411 |
SPACER Price: $2.42 |
| 6 |
73800600 |
Nut Hex w/Ins. 3/8-16 Unc Price: Call Us |
| 7 |
124181X |
Spring Seat Cprsn 2 250 Blk Zi Price: Call Us |
| 7 |
322-8 |
SCREW-HH Price: $1.26 |
| 8 |
17000616 |
Screw 3/8-16 X 1 Price: Call Us |
| 8 |
71-4410 |
SPACER Price: $5.97 |
| 9 |
19131614 |
Washer 13/32 X 1 X 14 Ga. Price: Call Us |
| 9 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 10 |
155925 |
Pan Seat Price: Call Us |
| 10 |
322-10 |
SCREW-HH Price: $0.70 |
| 11 |
166369 |
Knob Seat Price: Call Us |
| 11 |
321-2 |
SCREW-HH Price: $2.79 |
| 12 |
121246X |
Bracket Mounting Switch Price: Call Us |
| 12 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 13 |
121248X |
Bushing Snap Blk Nyl 50 Id Price: Call Us |
| 13 |
54-9290 |
BRACKET-MOUNTING Price: $16.99 |
| 14 |
72050412 |
Bolt Rdhd Sqnk 1/4-20x1-1/2 Price: Call Us |
| 15 |
134300 |
Spacer Split 28x 88 Price: Call Us |
| 15 |
68-8660 |
FITTING-HYD, 90 DEG Price: $181.88 |
| 16 |
121250X |
Spring Cprsn Price: Call Us |
| 16 |
321-4 |
SCREW-HH Price: $0.99 |
| 17 |
123976X |
Nut Lock 1/4 Lge Flg Gr 5 Zinc Price: Call Us |
| 17 |
68-8990 |
HEAD-FILTER Price: $153.83 |
| 18 |
54-9300-03 |
COVER-SHAFT, PUMP Price: $31.70 |
| 19 |
105-0033-03 |
DRIVE SHAFT ASM Price: $63.37 |
| 21 |
171852 |
Bolt Shoulder 5/16-18 Unc Price: Call Us |
| 21 |
23-9740 |
FILTER-OIL, HYDRAULIC Price: $13.14 |
| 22 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 22 |
73800500 |
Nut Hex Lock W/Ins 5/16-18 Price: Call Us |
| 23 |
68-9650 |
HOSE-AXLE Price: $30.32 |
| 24 |
19171912 |
Washer 17/32 X 1-3/16 X 12 Ga. Price: Call Us |
| 24 |
70-2620 |
FITTING-HYD, 90 DEG Price: $116.72 |
| 25 |
353-508 |
PLUG-HH Price: $7.96 |
| 26 |
353-987 |
FITTING-ELBOW, 90 Price: $74.72 |
| 27 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 28 |
323-7 |
SCREW-HH Price: $0.65 |
| 29 |
119-2880 |
TRANSMISSION ASM This part replaces 92-8947. Price: $4,321.31 |
| 30 |
41-8760 |
GASKET Price: $5.99 |
| 31 |
86-7220 |
GEAR-PINION Price: $81.33 |
| 32 |
32120-72 |
RING-SNAP Price: $2.09 |
| 33 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 34 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 35 |
340-99 |
FITTING-HYD, 90 DEG Price: $32.27 |
| 36 |
110-9695 |
HUB-PUMP This part replaces 33-4380. Price: $55.09 |
| 37 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
