| Ref | Part Number | Description |
|---|
| 1 |
1739687 |
DECAL-OPEI CAUTION Price: $6.36 |
| 2 |
1185574P |
Ball Bearing This part replaces 1185574. Price: $32.02 |
| 3 |
1746869 |
SPACER Price: $17.91 |
| 4 |
1769048099 |
Mower Spindle This part replaces 1765092. Price: $163.09 |
| 5 |
937-0146 |
Grease Fitting This part replaces 1185976. Price: $4.80 |
| 6 |
1765029 |
BLADE SPACER Not Available Price: |
| 7 |
1918880 |
Left Spindle Shaft (long) This part replaces 1766061. Price: $85.50 |
| 8 |
1770962 |
SPINDLE SHAFT (LONG) Not Available Price: |
| 9 |
1765196 |
SCR-HH 1/2-14X1.00 Price: $3.71 |
| 10 |
1765197 |
WASHER-BELLEVILLE Price: $24.18 |
| 11 |
1772303 |
MULCH BLADE 38" DECK Not Available Price: |
| 13 |
1766052 |
ROD (LH) FRO Not Available Price: |
| 14 |
1752554 |
FRONT LIFT ROD END Not Available Price: |
| 15 |
1766051 |
FRONT LIFT ROD (RH) Not Available Price: |
| 16 |
1723478 |
HITCH PIN Not Available Price: |
| 17 |
1763823 |
DECAL-OPEI Price: Call Us |
| 19 |
1739080 |
BELT-V Not Available Price: |
| 20 |
1773601 |
BELT-DRIVE 38" Price: $57.88 |
| 21 |
913-04050 |
Cogged Pulley, 56T This part replaces 1774220. Price: $143.14 |
| 22 |
1771870001 |
SHEAVE ASSEMBLY. DRIVE Not Available This part replaces 1771870. Price: |
| 23 |
736-0322 |
Flat Washer, .450 x 1.25 This part replaces 1736484. Price: $8.42 |
| 24 |
736-0171 |
Lock Washer, 7/16 This part replaces 1100244. Price: $3.86 |
| 25 |
1766984 |
SCREW-FLANGE LOCK Not Available Price: |
| 26 |
1715538 |
BUSHING-NYLINER .5X.5 Not Available Price: |
| 27 |
1186393 |
NUT-HFLK 3/8-16 ZP Price: $2.63 |
| 28 |
1764001 |
IDLER PULLEY Not Available Price: |
| 29 |
710-0347 |
Hex Cap Screw 3/8-16 x 1.75 This part replaces 1100086. Price: $4.39 |
| 30 |
1763219 |
SCR-SHLDR 3/8-16 Price: $8.93 |
| 31 |
1770963 |
ASSM-IDLER ARM Price: Call Us |
| 32 |
1100044 |
SCR-HHC 5/16-18X.75 GR 5 ZP Price: $3.76 |
| 33 |
1769768001 |
BRACKET-BELT TENSION Not Available Price: |
| 34 |
1749911 |
PULLEY Not Available Price: |
| 35 |
1719367 |
CLEVIS PIN Not Available Price: |
| 36 |
712-3000 |
Hex Lock Nut, 3/8-16 This part replaces 1733398. Price: $3.90 |
| 37 |
1762138 |
WHEEL ANTISCALP NLAUD Not Available Price: |
| 38 |
1765899 |
SPRING Not Available Price: |
| 39 |
1185649 |
RETAINING RING Not Available Price: |
| 40 |
1732499 |
NUT-TOP/LK 5/16-18 ZP Price: $3.49 |
| 42 |
1766342 |
SPACER GAGE WHEEL Not Available Price: |
| 43 |
1766189001 |
WHEEL GAGE ADJ. Not Available Price: |
| 44 |
1112587 |
PIN-CLEVIS .375 X .937 ZP Price: $4.29 |
| 45 |
714-0145 |
Click Pin This part replaces 1703011. Price: $4.42 |
| 46 |
753-04856A |
Deck Wheel, 5" Dia. This part replaces 1766087. Price: $18.23 |
| 47 |
710-3085 |
SCREW 3/8-16 x 3.50 GR5 This part replaces 1111615. Price: $3.90 |
| 48 |
1768540 |
DECAL-BELT DRIVE Price: Call Us |
| 49 |
736-3052 |
Flat Washer, .406 x 1.0 x .105 This part replaces 1100256. Price: $4.02 |
| 50 |
1773608 |
SPACER-1.25X.76X.50 Not Available Price: |
| 51 |
1770992 |
SPACER Not Available Price: |
| 52 |
1766787 |
HARDENED WASHER Not Available Price: |
| 53 |
1768862 |
DECAL-LIFT ROD Price: Call Us |
| 54 |
710-0521 |
SCREW 3/8-16 x 3 GR8 This part replaces 1111614. Price: $4.54 |
| 55 |
736-0169 |
L-Wash. 3/8" I.D." This part replaces 1100243. Price: $3.33 |
| 56 |
1760269 |
SPACER-SPE Not Available Price: |
| 57 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces 1186391. Price: $3.95 |
| 58 |
1770960 |
ROD-IDLER Not Available Price: |
| 59 |
1739796 |
EYE-BOLT Not Available Price: |
| 60 |
1773609 |
SPACER-1.25X.77X.88 Not Available Price: |
| 61 |
710-0347 |
Hex Cap Screw 3/8-16 x 1.75 This part replaces 1100086. Price: $4.39 |
| 62 |
936-3008 |
Flat Washer, .344 x .750 x .120 This part replaces 1982935. Price: $6.24 |
| 64 |
1771922001 |
PLATE-SPROCKET COVER Not Available Price: |
| 65 |
710-04065 |
Screw, 1/4-10 x .625 This part replaces 1771925. Price: $5.48 |
| 100 |
1773614 |
BASE-MOWER 38" W/DECALS Price: Call Us |
| 101 |
1769048099 |
Mower Spindle This part replaces 1769048. Price: $163.09 |
