| Ref | Part Number | Description |
|---|
| 0 |
632991 |
CARBURETOR Price: $108.30 |
| 1 |
121-4613 |
ARM-HOC, LH Price: $146.18 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532163465. Price: $139.99 |
| 1 |
631776A |
SHAFT & LEV Price: $12.00 |
| 2 |
106-8536 |
LH LIFT ARM ASM Price: $102.16 |
| 2 |
631970 |
RET SPRING Price: $3.00 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
121-4614 |
NUT-HF Price: $2.10 |
| 4 |
107-8107 |
WASHER-WAVE Price: $8.93 |
| 4 |
631184 |
WASHER Price: $1.25 |
| 5 |
106-8482 |
ADJUSTER Price: $30.57 |
| 5 |
631183 |
WASHER Price: $1.25 |
| 6 |
32120-19 |
E-RING Price: $2.27 |
| 6 |
631778 |
SHUTTER Price: $1.20 |
| 7 |
104-4754 |
SPRING-DETENT Price: $23.47 |
| 7 |
650506 |
SCREW Price: $0.87 |
| 8 |
43-5930 |
WASHER-LOCK, SPRING Price: $0.75 |
| 8 |
532176689 |
BOX.BATTERY.FENDER Price: $7.99 |
| 9 |
121-4615 |
SCREW-HH Price: $0.26 |
| 10 |
106-8528 |
SCREW-LOCK Price: $16.17 |
| 10 |
631779 |
SHAFT & LEV Price: $5.16 |
| 11 |
121-4616 |
PIN-GROOVED Price: $1.49 |
| 11 |
631780B |
RET SPRING Price: $1.25 |
| 12 |
121-4617 |
ROD-LIFT Price: $11.77 |
| 12 |
631184 |
WASHER Price: $1.25 |
| 13 |
631183 |
WASHER Price: $1.25 |
| 14 |
631753 |
SHUTTER Price: $1.25 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $11.99 |
| 16 |
632527 |
FUEL FITTING This part replaces 631775. Price: $6.03 |
| 17 |
651025 |
SCREW Price: $1.18 |
| 20 |
632281 |
IDLE SCREW Price: $2.60 |
| 21 |
532175685 |
HARNESS.ASM.LIGHT Price: $17.99 |
| 21 |
630766 |
SPRING Price: $1.25 |
| 22 |
532004152 |
LIGHTBULB Price: $2.99 |
| 22 |
630739 |
WASHER Price: $1.25 |
| 23 |
630740 |
O RING Price: $1.49 |
| 24 |
532004799 |
BATTERY CABLE Price: $6.99 |
| 25 |
532146147 |
CABLE BATTERY Price: $19.99 |
| 25 |
631951 |
FLOAT BOWL Price: $12.35 |
| 26 |
532175158 |
FUSE 20AMP Price: $3.99 |
| 27 |
631024 |
FLOAT SHAFT Price: $1.17 |
| 27 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 532053838. Price: $2.99 |
| 28 |
532122077 |
TIRE.REAR.TS.(23X10.5X12) This part replaces 532004607. Price: $279.99 |
| 28 |
632019A |
FLOAT This part replaces 632019. Price: $5.85 |
| 29 |
532421062 |
SWITCH.SNAPMOUNT.NC This part replaces 532121305. Price: $7.99 |
| 29 |
631028A |
GASKET This part replaces 631028. Price: $1.95 |
| 30 |
532175566 |
IGNITION SWITCH Price: $9.99 |
| 30 |
631021B |
INLET NEEDLE KIT This part replaces 631021. Price: $4.82 |
| 31 |
631022 |
CLIP Price: $1.25 |
| 32 |
27136A |
DRAIN ASSY Price: $5.96 |
| 33 |
27554 |
GASKET Price: $1.05 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $3.99 |
| 40 |
532179720 |
HARNESS.IGNITION Price: $74.99 |
| 40 |
632239 |
POWER SCREW Price: $10.32 |
| 41 |
539990071 |
HCS 1/4-20. This part replaces 871110408. Price: $1.99 |
| 41 |
630740 |
O RING Price: $1.49 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532000719. Price: $4.99 |
| 42 |
630739 |
WASHER Price: $1.25 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532178861. Price: $14.99 |
| 43 |
630738 |
SPRING Price: $1.25 |
| 44 |
27110A |
GASKET Price: $1.45 |
| 47 |
630748 |
WELCH PLUG Price: $1.17 |
| 48 |
532140844 |
ADAPTER.AMMETER Price: $3.99 |
| 48 |
631027 |
WELCH PLUG Price: $1.17 |
| 52 |
532141940 |
WIRE PROTECTION LOOP Price: $3.99 |
