| Ref | Part Number | Description |
|---|
| 1 |
114-3988 |
FAN DRIVE ASM This part replaces 74-5520. Price: $342.27 |
| 1 |
532419272 |
Price: $259.99 |
| 2 |
532195161 |
STUD.FASTNER.W/ANTI-ROTATE Price: $3.99 |
| 2 |
75-3780 |
FAN-ENGINE Price: $367.12 |
| 3 |
75-6380 |
SHAFT-FAN Price: $141.82 |
| 3 |
873900500 |
NUT LOCK HEX FLANGE 5/16-18 Price: $2.99 |
| 4 |
104-9312 |
PIN-GROOVED Price: $1.63 |
| 4 |
532417645 |
Price: $2.99 |
| 5 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
| 5 |
98-9313 |
PULLEY-FAN This part replaces 98-9313-03. Price: $18.49 |
| 6 |
104-9259 |
WASHER-THRUST Price: $21.05 |
| 6 |
532418863 |
ARMS.SUSP.MOWER.REAR.SRD Price: $4.99 |
| 7 |
251-318 |
BEARING-BALL Price: $16.40 |
| 8 |
104-0001 |
SPACER Price: $25.45 |
| 8 |
532420252 |
Price: $7.99 |
| 9 |
532199092 |
SPACER.RETAINER Price: $3.99 |
| 9 |
75-4450 |
HUB This part replaces 75-4450-03. Price: $205.03 |
| 10 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 10 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
| 11 |
532137729 |
SCREW.1/4-20X5/8 Price: $2.49 |
| 11 |
67-1630 |
SPACER Price: $28.84 |
| 12 |
323-6 |
SCREW-HH Price: $0.66 |
| 13 |
3230-2 |
BOLT-CARR Price: $0.47 |
| 13 |
872110612 |
BOLT.3/8-16X1.50 Price: $3.99 |
| 14 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 14 |
532173968 |
KEEPER.BELT.IDLER.PLATED This part replaces 532156085. Price: $4.99 |
| 15 |
532146763 |
PULLEY.IDLER.4.25 Price: $14.99 |
| 15 |
98-4530-03 |
SUPPORT-FAN Price: $349.24 |
| 16 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $2.69 |
| 16 |
98-4575-03 |
LEVER-IDLER, FAN Price: $43.57 |
| 17 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 17 |
532400234 |
NUT.FLANGE.LOCK.TOP Price: $3.99 |
| 18 |
532187690 |
WASHER.SPACER.MANDREL Price: $1.99 |
| 18 |
98-9312 |
V-BELT Price: $28.51 |
| 19 |
323-8 |
SCREW-HH Price: $1.20 |
| 19 |
532110485 |
BEARING Price: $7.99 |
| 20 |
532173984 |
SCREW, WASHER HEAD Price: $2.99 |
| 20 |
63-8140 |
PULLEY-IDLER Price: $47.94 |
| 21 |
98-9740 |
BRACKET-FAN, SUPPORT Price: $42.56 |
| 22 |
322-2 |
SCREW-HH Price: $0.69 |
| 22 |
532175820 |
PULLEY.IDLER.FLAT.46.PR.DR. Price: $19.99 |
| 23 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 23 |
817490628 |
SCREW LT Price: $3.99 |
| 24 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 24 |
819132012 |
WASHER Price: $2.99 |
| 25 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 25 |
529311701 |
KEEPER-BELT-BLACK This part replaces 532420253. Price: $2.99 |
| 26 |
532432466 |
This part replaces 532420255. Price: $27.99 |
| 26 |
98-9741 |
BRACKET-MOUNT, FAN Price: $44.53 |
| 27 |
532419271 |
V-BELT.DRIVE.MOWER.30" Price: $39.99 |
| 27 |
98-4561-03 |
SHIELD-ALTERNATOR Price: $56.98 |
| 28 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 29 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 29 |
532420895 |
Price: $2.99 |
| 30 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 31 |
33114-016 |
SCREW-HH Price: $0.27 |
| 32 |
322-4 |
SCREW-HH Price: $0.35 |
| 32 |
532197251 |
SPRING.MOWER.DRIVE.ELECTRIC Price: $5.99 |
| 33 |
532187281 |
HOUSING MANDREL Price: $20.99 |
| 34 |
532192870 |
MANDREL ASM This part replaces 532192872. Price: $30.99 |
| 35 |
532419274 |
BLADE.MOWER.BAGGING.30" Price: $19.99 |
| 36 |
532193003 |
BOLT.WASHER.ASM.7/16-2 Price: $5.99 |
| 38 |
532196539 |
BOLT.SHOULDER Price: $4.99 |
| 42 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 43 |
525568001 |
PULLEY, MANDREL 6.5" BLK This part replaces 532416877. Price: $23.99 |
| 72 |
532417236 |
Price: $48.99 |
| 73 |
532425274 |
Price: $40.99 |
| 74 |
532085902 |
RETAINER SPRING This part replaces 532124670. Price: $1.99 |
| 76 |
532415598 |
PORT.WASHOUT Price: $5.99 |
| 78 |
532422566 |
Price: $5.99 |
| 79 |
532142432 |
SCREW.HI-LO.CONSOLE Price: $3.99 |
| 80 |
532423062 |
PALNUT 1/4 Price: $2.99 |
