TRIMMER ASSEMBLY
Parts (47)
| Ref | Part Number | Description |
|---|---|---|
| 1 | 104-8714 | HOSE REEL FRAME ASM Price: $2,917.61 |
| 1 | 534234500 | Power Cord Price: $3.33 |
| 2 | 104-8715 | CHAINGUARD-REEL, HOSE Price: $180.77 |
| 2 | 534356714 | R.H./L.H. Handle Price: $3.33 |
| 3 | 104-8799 | GUIDE-REEL, HOSE Price: $961.88 |
| 3 | 534193001 | Trigger Switch Price: $3.33 |
| 4 | 534218100 | Bolt Price: $1.99 |
| 5 | 534282605 | Side Handle Price: $12.99 |
| 6 | 534437000 | Wing Nut Price: $3.33 |
| 7 | 534222502 | Upper Tube Price: $5.99 |
| 8 | 534223200 | Lower Tube Price: $3.33 |
| 9 | 534271624 | R.H./L.H. Housing Price: $14.99 |
| 10 | 534454003 | Motor Price: $3.33 |
| 11 | 534487255 | Air Baffle Price: $3.33 |
| 12 | 534404400 | P.C. Bridge Kit Price: $3.33 |
| 13 | 534193800 | Screw Price: $3.33 |
| 14 | 534653000 | Washer Price: $0.99 |
| 15 | 534379645 | Line Cutter Guard Price: $8.99 |
| 16 | 534222400 | Screw Price: $1.99 |
| 17 | 534970001 | Screw Price: $3.33 |
| 18 | 534713000 | Lockwasher Price: $0.99 |
| 19 | 534270100 | Hanger Price: $1.99 |
| 20 | 534162314 | Harness Ass'y. Price: $3.33 |
| 21 | 534193700 | Screw Price: $1.99 |
| 22 | 534487105 | Rear Plate Price: $3.33 |
| 23 | 534228803 | Washer Price: $3.33 |
| 24 | 534246702 | Retaining Ring Price: $1.99 |
| 25 | 534487400 | Wire Retaining Ring Price: $3.33 |
| 26 | 534158602 | Foam Pad Price: $0.60 |
| 27 | 534486805 | Spool & Line Price: $5.88 |
| 28 | 534157401 | Spring Price: $0.99 |
| 29 | 534486465 | Hub Ass'y. Price: $5.99 |
| 30 | 534157600 | Eyelet Price: $1.99 |
| 31 | 534270300 | Cotter Pin Price: $3.33 |
| 32 | 534228703 | Screw Price: $3.33 |
| 33 | 534207101 | Endbell Ass'y. (Drive) Price: $3.33 |
| 34 | 534228800 | Washer Price: $1.99 |
| 35 | 534227001 | Field Ass'y. Price: $24.99 |
| 36 | 534747002 | Retaining Ring Price: $1.99 |
| 37 | 534450400 | Brush Kit (Inc.42,43,44) Price: $12.32 |
| 38 | 534246700 | Retaining Ring Price: $0.99 |
| 39 | 534238900 | Washer Price: $1.99 |
| 40 | 534227501 | Endbell Ass'y. (Brush) Price: $3.33 |
| 41 | 534226000 | Insulator Price: $3.33 |
| 42 | 534227800 | Brush Price: $3.16 |
| 43 | 534228000 | Brush Spring Price: $1.99 |
| 44 | 534227700 | Brush Holder Price: $3.33 |
